982. Instrument cluster
PRIUS c_U (OM52J11U)
The following items are always displayed in the upper part of the
screen. (When using some menu items, these items will not be dis-
played.)
Odometer/trip meter
→P. 9 9
Average fuel consumption
Depending on whether the
odometer or trip meter is dis-
played, the displayed contents
differ. Use the displayed aver-
age fuel consumption as a ref-
erence.
● When the odometer is displayed: the average fuel consumption
since the hybrid system wa s started is displayed.
● When the trip meter is displayed: the average fuel consumption
since the trip meter was reset is displayed. The average fuel con-
sumption for trip mete r A and trip meter B is displayed separately.
When the trip meter is reset, average fuel consumption is also reset.
(→P. 99)
Clock
Change the time on the settings screen. ( →P. 105)
Items displayed in the upper part of the screen
1
2
3
Page 99 of 596
992. Instrument cluster
2
Instrument cluster
PRIUS c_U (OM52J11U)■
Odometer/trip meter
