TOYOTA PRIUS C 2014 NHP10 / 1.G Owners Manual

558
What to do if...
What to do if...
A tire puncturesP. 463If you have a flat tire
The hybrid system does not start
P. 475If the hybrid system will not start
P. 1 1 0Immobilizer system
P. 481If the vehicle 12-volt battery is dis-
charged
The shift lever cannot be
moved outP. 477If the shift lever cannot be shifted
from P
The engine coolant temperature
warning light flashes or comes on
Steam can be seen coming
from under the hood
P. 487If your vehicle overheats
The key is lostP. 478If you lose your keys
The 12-volt battery runs outP. 481If the vehicle 12-volt battery is dis-
charged
The doors cannot be lockedP. 6 5Side doors
P. 7 1Back door
The vehicle is stuck in
mud or sandP. 492If the vehicle becomes stuck
A warning light or indicator light
comes onP. 437If a warning light turns on or a
warning buzzer sounds

559
What to do if...
■
Warning lights
P. 438
or
P. 4 3 7P. 438
P. 4 3 8P. 438
orP. 439
P. 4 3 8
P. 439
P. 4 3 8
P. 439
orP. 439
P. 4 3 8
*: Slip indicator comes on.
Brake system warning
light
(red indicator)Electric power steering system
warning light
Slip indicator light*
Charging system warning
lightBrake system warning light
(yellow indicator)
Malfunction indicator
lampLow fuel level warning
light
Driver’s and front pas-
senger’s seat belt
reminder light
SRS warning light
Master warning light
ABS warning light
Tire pressure warning
light

560
GAS STATION INFORMATION
Fuel filler door openerP. 105Tire inflation pressureP. 504Hood lock release lever P. 364
Auxiliary catch leverP. 364Fuel filler doorP. 1 0 5
Fuel tank capacity
(Reference) 9.5 gal. (36 L, 7.9 Imp. gal.)
Fuel type
Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher
Cold tire inflation
pressure
P. 5 0 4
Engine oil capacity
(Drain and refill
 reference)qt. (L, Imp. qt.)
With filter 3.9 (3.7, 3.3)
Without filter 3.6 (3.4, 3.0)
Engine oil type Toyota Genuine Motor Oil or equivalent
Oil grade: P. 499
ILSAC GF-5 multigrade engine oil
Recommended oil viscosity: SAE 0W-20
