bluetooth TOYOTA PRIUS 2020 Accessories, Audio & Navigation (in English)

PRIUS_MM_OM47D53U_(U)
1
2
3
4
5
6
7
8
Quick guide• Basic system overview
Basic function
• Information to be read before operation
• Setting initial settings before operation
• Connecting the Bluetooth
® device
Audio/visual
system• Listening to the radio
• Enjoying music and video
Voice command
system• Operating the voice command system
Peripheral
monitoring
system
• Checking the situation around the vehicle
Phone• Operating the phone
(Hands-free system for cellular phones)
Connected
Services• Operating the Connected Services
Index• Search alphabetically

2TABLE OF CONTENTS
Introduction ................................4
Reading this manual .................. 5
1-1. Basic function Buttons overview................ 8
“Menu” screen .................. 10
Status icon ....................... 11
“Setup” screen ................. 13
“Information” screen ......... 14
2-1. Basic information before operation
Initial screen ..................... 16
Touch screen.................... 17
Home screen.................... 19
Entering letters and num- bers/list screen operation 20
Screen adjustment ........... 23
Linking multi-information dis- play and the system ....... 24
2-2. Connectivity settings Registering/Connecting a Bluetooth
® device .......... 25
Setting Bluetooth
® details 29
Wi-Fi
® Hotspot ................. 36
Apple CarPlay™ .............. 41
2-3. Other settings General settings ............... 46
Voice settings ................... 49
Vehicle settings ................ 503-1. Basic operation
Quick reference ................ 54
Some basics ..................... 56
3-2. Radio operation AM/FM/SiriusXM (SXM) radio....................................... 61
Internet radio .................... 69
3-3. Media operation CD .................................... 70
USB memory .................... 72
iPod/iPhone ...................... 74
Bluetooth
® audio .............. 77
AUX .................................. 80
3-4. Audio/visual remote con- trols
Steering switches ............. 82
3-5. Setup Audio settings ................... 84
3-6. Tips for operating the audio/visual system
Operating information ....... 86
4-1. Voice command system operation
Voice command system 100
Command list ................ 103
4-2. Mobile Assistant operation Mobile Assistant ............ 107
1Quick guide
2Basic function
3Audio/visual system
4Voice command system

3TABLE OF CONTENTS
1
2
3
4
5
6
7
5-1. Rear view monitor systemRear view monitor system.................................... 110
Rear view monitor system precautions.................. 112
Things you should know 117
6-1. Phone operation (Hands- free system for cellular
phones)
Quick reference............. 120
Some basics ................. 121
Placing a call using the Blue- tooth
® hands-free system
.................................... 125
Receiving a ca ll using the
Bluetooth
®hands-free sys-
tem .............................. 128
Talking on the Bluetooth
®
hands-free system....... 129
Bluetooth
® phone message
function........................ 131
6-2. Setup Phone settings .............. 136
6-3. What to do if... Troubleshooting ............ 146
7-1. Connected Services over- view
Functional overview ...... 152Type A: Function achieved by
using a smartphone or DCM.................................... 153
Type B: Function achieved by using DCM and the system.................................... 156
Type C: Function achieved by using DCM................... 157
7-2. Connected Services opera- tion
Toyota Apps ................... 159
7-3. Setup Toyota Apps settings ..... 163
Alphabetical Index ........ 166
5Peripheral monitoring
system
6Phone
7Connected Services
Index

81-1. Basic function
1-1.Basic function
Press to eject a disc.*1 ( P. 5 7 )
By touching the screen with y our finger, you can control the
selected functions. ( P.17)
Insert a disc into this slot. The CD player turns on immediatel y.
*1
( P. 5 7 )
Press to play/pause. Press to turn mute on/off.
*1
Press to seek up or down for a radio station or to access a
desired track/file. ( P.61, 70, 72, 74, 77)
Press to access the Bluetooth
® hands-free system. ( P.120)
When an Apple CarPlay connection is established, press to dis-
play the phone app screen.
*2, 3
Press to display the Toyota apps screen.*3, 4 (  P.159)
Turn to change the radio station or skip to the next or previou s
track/file. ( P.61, 70, 72, 74, 77)
Press to turn the audio/visual system on and off, and turn it t o
adjust the volume. Press and hold to restart the system. ( P.16,
Buttons over view
Operations of each part
A
B
C
D
E
F
G
H
I

111-1. Basic function
1
Quick guide
Indicate during data commu-
nication performed via Data
Communication Module
(DCM)
*1
The reception level of Data
Communication Module
(DCM) display
*1 ( P. 1 1 )
The reception level of the
connected phone display
( P. 1 1 )
Remaining battery charge
display ( P. 1 2 )
Bluetooth
® phone connection
condition display ( P.12)
Wi-Fi
® connection condition
display
*1, 2 (  P. 3 6 )
*1: Vehicles with DCM
*2: This function is not made avail-
able in some countries or areas.
●The number of status icons that
can be displayed differs depend-
ing on the displayed screen.
The level of reception does not
always correspond with the level
displayed on the cellular phone.
The level of reception may not
be displayed depending on the
phone you have.
When the cellular phone is out
of the service area or in a place
inaccessible by radio waves,
/ is displayed.
“Rm” is displayed when receiv-
ing in a roaming area. While
roaming, display “Rm” top-left
on the icon.
The receiving area may not be
displayed depending on the type
of Bluetooth
® phone you have.
While connected with cellular
phone
Status icon
Status icons are displayed
at the top of the screen.
Status icon explanation
A
B
C
D
E
F
5HFHSWLRQOHYHOGLVSOD\
Reception LevelIndicators
Poor
Excellent

121-1. Basic function
While using Data Communi-
cation Module (DCM)
While using Wi-Fi®hotspot
●When Wi-Fi® hotspot is off, no
item is displayed.
The amount displayed does not
always correspond with the
amount displayed on the Blue-
tooth
® device.
The amount of battery charge
left may not be displayed
depending on the type of the
Bluetooth
® device connected.
This system does not have a
charging function. An antenna for the Bluetooth
®
connection is built into the
instrument panel.
The condition of the Bluetooth
®
connection may deteriorate and
the system may not function
when a Bluetooth
® phone is
used in the following conditions
and/or places:
The cellular phone is obstructed
by certain objects (such as
when it is behind the seat or in
the glove box or console box).
The cellular phone is touching or
is covered with metal materials.
Leave the Bluetooth
® phone in a
place where the condition of the
Bluetooth
® connection is good.
Reception LevelIndicators
Poor
Excellent
Reception LevelIndicators
No connection
Connected
Remaining battery charge
display
Remaining chargeIndicators
Empty
Full
Bluetooth® connection
condition display
IndicatorsConditions
(Blue)
Indicates that the con-
dition of the Blue-
tooth
® connection is
good.
(Gray)
While in this condition,
sound quality during
phone calls may dete-
riorate.
Indicates that the cel-
lular phone is not con-
nected via Bluetooth
®.

131-1. Basic function
1
Quick guide
Press the “MENU” button, then
select “Setup” to display the
“Setup” screen. The items
shown on the “Setup” screen
can be set.Select to change the selected
language, operation sound
settings, etc. ( P. 4 6 )
Select to set Bluetooth
®
device and Bluetooth
® sys-
tem settings. ( P. 2 9 )
Select to set audio settings.
( P. 8 4 )
Select to set the phone
sounds, contacts, message
settings, etc. ( P.136)
Select to set the voice set-
tings. ( P.49) Select to set vehicle informa-
tion. (
P.50)
Select to set Wi-Fi
® connec-
tion settings.
*1, 2 (  P. 3 7 )
Select to set Toyota apps set-
tings.
*2 (  P.163)
*1: Vehicles with DCM
*2: This function is not made avail-
able in some countries or areas.
“Setup” screen
“Setup” screen
A
B
C
D
E
F
G
H

15
2
2
Basic function
Basic function
2-1. Basic information before operation
Initial screen ................... 16
Touch screen.................. 17
Home screen.................. 19
Entering letters and num- bers/list screen operation..................................... 20
Screen adjustment ......... 23
Linking multi-information display and the system. 24
2-2. Connectivity settings Registering/Connecting a Bluetooth
® device ........ 25
Setting Bluetooth
® details
..................................... 29
Wi-Fi
® Hotspot ............... 36
Apple CarPlay™ ............ 41
2-3. Other settings General settings ............. 46
Voice settings ................. 49
Vehicle settings .............. 50

252-2. Connectivity settings
2
Basic function
2-2.Connectivity settings
■Registering from the sys-
tem
1 Turn the Bluetooth
® connec-
tion setting of your cellular
phone on.
 This function is not available
when Bluetooth
® connection
setting of your cellular phone
is set to off. 2
Press the “MENU” button.
3 Select “Phone”.
 Operations up to this point
can also be performed by
pressing the “PHONE” button
on the instrument panel.
4 Select “Yes” to register a
phone.
5 Select the desired Bluetooth
®
device.
 If the desired Bluetooth
®
phone is not on the list, select
“If you cannot find...” and fol-
low the guidance on the
Registering/Connect-
ing a Bluetooth®
device
To use the hands-free sys-
tem, it is necessary to regis-
ter a Bluetooth
® phone with
the system.
Once the phone has been
registered, it is possible to
use the hands-free system.
This operation cannot be
performed while driving.
When an Apple CarPlay
connection is established,
Bluetooth
® functions of the
system will become unavail-
able and any connected
Bluetooth
® devices will be
disconnected.
Registering a Bluetooth®
phone for the first time

262-2. Connectivity settings
screen. (P. 2 7 )
6 Register the Bluetooth
®
device using your Blue-
tooth
® device.
 For details about operating
the Bluetooth
® device, see
the manual that comes with it.
 A PIN code is not required for
SSP (Secure Simple Pairing)
compatible Bluetooth
®
devices. Depending on the
type of Bluetooth
® device
being connected, a message
confirming registration may
be displayed on the Blue-
tooth
® device’s screen.
Respond and operate the
Bluetooth
® device according
to the confirmation message.
7 Check that the following
screen is displayed, indicat-
ing pairing was successful (a
Bluetooth
® link has been established but registration is
not yet complete).
 The system is connecting to
the registered device.
 At this stage, the Bluetooth
®
functions are not yet avail-
able.
8 Check that “Connected” is
displayed and registration is
complete.
 If an error message is dis-
played, follow the guidance
on the screen to try again.
●If a cellular phone does not oper-
ate properly after being con-
nected, turn the cellular phone off
and on and then c onnect it again.
