TOYOTA PRIUS 2020 Owners Manual (in English)

PRIUS_OM_OM47D44U_(U)
4214-6. Driving tips
4
Driving
NOTICE
■Repairing or replacing snow tires
Request repairs or replacement of snow tires from Toyota dealer s or legiti-
mate tire retailers.
This is because the removal and attachment of snow tires affect s the opera-
tion of the tire pressure warning valves and transmitters.
■ Fitting tire chains
The tire pressure warning valves and transmitters may not funct ion correctly
when tire chains are fitted.

422
PRIUS_OM_OM47D44U_(U)
4-6. Driving tips

423
PRIUS_OM_OM47D44U_(U)
5Interior features
5-1. Using the air conditioning system and defogger
Automatic air conditioning system (vehicles with
7-inch display) ................. 424
Automatic air conditioning system (vehicles with
11.6-inch display) ............ 434
Heated steering wheel/ seat heaters .................... 444
5-2. Using the interior lights Interior lights list ................ 446• Front interior light .......... 447
• Front personal lights ..... 447
• Rear interior light .......... 448 5-3. Using the storage
features
List of storage features ..... 449 • Glove box...................... 450
• Console box .................. 450
• Cup holders .................. 451
• Bottle holders/door pockets ................. 452
• Auxiliary boxes.............. 453
• Seat back pockets ........ 454
Luggage compartment features ........................... 455
5-4. Using the other interior features
Other interior features ....... 461 • Sun visors ..................... 461
• Vanity mirrors................ 461
• Power outlets ................ 462
• USB charging ports....... 463
• Wireless charger ........... 465
• Armrest ......................... 474
• Coat hooks.................... 474
• Assist grips ................... 475
Garage door opener.......... 476

424
PRIUS_OM_OM47D44U_(U)
5-1. Using the air conditioning system and defogger
Automatic air conditioning system
(vehicles with 7-inch display)
■Adjusting the temperature setting
Move the temperature setting
knob upwards to increase the
temperature and downwards to
decrease the temperature.
If is not pressed, the sys-
tem will blow ambient tempera-
ture air or heated air.
■
Fan speed setting
Move the fan speed setting
knob upwards to increase the
fan speed and downwards to
decrease the fan speed.
The fan speed is shown on the
display. (7 levels)
Press to turn the fan off.
Air outlets and fan speed are automatically adjusted according
to the temperature setting.
Air conditioning controls
Temperature
setting knob
Fan speed
setting knob

PRIUS_OM_OM47D44U_(U)
4255-1. Using the air conditioning system and defogger
5
Interior features
■Change the airflow mode
Move the airflow change knob
upwards or downwards to
change the airflow mode.
The air outlets used are
switched each time the knob is
operated.
Air flows to the upper body
Air flows to the upper body
and feet
Air flows to the feet
Air flows to the feet and the
windshield defogger oper-
ates
Airflow change
knob
1
2
3
4

4265-1. Using the air conditioning system and defogger
PRIUS_OM_OM47D44U_(U)■
S-FLOW mode
In S-FLOW mode, priority for the
airflow is given to the front seats,
reducing the airflow and air conditioning effect on the rear se ats.
When a passenger is not detected in the front passenger seat,
depending on the set temperature and ambient temperature, prior -
ity for the airflow will be given to the driver’s seat only.
However, air will always be blown from the side outlet of the front pas-
senger seat.
The following S-FLOW modes are available:
Automatic S-FLOW mode
The system determines whether or not a rear passenger is in the
vehicle by the opening and closing of a rear door. When a rear pas-
senger is determined to be in t he vehicle, S-FLOW mode will be
automatically disabled.
To enable S-FLOW mode again, press and enter manual
S-FLOW mode. ( P. 430)
The indicator will illuminate when S-FLOW mode is enabled.
Manual S-FLOW mode
When is pressed, S-FLOW mo de will be manually enabled/
disabled. ( P. 430)
The indicator will illuminate when S-FLOW mode is enabled.
When the power switch is turned to ON mode, the system is oper-
ated in automatic S-FLOW mode.
■Other functions
● Switching between outside air and recirculated air modes
(  P. 427)
● Defogging the windshield ( P. 4 2 8 )
● Defogging the rear window and outside rear view mirrors
(  P. 428)

PRIUS_OM_OM47D44U_(U)
4275-1. Using the air conditioning system and defogger
5
Interior features
Press .
Adjust the temperature setting. (P. 4 2 4 )
Press .
The cooling and dehumidificati on function switches between on a nd
off each time is pressed.
To stop the operation, press .
■Automatic mode indicator
If the fan speed setting or air flow modes are operated, the
indicator goes off. However, automatic mode for functions other
than that operat ed is maintained.
■Switching between outside air and recirculated air modes
Press .
The mode switches between outside air mode and recirculated air mode
each time is pressed.
The indicator illuminates when the recirculated air mode is
selected.
■
Air conditioning eco mode
The air conditioning system is c ontrolled with low fuel consumption
prioritized such as re ducing fan speed, etc.
Press .
The air conditioning eco mode switches between on and off each time
is pressed.
“ECO” is displayed in the air conditioning control panel displa y when the
air conditioning eco mode is on.
Using automatic mode
Other functions
1
2
3
4

4285-1. Using the air conditioning system and defogger
PRIUS_OM_OM47D44U_(U)■
Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Press .
Set to outside air mode if the recirculated air mode is used.
(It
may switch automatically.)
To defog the windshield and the side windows early, turn the ai r flow and
temperature up.
The indicator illuminates when the defoggers are on.
To return to the previous mode, press again when the wind-
shield is defogged. Also, turning the power switch off during o peration
can return to the previous mode.
■
Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window and to remove rain-
drops, dew and frost from the outside rear view mirrors.
Press .
Defoggers switch between on and off each time is pressed.
The indicator illuminates when the defoggers are on.
The defoggers will automatically turn off after approximately 1 5 minutes.
■
Eco score (A/C score)
 P. 1 2 9

PRIUS_OM_OM47D44U_(U)
4295-1. Using the air conditioning system and defogger
5
Interior features
■Location of air outlets
The air outlets and air volume
change according to the
selected airflow mode.
■Adjusting the air flow direction
Direct air flow to the left or right,
up or down.
■Opening and closi ng the air outlets
Air outlets
Left side outlet/right side outletCenter outlets
Open the vent
Close the vent Open the vent
Close the vent
1
2
1
2

4305-1. Using the air conditioning system and defogger
PRIUS_OM_OM47D44U_(U)
■Using automatic mode
Fan speed is adjusted automatically according to the temperatur e setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after is pressed.
■ Setting confirmation screen
■ S-FLOW mode operation
■ Changing from manual S-FLOW mode to automatic S-FLOW mode
Press to disable S-FLOW mode.
The indicator will go off.
Turn the power switch off.
After 60 minutes have elapsed, change the power switch to ON mo de.
■ Changing settings using the multi-information display
The air conditioning system settings can be changed on the scr een of
the multi-information display. ( P. 145)
■ Fogging up of the windows
●The windows will easily fog up when the humidity in the vehicle is high.
Turning on will dehumidify the air from the outlets and defog the
windshield effectively.
● If you turn off, the windows may fog up more easily.
● The windows may fog up if the recirculated air mode is used.
When changing the settings of the air
conditioning system, the setting confirma-
tion screen is shown as a pop-up on the
multi-information display.
Press of the meter control switches to
go back to the previous screen.
When is pressed, the S-FLOW
mode status is displayed on the multi-
information display.
1
2
3
