display TOYOTA PRIUS 2021 Accessories, Audio & Navigation (in English)

286
2. CONNECTED SERVICE OPERATION
PRIUS_Navi_OM47E22U_(U)
20.03.26 18:17
1Press the “MENU” button.
2Select “Destination” .
3Select “Web Search” .
4Check that the “Web Search” screen is
displayed.
1Display the “Web Search” screen.
(P.286)
2Select the desired application button to
search.
3Enter a search t erm, and select “OK”.
4Select an item in list.
5Select “Go to ”.
LINKING Toyota Apps AND
NAVIGATION FUNCTION
The system can set a destination and
make a hands-free call via Toyota
apps. For details about the function
and service of each application, refer
to http://www.toyota.com/audio-
multimedia/.
SETTING A DESTINATION
USING Toyota Apps
Locations that were searched using
Toyota apps can be set as a destina-
tion.

287
2. CONNECTED SERVICE OPERATION
PRIUS_Navi_OM47E22U_(U)
20.03.26 18:17
Toyota Apps
9
6Select “OK” to start guidance.
1Display the “Web Search” screen.
(P.286)
2Select the desired application button to
search.
3Enter a search term, and select “GO”.
4Select “Call”.
5Select “Yes”.
“Cancel” : Select to cancel making a
phone call.
6Check that the “Ca ll” screen is dis-
played.
 For the operation of the route guidance
screen and the function of each screen
button: P.235
INFORMATION
● Actual sequence may vary based on the
application.
MAKING A PHONE CALL
USING A POI DESTINATION
Phone call can be made to POI loca-
tions which were searched.
 For phone operation and the function of
each screen button: P.176

288
2. CONNECTED SERVICE OPERATION
PRIUS_Navi_OM47E22U_(U)
20.03.26 18:17
1Display the Toyota apps screen.
(P.282)
2Select the desired application button.
3Select the character input space.
4Enter a search term, and then select
“OK”.
5Entering characters will be reflected on
the character input space.
Toyota Apps KEYWORD
OPERATION
Information can be entered to an appli-
cation by the software keyboard.
The keyboard layout can be changed.
( P. 7 2 )
USING THE SOFTWARE
KEYBOARD
For details on operating the keyboard:
P. 4 4

289
2. CONNECTED SERVICE OPERATION
PRIUS_Navi_OM47E22U_(U)
20.03.26 18:17
Toyota Apps
9
1Press the “MENU” button.
2Select “Toyota Apps” .
3Select “Fuel”.
The screen shown above is only an exam-
ple. The actual screen may be different.
4Select a desired gas and charging sta-
tion.
“Sort”: Select to sort the gas and charging
stations. ( P.290)
“Fuel Type” : Select to narrow down the
desired fuel type. ( P.290)
5The detailed informations about the
gas and charging stations will be dis-
played.
“Map” : Select to display the map of the se-
lected station.
“Call” : Select to call the registered num-
ber.
FUEL APPLICATION
Gas and charging stations can be dis-
played on the list.
Their location can also be set as a des-
tination.

290
2. CONNECTED SERVICE OPERATION
PRIUS_Navi_OM47E22U_(U)
20.03.26 18:17
1Displaying the “Fuel” screen. (P.289)
2Select “Sort”.
3Select the desired sorting criteria.
1Displaying the “Fuel” screen. ( P.289)
2Select “Fuel Type” .
3Select the desired fuel type.
SORTING
The order of a list displayed on the
screen can be sorted in the order of
distance from the current location,
name, and price.
SELECTING A FUEL TYPE
The list displayed on the screen can be
narrowed down the supported fuel
type.

295
PRIUS_Navi_OM47E22U_(U)
20.04.15 12:05
E
Editing route............................................ 246Adding destinations ............................. 247
Deleting destinations ........................... 247
Detour setting ...................................... 249
Reordering destinations ...................... 247
Selecting route type ............................ 248
Setting route preferences .................... 248
Starting from adjacent road ................. 250
Entering letters and numbers/ list screen operation .............................. 44
Entering letters and numbers ................ 44
List screen ............................................. 45
F
Function index .......................................... 32
G
General settings........................................ 72
General settings screen ........................ 72
GPS (Global positioning system) ............ 272
Limitations of the navigation system ... 272
I
Information .............................................. 147
“Information” screen.................................. 24
Initial screen.............................................. 36
Internet radio........................................... 104Listening to internet radio .................... 104
iPod......................................................... 10 9
iPod audio ........................................... 112
Overview ............................................. 109
L
Linking multi-information display and navigation system........ .......................... 50
M
Map database version and covered
area ..................................................... 275
About the map data ............................. 276
Map information................................... 275
Map screen ............................................... 16 Display areas......................................... 18
Status display ........................................ 20
Map screen information .......................... 213 Displaying information about the icon where the cursor is set..................... 218
Displaying map information ................. 213
Standard map icons ............................ 219
Map screen operation ............................. 207
Adjusting location in small increments ....................................... 212
Current position display ....................... 207
Map scale ............................................ 208
Orientation of the map ......................... 208
Screen scroll operation........................ 211
Switching the map mode ..................... 209
Media operation ...................................... 105
Memory points ........................................ 251
Memory points settings ........................... 251 Deleting previous destinations ............ 260
Setting up address book...................... 255
Setting up areas to avoid..................... 258
Setting up home .................................. 252
Setting up preset destinations ............. 253
Menu screen ............................................. 14
Mobile assistant ...................................... 144
Mobile assistant operation ...................... 144

296
ALPHABETICAL INDEX
PRIUS_Navi_OM47E22U_(U)
20.04.15 12:05
N
Navigation operation ................................. 26
Navigation system................................ ... 201
O
Operating information ............................. 123
Error messages ................................... 129
File information .................................... 125
iPod ..................................................... 124
Radio ................................................... 123
Terms .................................................. 127
Operation flow: Guiding the route ............. 30
Operation of menu buttons on map screen.................................................... 42
Change the menu buttons ..................... 43
Display/hide the menu buttons .............. 42
Other settings............................................ 72
P
Peripheral monitoring system ................. 151
Phone...................................................... 163
Phone operation (Hands-free system for cellular phones) ................................... 164
Phone settings ........................................ 184 “Contacts/Call History” screen............. 186
“Messaging” screen ............................. 192
“Notifications” screen........................... 193
“Sounds” screen .................................. 185
Q
Quick guide ............................................... 11
Quick reference................... 22, 82, 164, 204Map screen.......................................... 204
Navigation options screen ................... 206
R
Radio operation .........................................89
Rear view monitor system .......................152
Driving precautions ..............................152
Screen description ...............................154
Rear view monitor system precautions ...156 Area displayed on screen ....................156
Differences between the screen and the actual road .................................158
The camera .........................................157
When approaching three-dimensional objects..............................................159
Receiving on the Bluetooth
® phone ........175
Incoming calls ......................................175
Receiving weather information ................148
Displaying weather information ...........148
Registering home ......................................26
Registering preset destinations .................28
Registering/connecting Bluetooth
®
device ....................................................51
Certification............................................55
Profiles...................................................53
Registering a Bluetooth
® audio
player for the first time .......................52
Registering a Bluetooth
® phone
for the first time ..................................51
Route guidance .......................................239
Route guidance screen ...........................239 During freeway driving .........................242
Route overview ....................................241
Screen for route guidance ...................239
Turn list screen ....................................244
Turn-by-turn arrow screen ...................244
When approaching intersection ...........243

297
PRIUS_Navi_OM47E22U_(U)
20.04.15 12:05
S
Screen adjustment .................................... 48
Search operation .................................... 225Searching by address ......................... 227
Searching by address book................. 231
Searching by coordinates.................... 234
Searching by emergency .................... 232
Searching by intersection and freeway ............................................ 232
Searching by map ............................... 234
Searching by point of interest.............. 228
Searching from previous destinations ..................................... 231
Selecting search area ......................... 226
Setting home as destination ................ 226
Setting preset destinations as destination ....................................... 226
Setting Bluetooth
® details ......................... 58
“Bluetooth* Setup” screen ..................... 58
Connecting a Bluetooth
® device ........... 61
Deleting a Bluetooth® device ................ 60
Editing the Bluetooth® device
information ......................................... 63
Registering a Bluetooth
® device ........... 59
“System Settings” screen ...................... 64 Setting home as the destination................ 31
Setup............................... 121, 184, 261, 291
“Setup” screen .......................................... 22
SiriusXM
® Satellite Radio ......................... 98
Displaying the radio ID ........................ 101
How to subscribe to SiriusXM Radio
Services ........................................... 100
If the satellite radio tuner malfunctions..................................... 102
Overview ............................................... 98
Selecting a channel from the list ......... 101
Some basics ..................................... 83, 165 About the contacts in the contact list ... 168
Audio screen adjustment ....................... 87
Registering/connecting a Bluetooth
®
phone ............................................... 166
Selecting an audio source ..................... 84
“Sound Settings” screen ........................ 85
Turning the system on and off ............... 83
USB/AUX port ....................................... 85
Using the phone switch/microphone ... 166
Voice command system .... ............ 88, 167
When selling or disposing of the vehicle.............................................. 169
Starting route guidance ........................... 235 Pausing guidance ................................ 238
Starting route guidance ....................... 235
Steering switches .................................... 119
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

298
ALPHABETICAL INDEX
PRIUS_Navi_OM47E22U_(U)
20.04.15 12:05
T
Talking on the Bluetooth® phone ............ 176
Incoming call waiting ........................... 178
Things you should know ......................... 161
If you notice any symptoms ................. 161
Tips for operating the audio system ........ 123
Tips for the navigation system ................ 272
Touch screen gestures ............................. 40
Touch screen operation ............................ 41
Toyota Apps .................................... 277, 282 Fuel application ................................... 289
Linking Toyota Apps and navigation function ............................................ 286
Toyota Apps keyword operation .......... 288
Using Toyota Apps .............................. 282
Toyota Apps settings .............................. 291
Traffic information ................................... 220 Displaying traffic information on the map ....................................... 222
Traffic settings......................................... 265 Auto avoid traffic.................................. 266
My traffic routes ................................... 267
Screen for traffic settings..................... 265
Troubleshooting ...................................... 195
Typical voice guidance prompts.............. 245
U
USB memory ...........................................105 Overview..............................................105
USB audio ...........................................108
USB video............................................108
Useful information ...................................148
V
Vehicle settings .........................................76 Maintenance ..........................................76
Voice command system ..................131, 132 Using the voice command system .......132
Voice command system operation ......133
Voice command system oper ation ..........132
Voice settings ............................................75
Voice settings screen ............................75
W
What to do if... ........................................195
