USB TOYOTA PRIUS 2011 3.G Navigation Manual

AUDIO SYSTEM
186

Selecting a desired folder
(USB memory only)
“Folder
”: Touch this touch −screen but-
ton to go to the next folder.
“Folder \b”: Touch this touch −screen but-
ton to go to the previous folder.
“Select” for Folder: The desired folder
can be selected in a list. This function is
available only when the vehicle is not mov-
ing.
Touch “Select” . The folder list is dis-
played.
Touch the desired folder number. The sys-
tem will start playing the first file of the se-
lected folder.
: By touching this touch−screen but-
ton, the list moves up by 5 folder groups.
If this touch−screen button is touched
when the top page of the list is displayed,
the last page is displayed.
: By touching this touch−screen but-
ton, the list moves down by 5 folder
groups. If this touch−screen button is
touched when the last page of the list is
displayed, the top page is displayed.

AUDIO SYSTEM
187

Selecting a desired file or track
“SEEK/TRACK” button: Use for direct
access to a desired file or track.
Push the “
”
or “” button of “SEEK/
TRACK” and repeat it until the desired file
or track appears on the screen. As you re-
lease the button, the USB memory or iPod
will start playing the selected file or track
from the beginning.
Fast forward:
Push and hold the “
” button of “SEEK/
TRACK” to fast forward the player. When
you release the button, the player will re-
sume playing from that position.
Reverse:
Push and hold the “
” button of “SEEK/
TRACK” to reverse the player. When you
release the button, the player will resume
playing.
U6006vnia
“TUNE/FILE” knob: Use for direct access
to a desired file or track in the player.
Turn the “TUNE/FILE” knob to step up or
down all the files or tracks in the player you
are currently listening to.

AUDIO SYSTEM
188
USB memory
iPod
“Select” for File or Track: The desired
file or track can be selected in a list. This
function is available only when the vehicle
is not moving.
Touch “Select” . The file or track list is dis-
played.
Touch the desired file or track number. The
changer will start playing the selected file
or track from the beginning.
: By touching this touch−screen but-
ton, the list moves up by 5 file or track
groups. If this touch−screen button is
touched when the top page of the list is dis-
played, the last page is displayed.
: By touching this touch−screen but-
ton, the list moves down by 5 file or track
groups. If this touch−screen button is
touched when the last page of the list is
displayed, the top page is displayed.

AUDIO SYSTEM
189

Searching for a desired file
(USB memory only)
Touch “SCAN” briefly while the music
is playing.
“SCAN”
appears on the screen. The play-
er will play the next file for 10 seconds,
then scan again. To select a file, touch
“SCAN” a second time. If the player
reaches the end of the memory, it will con-
tinue scanning at file1.
After all the files are scanned in one pass,
normal play resumes.
Searching for a desired folder
(USB memory only)
Touch “SCAN” for longer than a second
while the music is playing.
“FLD.SCAN” appears on the screen. The
program at the beginning of each folder will
be played for 10 seconds. To continue lis-
tening to the program of your choice, touch
“SCAN” a second time.
After all the folders are scanned in one
pass, normal play resumes.

AUDIO SYSTEM
190

Other function
USB memory
iPod
“RPT”: Use this control to automatic re-
play the file or track you are currently lis-
tening to.
Repeating a file or track —
While the file or track is playing, touch
“RPT” briefly.
“RPT” appears on the screen. When the
file or track is fini shed, the player will auto-
matically play it again. To cancel the re-
peat, touch “RPT” once again. Repeating a folder (USB memory
only) —
While
the folder is playing, touch “RPT”
for longer than a second.
“FLD.RPT” appears on the screen. When
the folder is finished, the changer will auto-
matically go back to the beginning of the
folder and play the folder again. To cancel
it, touch “RPT” once again.
“RAND”: Use this for automatic and ran-
dom selection of files or tracks on the al-
bum that you are currently listening to.
Playing the file or track in random or-
der —
While the file or track is playing, touch
“RAND” briefly.
“RAND” appears on the screen. The sys-
tem selects a file or track you are currently
listening to. To cancel this function, touch
“RAND” once again.
Playing the files in all folders in random
order —
Touch “RAND” for longer than a second
while the music is playing. “FLD.RAND”
appears on the screen. The system se-
lects a file in all folders. To cancel it, touch
“RAND” once again.
When a file is skipped or the system is in-
operative, touch “RAND” to reset.

AUDIO SYSTEM
192
Bluetooth audio player
Use this switch to skip up or down to a dif-
ferent track or album in either direction.
To select a desired track:
Quickly push and release the “
” or “”
side of the switch until the track you want
to listen to is set. If you want to return to the
beginning of the current track, push the
“
” side of the switch once quickly.
To select a desired album:
Push and hold “
” or “” switch until
you hear a beep to change to the next or
the previous album. Repeat this operation
until you reach the album you want to listen
to.
USB memory/iPod
Use this switch to skip up or down to a dif-
ferent file, track or folder in either direction.
To select a desired file or track:
Push the “
” or “” side of the switch
until the file or track you want to listen to is
set. If you want to return to the beginning
of the current file or track, push the “
”
side of the switch once quickly.
To select a desired folder (USB memory
only):
Push and hold “
” or “” switch until
you hear a beep to change to the next or
the previous folder. Repeat this operation
until you reach the folder you want to listen
to.
3“MODE” switch
Push “MODE” switch to select an audio
mode. Each push changes the mode se-
quentially if the desired mode is ready to
use.
To turn the audio system on, push the
“MODE” switch.
To turn the audio system off, push and hold
the “MODE” switch until you hear a beep.
NOTICE
To ensure correct audio system op-
erations:
Be careful not to spill beverages
over the audio system.
Do not put anything other than an
appropriate disc into the CD
changer.
The use of a cellular phone inside
or near the vehicle may cause a
noise from the speakers of the au-
dio system which you are listening
to. However, this does not indicate
a malfunction.
RADIO RECEPTION
Usually, a problem with radio reception
does not mean there is a problem with your
radio — it is just the normal result of condi-
tions outside the vehicle.
For example, nearby buildings and terrain
can interfere with FM reception. Power
lines or telephone wires can interfere with
AM signals. And of course, radio signals
have a limited range. The farther you are
from a station, the weaker its signal will be.
In addition, reception conditions change
constantly as your vehicle moves.
Here are some common reception prob-
lems that probably do not indicate a prob-
lem with your radio:
Audio system operating
hints

AUDIO SYSTEM
193
FM
Fading and drifting stations — Generally,
the effective range of FM is about 25 miles
(40 km). Once outside this range, you may
notice fading and drifting, which increase
with the distance from the radio transmit-
ter. They are often accompanied by distor-
tion.
Multi−path — FM signals are reflective,
making it possible for two signals to reach
your antenna at the same time. If this hap-
pens, the signals will cancel each other
out, causing a momentary flutter or loss of
reception.
Static and fluttering — These occur when
signals are blocked by buildings, trees, or
other large objects. Increasing the bass
level may reduce static and fluttering.
Station swapping — If the FM signal you
are listening to is interrupted or weakened,
and there is another strong station nearby
on the FM band, your radio may tune in the
second station until the original signal can
be picked up again.
AM
Fading — AM broadcasts are reflected by
the upper atmosphere — especially at
night. These reflected signals can inter-
fere with those received directly from the
radio station, causing the radio station to
sound alternately strong and weak.
Station interference — When a reflected
signal and a signal received directly from
a radio station are very nearly the same
frequency, they can interfere with each
other, making it difficult to hear the broad-
cast.
Static — AM is easily affected by external
sources of electrical noise, such as high
tension power lines, lightening, or electri-
cal motors. This results in static. XM

Cargo loaded on the roof luggage carrier,
especially metal objects, may adversely
affect the reception of XM  Satellite Radio.
Alternation or modifications carried out with-
out appropriate authorization may invalidate
the user’s right to operate the equipment.
iPod
About iPod —
Apple is not responsible for the opera-
tion of this device or its compliance with
safety and regulatory standards.
iPod is a trademark of Apple lnc., regis-
tered in the U.S. and other countries.
Compatible models —
Model
GenerationSoftware version
iPod5th
generationVer. 1.2.0 or
higher
iPod
nano1st
generationVer. 1.3.0 or
higher
2nd
generationVer. 1.1.2 or
higher
3rd
generationVer. 1.0.0 or
higher
iPod
touch1st
generationVer. 1.1.0 or
higher
iPod
classic1st
generationVer. 1.0.0 or
higher
Depending on differences between mod-
els or software versions etc., some models
listed above might be incompatible with
this system.
iPod 4th generation and earlier models are
not compatible with this system.
iPhone, iPod mini, iPod shuffle and iPod
photo are not compatible with this system.
USB memory
USB memory that can be used for MP3
and WMA playback.
USB communication formats: USB 2.0
FS (12 MBPS)
File formats: FAT 16/32 (Windows)
Correspondence class: Mass storage
class

AUDIO SYSTEM
197
MP3/WMA FILES
MP3 (MPEG Audio Layer 3) and WMA
(Windows Media Audio) are audio
compression standards.
The MP3/WMA player can play MP3
and WMA files on CD−ROM, CD−R
and CD −RW discs.
The unit can play disc recordings com-
patible with ISO 9660 level 1 and level
2 and with the Romeo and Joliet file
system.
When naming an MP3 or WMA file, add
the appropriate file extension (.mp3 or
.wma).
The MP3/WMA player plays back files
with .mp3 or .wma file extensions as
MP3 or WMA files. To prevent noise
and playback errors, use the appropri-
ate file extensions.
The MP3/WMA player can play only
the first session using multi −session
compatible CDs.
MP3 player — MP3 files are compat-
ible with the ID3 Tag Ver. 1.0, Ver. 1.1,
Ver. 2.2, and Ver. 2.3 formats. The unit
cannot display disc title, track title and
artist name in other formats.
USB memory — MP3 files are compat-
ible with the ID3 Tag Ver. 1.0, Ver.1.1,
Ver 2.2, Ver 2.3 and Ver 2.4 formats.
The unit cannot display track title and
artist name in other formats.
WMA files can contain a WMA tag that
is used in the same way as an ID3 tag.
WMA tags carry information such as
track title, artist name.
The emphasis function is available
only when playing MP3/WMA files re-
corded at 32, 44.1 and 48 kHz.
Sampling frequency
MP3 files for MP3 player:
MPEG 1 LAYER 3 — 32, 44.1, 48 kHz
MPEG 2 LSF LAYER 3 — 16, 22.05, 24
kHz
MP3 files for USB memory:
MPEG 1 AUDIO LAYER 2, 3 — 32,
44.1, 48 kHz
MPEG 2 AUDIO LAYER 2, 3 — 16,
22.05, 24 kHz
MPEG 2.5 — 8, 11.025, 12 kHz
WMA files for WMA player:
Ver. 7, 8, 9 CBR — 32, 44.1, 48 kHz
WMA files for USB memory:
Ver. 9 — HIGH PROFILE 32, 44.1, 48
kHz
The sound quality of MP3/WMA files
generally improves with higher bit rate-
s. In order to achieve a reasonable lev-
el of sound quality, discs recorded with
a bit rate of at least 128 kbps are rec-
ommended.
Playable bit rates
MP3 files for MP3 player:
MPEG 1 LAYER3 — 64 to 320 kbps
MPEG 2 LSF LAYER3 — 64 to 160
kbps
MP3 files for USB memory:
MPEG 1 AUDIO LAYER 2, 3 — 32 to
320 kbps
MPEG 2 AUDIO LAYER 2, 3 — 32 to
160 kbps
MPEG 2.5 — 32 to 160 kbps
WMA files for WMA player:
Ver. 7, 8 CBR — 48 to 192 kbps
Ver. 9 CBR — 48 to 320 kbps
WMA files for USB memory:
Ver. 9 CBR — 32 to 320 kbps
The MP3/WMA player does not play
back MP3/WMA files from discs re-
corder using packet write data transfer
(UDF format). Discs should be re-
corded using “pre −mastering” software
rather than packet− write software.

AUDIO SYSTEM
198

M3u playlists are not compatible with
the audio player.
MP3i (MP3 interactive) and MP3PRO
formats
are not compatible with the au-
dio player.
The player is compatible with VBR
(Variable Bit Rate).
When playing back files recorded as
VBR (Variable Bit Rate) files, the play
time will not be correctly displayed if
fast−forward or reverse operations are
used.
It is not possible to check folders that
do not include MP3/WMA files.
MP3/WMA files in folders up to 8 levels
deep can be played. However, the
start of playback may be delayed when
using discs containing numerous lev-
els of folders. For this reason, we rec-
ommend creating discs with no more
than two levels of folders.
6U5161aX
001.mp3
002.wma
Folder 1003.mp3
Folder 2
004.mp3
005.wma
Folder 3006.mp3
The play order of the compact disc with
the structure shown above is as fol-
lows:
001.mp3 002.wma . . . 006.mp3
MP3/WMA player — It is possible to
play up to 192 folders or 255 files on
one disc.
USB memory — It is possible to play
up to 999 folders, 255 files per folder or
65,025 files in device.
The order changes depending on the
PC and MP3/WMA encoding software
you use.

INDEX
340
Clock button22, 257
. . . . . . . . . . . . . . . . . . .
Clock settings 257
. . . . . . . . . . . . . . . . . . . . . .
CLOSE button 142, 161, 162, 333 . . . . . . .
Command list 47
. . . . . . . . . . . . . . . . . . . . . . .
Compass mode 41
. . . . . . . . . . . . . . . . . . . . .
Compass mode screen 39, 41
. . . . . . . . . . .
Connecting a Bluetooth
audio player 177, 313
. . . . . . . . . . . . . . . .
Connecting a Bluetooth  phone 126 . . . . . .
Connecting a USB memory or iPod 182
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contacts 130, 283
. . . . . . . . . . . . . . . . . . . . .
Contrast 31
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Coordinates button 20, 69
. . . . . . . . . . . . . . .
Current position display 33
. . . . . . . . . . . . . .
Current position/tire change calibration 267
. . . . . . . . . . . . . . . . . . . . . . .
Cursor position as a destination 34 . . . . . . .
Cursor position as
an address book entry 34
. . . . . . . . . . . . .
Customize POI icons 262
. . . . . . . . . . . . . . .
D
Database version 334
. . . . . . . . . . . . . . . . . .
Dayligth saving time 257
. . . . . . . . . . . . . . . .
Dealer setting 318
. . . . . . . . . . . . . . . . . . . . . .
Default 263, 266, 271, 304, 308, 315 . . . . . .
Del. Dest. button 20, 69
. . . . . . . . . . . . . . . . .
Delete personal data 252, 256
. . . . . . . . . . .
Deleting a Bluetooth  phone 278
. . . . . . . . .
Deleting address book entries 112 . . . . . . . .
Deleting areas to avoid 117
. . . . . . . . . . . . . .
Deleting call history 295
. . . . . . . . . . . . . . . . .
Deleting destinations 83
. . . . . . . . . . . . . . . .
Deleting home 103
. . . . . . . . . . . . . . . . . . . . .
Deleting preset destinations 106
. . . . . . . . .
Deleting previous destinations 117 . . . . . . .
Deleting set destinations 69, 83
. . . . . . . . . .
Deleting the phonebook data 287 . . . . . . . .
Deleting the speed dial 294
. . . . . . . . . . . . . .
Deleting the voice tag 300
. . . . . . . . . . . . . . .
DEST button 10, 12, 14, 16, 17, 20, 50 . . . .
Destination information 38
. . . . . . . . . . . . . . .
Destination screen 20, 50
. . . . . . . . . . . . . . .
Destination search 49, 50
. . . . . . . . . . . . . . .
Destination search by “Address” 53 . . . . . . .
Destination search by “Address Book” 64
. . . . . . . . . . . . . . . . . . .
Destination search by “Coordinates” 69 . . .
Destination search by “Emergency” 64 . . . . Destination search by
“Intersection & Freeway” 65
. . . . . . . . . . .
Destination search by “Map” 68
. . . . . . . . . .
Destination search by “Point of Interest” 57
. . . . . . . . . . . . . . . . . .
Destination search by
“Previous Destinations” 63
. . . . . . . . . . . .
Destination search by Home 52
. . . . . . . . . .
Destination search by Preset destinations 52
. . . . . . . . . . . . . . . .
Detailed navigation settings 261
. . . . . . . . . .
Details 305
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Detour setting 84
. . . . . . . . . . . . . . . . . . . . . . .
Dialing by name 134
. . . . . . . . . . . . . . . . . . . .
Disc coverage area 334
. . . . . . . . . . . . . . . . .
Disc slot 161, 333
. . . . . . . . . . . . . . . . . . . . .
DISP button 10, 31
. . . . . . . . . . . . . . . . . . . . .
Display phone status 307
. . . . . . . . . . . . . . .
Display POI icons 90
. . . . . . . . . . . . . . . . . . .
Displaying the title and name 158 . . . . . . . .
Distance and time to destination 10, 81 . . . .
Driving precautions 216
. . . . . . . . . . . . . . . . .
Driving speeds 262, 263
. . . . . . . . . . . . . . . .
Dual map 40
. . . . . . . . . . . . . . . . . . . . . . . . . .
Dual map screen 39, 40
. . . . . . . . . . . . . . . . .
E
Edit “Dealer” or ”Contact” 319
. . . . . . . . . . . .
Edit “Location” 320
. . . . . . . . . . . . . . . . . . . . .
Edit “Phone #” 320
. . . . . . . . . . . . . . . . . . . . .
Edit route 73
. . . . . . . . . . . . . . . . . . . . . . . . . .
Editing address book entries 108
. . . . . . . . .
Editing area to avoid 114
. . . . . . . . . . . . . . . .
Editing home 102
. . . . . . . . . . . . . . . . . . . . . .
Editing preset destinations 105
. . . . . . . . . . .
Editing the Bluetooth  phone 277 . . . . . . . .
Editing the device name 303
. . . . . . . . . . . . .
Editing the passcode 304
. . . . . . . . . . . . . . .
Editing the phonebook data 285
. . . . . . . . . .
Editing the speed dial 293
. . . . . . . . . . . . . . .
Editing the voice tag 300
. . . . . . . . . . . . . . . .
Eject button 162
. . . . . . . . . . . . . . . . . . . . . . .
Ejecting discs 162
. . . . . . . . . . . . . . . . . . . . . .
Emergency button 20, 64
. . . . . . . . . . . . . . . .
Enter a Bluetooth phone 125
. . . . . . . . . . .
Estimated arrival time 81
. . . . . . . . . . . . . . . .
Estimated travel time 81
. . . . . . . . . . . . . . . .
10/09/14 377A_NAVI_U
OM47699U
