4-1. Before drivingDriving the vehicle ............. 166
Cargo and luggage............ 175
Vehicle load limits ............. 179
Trailer towing..................... 180
Dinghy towing.................... 181
4-2. Driving procedures Engine (ignition) switch ..... 182
Power (ignition) switch ...... 186
EV drive mode................... 193
Hybrid transmission........... 196
Turn signal lever................ 199
Parking brake .................... 200
4-3. Operating the lights and wipers
Headlight switch ................ 201
Fog light switch ................. 205
Windshield wipers and washer ............................ 207
Rear window wiper and washer ............................ 211
4-4. Refueling Opening the fuel tank cap .................................. 214 4-5. Using the driving
support systems
Cruise control .................... 218
Rear view monitor system ............................. 222
Driving assist systems ....... 232
4-6. Driving tips Hybrid vehicle driving tips ................................... 238
Winter driving tips .............. 241
5-1. Using the audio system Audio system types ........... 246
5-2. Basic Operations (Multimedia system)
Multimedia system ............. 247
Steering wheel audio switches........................... 249
USB port/AUX port ............ 250
Basic audio operations ...... 252
5-3. Setup (Multimedia system)
Setup menu ....................... 254
General settings ................ 255
Audio settings .................... 257
Display settings ................. 258
Voice settings .................... 259
5-4. Using the Multimedia system
Selecting the audio source.............................. 260
List screen operation ......... 261
Optimal use of the multimedia system..... 263
4Driving
5Audio system
Page 5 of 552
5
1
9 8 6 5
4
3
2
PRIUS c_U (OM52E68U)
10
7
6-1. Using the air conditioning system and defogger
Automatic air conditioning system............................. 340
Seat heaters ...................... 348
6-2. Using the interior lights Interior lights list ................ 349
• Interior lights ................. 350
• Personal lights .............. 350
6-3. Using the storage features
List of storage features...... 352
• Glove box...................... 353
• Console box .................. 353
• Auxiliary boxes.............. 354
• Cup holders .................. 355
• Bottle holders ................ 356
6-4. Other interior features Other interior features ....... 357
• Sun visors ..................... 357
• Vanity mirrors................ 357
• Outside temperature display........................... 357
• Power outlet .................. 359
• Coat hooks.................... 360
• Assist grips ................... 361
• Luggage cover .............. 362 7-1. Maintenance and care
Cleaning and protecting the vehicle exterior .......... 366
Cleaning and protecting the vehicle interior ........... 369
7-2. Maintenance Maintenance requirements ................... 372
General maintenance ........ 375
Emission inspection and maintenance (I/M)
programs ......................... 378
7-3. Do-it-yourself maintenance
Do-it-yourself service precautions ...................... 379
Hood .................................. 382
Positioning a floor jack....... 384
Engine compartment ......... 385
12-volt battery .................... 394
Tires................................... 398
Tire inflation pressure ........ 406
Wheels............................... 409
Air conditioning filter .......... 411
Wireless remote control/ electronic key battery ...... 413
Checking and replacing fuses ................................ 416
Light bulbs ......................... 420
6Interior features7Maintenance and care
Page 9 of 552
9
PRIUS c_U (OM52E68U)The installation of a mobile two-way radi
o system in your vehicle could affect
electronic systems such as:
● Multiport fuel injection system/sequential multiport fuel injection system
● Cruise control system
● Anti-lock brake system
● SRS airbag system
● Seat belt pretensioner system
Be sure to check with your Toyota dealer for precautionary measures or spe-
cial instructions regarding installation of a mobile two-way radio system.
High voltage parts and cables on the hybrid vehicles emit approximately the
same amount of electromagnetic waves as the conventional gasoline pow-
ered vehicles or home electronic appliances despite of their electromagnetic
shielding.
Unwanted noise may occur in the reception of the mobile two-way radio.
Your Toyota is equipped with several sophisticated computers that will record
certain data, such as:
• Engine speed
• Electric motor speed (traction motor speed)
• Accelerator status
• Brake status
• Vehicle speed
• Shift position
• Hybrid battery (traction battery) status
The recorded data varies according to the vehicle grade level and options
with which it is equipped. Furthermore, these computers do not record con-
versations, sounds or pictures.
●Data usage
Toyota may use the data recorded in these computers to diagnose malfunc-
tions, conduct research and development, and improve quality.
Toyota will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased
• In response to an official request by the police, a court of law or a govern- ment agency
• For use by Toyota in a law suit
• For research purposes where the data is not tied to a specific vehicle or vehicle owner
Installation of a mobile two-way radio system
Vehicle data recordings
Page 15 of 552
15Pictorial index
PRIUS c_U (OM52E68U)Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 207
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 241
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 214
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 214
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 492
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 398
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . P. 497
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 241
Checking/rotation/tire pressure warning system . . . . . . . . . P. 398
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 462
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 382
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 382
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 493
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 483
Headlights/daytime running lights . . . . . . . . . . . . . . . . . . . . P. 201
Front fog lights
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 205
Front turn signal/parking lights . . . . . . . . . . . . . . . . . . . . . . P. 201
Front side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 201
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 199
Stop/tail lights/rear side marker lights . . . . . . . . . . . . . . . . . P. 201
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 196
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 201
4
5
6
7
Light bulbs of the exterior lights for driving
(Replacing method: P. 420, Watts: P. 498)
*: If equipped
8
9
10
11
12
13
14
15
Page 16 of 552
16Pictorial index
PRIUS c_U (OM52E68U)
■Instrument panel
Engine/“POWER” switch*1. . . . . . . . . . . . . . . . . . . . . . P. 182, 186
Starting the hybrid system/changing the modes . . . . . . . P. 182, 186
Emergency stop of the hybrid system . . . . . . . . . . . . . . . . . . . P. 431
When the hybrid system will not start . . . . . . . . . . . . . . . . . . . P. 473
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 449
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 196
Changing the shift position. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 196
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 433
When the shift lever does not move. . . . . . . . . . . . . . . . . . . . . P. 475
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 91
Reading the meters/adjusting the meter light . . . . . . . . . . . . . . P. 91
Warning lights/indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . P. 86
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . P. 441
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 94
When the warning messages are displayed . . . . . . . . . . . . . . P. 4491
2
3
Page 71 of 552
71
1
For safety and security
PRIUS c_U (OM52E68U)
1-2. Hybrid system
The illustration is an example for explanation and may differ from the
actual item.Gasoline engine
Electric motor (Traction motor)
Hybrid system features
Your vehicle is a hybrid vehicle. It has characteristics different
from conventional vehicles. Be sure you are closely familiar with
the characteristics of your vehicle, and operate it with care.
The hybrid system combines the use of a gasoline engine and
an electric motor (traction motor) according to driving condi-
tions, improving fuel efficiency and reducing exhaust emis-
sions.
1
2
Page 72 of 552
721-2. Hybrid system
PRIUS c_U (OM52E68U)
◆When stopped/during start off
The gasoline engine stops* when the vehicle is stopped. During
start-off, the electric motor (traction motor) drives the vehicle. At
slow speeds or when traveling down a gentle slope, the engine is
stopped* and the motor is used.
When the shift lever is in N, the hybrid battery (traction battery) is
not being charged.
*When the hybrid battery (traction battery) requires charging or the engine
is warming up, etc., the gasoline engine will not automatically stop.
( P. 73)
◆During normal driving
The gasoline engine is predominantly used. The electric motor
(traction motor) charges the hybrid battery as necessary.
◆When accelerating sharply
The power of the hybrid battery (traction battery) is added to that of
the gasoline engine via the electric motor (traction motor).
◆When braking (regenerative braking)
The wheels operate the electric motor (traction motor) as a power
generator, and the hybrid battery (traction battery) is charged.
When the gasoline engine is off while driving, a sound is produced to
warn pedestrians, people riding bicycles or other people and vehicles
in the surrounding area that the vehicle is approaching. The pitch of
the sound adjusts according to vehicle speed. When vehicle speed is
approximately 16 mph (25 km/h) or more, the warning system turns
off.
Vehicle Proximity Notification System
Page 73 of 552
731-2. Hybrid system
1
For safety and security
PRIUS c_U (OM52E68U)
■Regenerative braking
In the following situations, kinetic energy is converted to electric energy and
deceleration force can be obtained in c onjunction with the recharging of the
hybrid battery (traction battery).
● The accelerator pedal is released with the shift lever in D or B.
● The brake pedal is depressed with the shift lever in D or B.
■ EV drive indicator lamp
■ Conditions in which the gasoline engine may not stop
The gasoline engine starts and stops automatically. However, it may not stop
automatically in the following conditions:
●During gasoline engine warm-up
● During hybrid battery (traction battery) charging
● When the temperature of the hybrid battery (traction battery) is high or low
● When the heater is switched on
The EV drive indicator lamp comes on
when the vehicle is driven using only the
electric motor (traction motor) or the gas-
oline engine is stopped.
Displayed when “ECO Score” or the
basic display of “ECO Savings” is
selected. (
P. 98)
Page 74 of 552
741-2. Hybrid system
PRIUS c_U (OM52E68U)■
Charging the hybrid ba ttery (traction battery)
As the gasoline engine charges the hybrid battery (traction battery), the bat-
tery does not need to be charged from an outside source. However, if the
vehicle is left parked for a long time the hybrid battery (traction battery) will
slowly discharge. For this reason, be sure to drive the vehicle at least once
every few months for at least 30 minutes or 10 miles (16 km). If the hybrid
battery (traction battery) becomes fully discharged and you are unable to start
the hybrid system, contact your Toyota dealer.
■ Charging the 12-volt battery
P. 480
■ After the 12-volt battery has dischar ged or when the terminal has been
removed and installed during exchange, etc.
The gasoline engine may not stop even if the vehicle is being driven by the
hybrid battery (traction battery). If this continues for a few days, contact your
Toyota dealer.
Page 75 of 552
751-2. Hybrid system
1
For safety and security
PRIUS c_U (OM52E68U)■
Sounds and vibrations specific to a hybrid vehicle
There may be no engine sound or vibration even though the vehicle is able to
move with the “READY” indicator is illuminated. For safety, apply the parking
brake and make sure to shift the shift lever to P when parked.
The following sounds or vibrations may occur when the hybrid system is
operating and are not a malfunction:
●Motor sounds may be heard from the engine compartment.
● Sounds may be heard from the hybrid battery (traction battery) under the
rear seats when the hybrid system starts or stops.
● Relay operating sounds such as a snap or soft clank will be emitted from the
hybrid battery (traction battery), under the rear seats, when the hybrid sys-
tem is started or stopped.
● Sounds from the hybrid system may be heard when the back door is open.
● Sounds may be heard from the transmission when the gasoline engine
starts or stops, when driving at low speeds, or during idling.
● Engine sounds may be heard when accelerating sharply.
● Sounds may be heard due to regenerative braking when the brake pedal is
depressed or as the accelerator pedal is released.
● Vibration may be felt when the gasoline engine starts or stops.
● Cooling fan sounds may be heard from the air intake vent on the side of the
lower part of the rear left seat.
■ Vehicle Proximity Notification System
In the following cases, the Vehicle Proximity Notification System sound may
be difficult for pedestrians, people riding bicycles or other people and vehicles
in the surrounding area to hear:
● When there is a lot of noise in the vicinity
● When it is raining or during strong winds
● When in the area surrounding the rear of the vehicle, rather than in front of
the vehicle
■ Maintenance, repair, recycling, and disposal
Contact your Toyota dealer regarding maintenance, repair, recycling and dis-
posal. Do not dispose of the vehicle yourself.
■ Customization that can be configured at Toyota dealer
Settings (e. g. the volume of Vehicle Proximity Notification System sound)
can be changed. (Customizable features: P. 514)
