wipers TOYOTA PRIUS 2018 Owners Manual (in English)

3
1
9 8
7
6 4 3
2
PRIUS_OM_OM47B89U_(U)
10
5
3-4. Adjusting the steering wheel and mirrors
Steering wheel .................. 198
Inside rear view mirror....... 200
Outside rear view mirrors ............................. 202
3-5. Opening and closing the windows and moon roof
Power windows ................. 204
Moon roof .......................... 208
4-1. Before driving Driving the vehicle ............. 214
Cargo and luggage............ 225
Vehicle load limits ............. 228
Trailer towing..................... 229
Dinghy towing.................... 230
4-2. Driving procedures Power (ignition) switch ...... 231
EV drive mode................... 237
Hybrid transmission........... 240
Turn signal lever................ 246
Parking brake .................... 247
4-3. Operating the lights and wipers
Headlight switch ................ 248
Automatic High Beam ....... 253
Fog light switch ................. 258
Windshield wipers and washer ............................ 260
Rear window wiper and washer ............................ 266 4-4. Refueling
Opening the fuel tank cap................................... 268
4-5. Using the driving support systems
Toyota Safety Sense P ...... 273
PCS (Pre-Collision System) ........................... 281
LDA (Lane Departure Alert with steering
control) ............................ 293
Dynamic radar cruise control with full-speed
range ............................... 304
Cruise control .................... 319
Driving mode select switch .............................. 324
BSM (Blind Spot Monitor)......... 326
• The Blind Spot Monitor function.......................... 331
• The Rear Cross Traffic Alert function ................. 334
Intuitive parking assist ....... 339
Intelligent Clearance Sonar ............................... 350
S-APGS (Simple Advanced Parking
Guidance System) ........... 363
Rear view monitor system ............................. 398
Driving assist systems ....... 408
4-6. Driving tips Hybrid vehicle driving tips ................................... 415
Winter driving tips .............. 418
4Driving

17Pictorial index
PRIUS_OM_OM47B89U_(U)Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 260
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 418
Precautions against car wash (vehicles with rain-sensing
windshield wipers) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 584
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 268
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 268
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 747
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 618
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . P. 752
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 418
Checking/rotation/tire pressure warning system . . . . . . . . . P. 618
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . P. 691, 705
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 601
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 601
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 748
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 735
Headlights/daytime running lights . . . . . . . . . . . . . . . . . . . . P. 248
Parking lights
*1/side marker lights/
LED accent lights
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 248
Fog lights
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 258
Turn signal lights/parking lights
*1. . . . . . . . . . . . . . . . P. 246, 248
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 246
Tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 248
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 248
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 240
4
5
6
7
Light bulbs of the exter ior lights for driving
(Replacing method: P. 654, Watts: P. 754)
*1: The location of the parking lights may differ depending on the grade, etc.
*2: If equipped
8
9
10
11
12
13
14
15

19Pictorial index
PRIUS_OM_OM47B89U_(U)Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 114
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 114
Energy monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 117
When the warning messages are displayed . . . . . . . . . . . . . . P. 684
Parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 247
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 247
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 418
Warning buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 247
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 246
Headlight switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 248
Headlights/parking lights/tail lights/
daytime running lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 248
Fog lights
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 258
Windshield wipers and washer switch . . . . . . . . . . . . . . . . P. 260
Rear window wiper and washer switch
*1 . . . . . . . . . . . . . . P. 266
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 260, 266
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 616
Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . P. 664
Fuel filler door opener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 270
Hood lock release lever. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 601
Tilt and telescopic steering lock release lever . . . . . . . . . . P. 198
Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . P. 516, 526
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 516, 527
Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 520, 530
Entune Audio
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 424
Audio system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 425
Hands-free system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 474
Entune Premium Audio with Navigation
*1, 2
P position switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 241
*1: If equipped
*2: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.
4
5
6
7
8
9
10
11
12
13
14

213
PRIUS_OM_OM47B89U_(U)
4Driving
4-1. Before drivingDriving the vehicle ............. 214
Cargo and luggage ........... 225
Vehicle load limits ............. 228
Trailer towing..................... 229
Dinghy towing ................... 230
4-2. Driving procedures Power (ignition) switch ...... 231
EV drive mode .................. 237
Hybrid transmission........... 240
Turn signal lever................ 246
Parking brake .................... 247
4-3. Operating the lights and wipers
Headlight switch ................ 248
Automatic High Beam ....... 253
Fog light switch ................. 258
Windshield wipers and washer ............................ 260
Rear window wiper and washer ............................ 266
4-4. Refueling Opening the fuel tank cap .................................. 268 4-5. Using the driving support
systems
Toyota Safety Sense P ..... 273
PCS (Pre-Collision System)........................... 281
LDA (Lane Departure Alert with steering
control) ............................ 293
Dynamic radar cruise control with full-speed
range............................... 304
Cruise control .................... 319
Driving mode select switch .............................. 324
BSM (Blind Spot Monitor) ........ 326
• The Blind Spot Monitor function ......................... 331
• The Rear Cross Traffic Alert function ................. 334
Intuitive parking assist....... 339
Intelligent Clearance Sonar .............................. 350
S-APGS (Simple Advanced Parking
Guidance System) .......... 363
Rear view monitor system ............................ 398
Driving assist systems ...... 408
4-6. Driving tips Hybrid vehicle driving tips .................................. 415
Winter driving tips ............. 418

248
PRIUS_OM_OM47B89U_(U)
4-3. Operating the lights and wipers
Headlight switch
Turning the end of the lever turns on the lights as follows:
U.S.A. (type A)The daytime running
lights turn on. ( →P. 251)
The side marker, park-
ing, tail, license plate,
instrument panel lights,
and daytime running
lights ( →P. 251) turn on.
The headlights and all
the lights listed above
(except daytime running
lights) turn on.
The daytime running
lights turn off.
The headlights can be operated manually or automatically.
Operating instructions
1
2
3
4

PRIUS_OM_OM47B89U_(U)
2494-3. Operating the lights and wipers
4
Driving
U.S.A. (type B)
The headlights, side
marker, parking lights,
LED accent lights (if
equipped), daytime run-
ning lights (→P. 251)
and so on turn on and
off automatically (when
the power switch is in
ON mode).
The side marker, park-
ing, LED accent (if
equipped), tail, license
plate, instrument panel
lights, and daytime run-
ning lights ( →P. 251)
turn on.
The headlights and all
the lights listed above
(except daytime run-
ning lights) turn on.
The daytime running
lights turn off.1
2
3
4
(if equipped)

250
PRIUS_OM_OM47B89U_(U)
4-3. Operating the lights and wipers
CanadaThe headlights, side
marker, parking lights,
LED accent lights (if
equipped), daytime run-
ning lights ( →P. 251)
and so on turn on and
off automatically (when
the power switch is in
ON mode).
The side marker, park-
ing, LED accent (if
equipped), tail, license
plate, instrument panel
lights, and daytime run-
ning lights ( →P. 251)
turn on.
The headlights and all the ligh ts listed above (except day-
time running lights) turn on.
The daytime running lights turn on. ( →P. 251)
With the headlights on, push
the lever away from you to turn
on the high beams.
Pull the lever toward you to the
center position to turn the high
beams off.
Pull the lever toward you and
release it to flash the high
beams once.
You can flash the high beams with the headlights on or off.
1
2
Turning on the high beam headlights
3
4
1
2

PRIUS_OM_OM47B89U_(U)
2514-3. Operating the lights and wipers
4
Driving
■Daytime running light system
●The daytime running lights illuminate using the same lights as the head-
lights, and illuminate dimmer than the headlights.
● To make your vehicle more visible to other drivers during daytime driving,
the daytime running lights turn on automatically when all of the following
conditions are met. (The daytime running lights are not designed for use at
night.)
• The hybrid system is operating
• The parking brake is released
• The headlight switch is in the (Canada only), , or
* position
*: When the surroundings are bright
The daytime running lights remain on after they illuminate, even if the park-
ing brake is set again.
● For the U.S.A.: Daytime running lights can be turned off by operating the
switch.
● Compared to turning on the headlights, the daytime running light system
offers greater durability and consumes less electricity, so it can help improve
fuel economy.
■ Headlight control sensor (if equipped)
■ Automatic light off system
●When the headlights come on: The headlights and tail lights turn off 30 sec-
onds after a door is opened and closed if the power switch is turned to
ACCESSORY mode or turned off. (The lights turn off immediately if on
the key is pressed after all the doors are locked.)
● When only the tail lights come on: The tail lights turn off automatically if the
power switch is turned to ACCESSORY mode or turned off and the driver’s
door is opened.
To turn the lights on again, turn the power switch to ON mode, or turn th\
e light
switch off once and then back to or . The sensor may not function properly if an
object is placed on the sensor, or anything
that blocks the sensor is affixed to the
windshield.
Doing so interferes with the sensor
detecting the level of ambient light and
may cause the automatic headlight sys-
tem to malfunction.
Air conditioning operation may also be
interrupted.

252
PRIUS_OM_OM47B89U_(U)
4-3. Operating the lights and wipers
■12-volt battery-saving function
In order to prevent the 12-volt battery of the vehicle from discharging, if the
headlights and/or tail lights are on when the power switch is turned off, the
12-volt battery saving function will operate and automatically turn off all the
lights after approximately 20 minutes.
When any of the following are performed, the 12-volt battery-saving function
is canceled once and then reactivated. All the lights will turn off automatically
20 minutes after the 12-volt battery-saving function has been reactivated:
●When the headlight switch is operated
● When a door is opened or closed
■ If “Headlight System Ma lfunction Visit Your Dealer” is displayed on the
multi-information display
The system may be malfunctioning. Have the vehicle inspected by your Toy-
ota dealer.
■ Customization
Settings (e.g. light sensor sensitivity) can be changed.
(Customizable features: →P. 770)
NOTICE
■To prevent 12-volt battery discharge
Do not leave the lights on longer than necessary when the hybrid system is
off.

253
PRIUS_OM_OM47B89U_(U)
4-3. Operating the lights and wipers
4
Driving
Automatic High Beam∗
Push the lever away from you
with the headlight switch in the or position.
Press the Automatic High
Beam switch.
The Automatic High Beam indica-
tor will come on when the head-
lights are turned on automatically
to indicate that the system is
active.
∗: If equipped
The Automatic High Beam uses an in-vehicle camera sensor to
assess the brightness of streetlights, the lights of vehicles
ahead etc., and automatically turns the high beam on or off as
necessary.
WARNING
■ Limitations of the Automatic High Beam
Do not rely on the Automatic High Beam. Always drive safely, taking care to
observe your surroundings and turning the high beam on or off manually if
necessary.
■ To prevent incorrect operation of the Automatic High Beam system
Do not overload the vehicle.
Activating the Automatic High Beam system
1
2
