TOYOTA PRIUS 2021 Owners Manual (in English)

611
PRIUS_OM_OM47E09U_(U)
7
When trouble arises
7-2. Steps to take in an emergency
If you have a flat tire (vehicles without
spare tire)
Your vehicle is not equipped with a spare tire, but instead is
equipped with an emergency tire puncture repair kit.
A puncture caused by a nail or screw passing through the tire
tread can be repaired temporarily using the emergency tire
puncture repair kit. (The kit contains a bottle of sealant. The
sealant can be used only once to temporarily repair one tire
without removing the nail or screw from the tire.) After tempor ar-
ily repairing the tire with the kit, have the tire repaired or
replaced by your Toyota dealer.
WARNING
■If you have a flat tire
Do not continue driving with a flat tire.
Driving even a short distance wit h a flat tire can damage the tire and the
wheel beyond repair, which cou ld result in an accident.

6127-2. Steps to take in an emergency
PRIUS_OM_OM47E09U_(U)
●Stop the vehicle in a safe place on a hard, flat surface.
● Set the parking brake.
● Shift the shift position to P.
● Stop the hybrid system.
● Turn on the emergency flashers.
● Check the degree of the tire damage.
A tire should only be repaired
with the emergency tire punc-
ture repair kit if the damage is
caused by a nail or screw pass-
ing through the tire tread. • Do not remove the nail or screw from the tire. Remov-
ing the object may widen the
opening and make emer-
gency repair with the repair
kit impossible.
• To avoid sealant leakage, move the vehicle until the area of the
puncture, if known, is positioned at the top of the tire.
■A flat tire that cannot be repaired with the emergency tire pun cture
repair kit
In the following cases, the tire cannot be repaired with the em ergency tire
puncture repair kit. Contact your Toyota dealer.
●When the tire is damaged due to driving without sufficient air pressure
●When there are any cracks or damage at any location on the tire , such
as on the side wall, except the tread
●When the tire is visibly separated from the wheel
●When the cut or damage to the tr ead is 0.16 in. (4 mm) long or more
●When the wheel is damaged
●When two or more tires have been punctured
●When more than one sharp objects such as nails or screws have p assed
through the tread on a single tire
●When the sealant has expired
Before repairing the tire

6137-2. Steps to take in an emergency
PRIUS_OM_OM47E09U_(U)
7
When trouble arises
2WD models
Location of the emergency tire puncture repair kit and tools
Jack handle
Jack
(Use of the jack: P. 6 1 7 )
Wheel nut wrench Emergency tire puncture
repair kit
Towing eyelet1
2
3
4
5

6147-2. Steps to take in an emergency
PRIUS_OM_OM47E09U_(U)
AWD models
To w i n g e y e l e t
Jack handle
Wheel nut wrenchEmergency tire puncture
repair kit
Jack
(Use of the jack: 
P. 617)1
2
3
4
5

6157-2. Steps to take in an emergency
PRIUS_OM_OM47E09U_(U)
7
When trouble arises
Emergency tire puncture repair kit components
Hose
Air release cap
StickerPower plug
Air pressure gauge
Compressor switch1
2
3
4
5
6

6167-2. Steps to take in an emergency
PRIUS_OM_OM47E09U_(U)
Pull up the handle to open the
deck board.
Secure the deck board using
the grocery bag hooks.
( P. 469)
Take out the emergency t ire puncture repair kit.
2WD models: If the luggage cover (if equipped) is stowed, turn over the
tonneau cover to take out the emergency tire puncture repair ki t.
Taking out the emergency tire puncture repair kit
1
2
3
2WD modelsAWD models

6177-2. Steps to take in an emergency
PRIUS_OM_OM47E09U_(U)
7
When trouble arises
■Taking out the jack
Unhook the tightening strap and take out the jack.
■Storing the jack
Place the jack in the same direction as the mark next to the storage
space.
2WD models AWD models
2WD modelsAWD models
WARNING
■After using the tools and jack
Before driving, make sure all the tools and jack are securely i n place in
their storage locatio n to reduce the possibility of personal in jury during a
collision or su dden braking.

6187-2. Steps to take in an emergency
PRIUS_OM_OM47E09U_(U)
Take out the repair kit from the plastic bag.
Remove the valve cap from the
valve of the punctured tire.
Extend the hose. Remove the
air release cap from the hose.
Attach the sticker enclosed with
the bottle on the specified loca-
tions. (See step .)
You will use the air release cap
again. Therefore keep it in a safe
place.
Connect the hose to the valve.
Screw the end of the hose clock-
wise as far as possible.
Emergency repair method
1
2
3
10
4

6197-2. Steps to take in an emergency
PRIUS_OM_OM47E09U_(U)
7
When trouble arises
Make sure that the compressor
switch is off.
Lift the rubber stopper on the
compressor.
Remove the power plug from
the compressor.5
6
7

6207-2. Steps to take in an emergency
PRIUS_OM_OM47E09U_(U)
Connect the power plug to the
power outlet socket. (P. 474)
Connect the bottle to the com-
pressor.
As shown in the illustration, insert
the bottle securely into the com-
pressor until the upper side of the
mark on the bottle is aligned with
the upper end of the notch.
Attach the sticker provided with
the tire puncture repair kit to a
position easily seen from the
driver’s seat.
8
9
10
