5328-2. Steps to take in an emergency
PRIUS c_U
WARNING
■To prevent an accident or injury when inspecting under the hood of
your vehicle
● If steam is seen coming from under the hood, do not open the ho od until
the steam has subsided. The engine compartment may be very hot, caus-
ing serious injuries such as burns.
● After the hybrid system has been turned off, check that on the multi-
information display and the “READY” indicator are off.
When the hybrid system is operating, the gasoline engine may au tomati-
cally start, or the cooling fan may suddenly operate even if th e gasoline
engine stops. Do not touch or approach rotating parts such as t he fan,
which may lead to fingers or clothing (especially a tie, a scarf or a muffler)
getting caught, resulting in serious injury.
● Do not loosen the radiator cap while the hybrid system and radi ator are
hot.
Serious injuries, such as burns, may result from hot coolant an d steam
released under pressure.
NOTICE
■ When adding engine/power control unit coolant
Wait until the hybrid system has cooled down before adding engine/power
control unit coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot hybrid sys-
tem too quickly can cause damage to the hybrid system.
■ To prevent damage to the cooling system
Observe the following precautions:
● Avoid contaminating the coolant with foreign matter (such as sa nd or dust
etc.).
● Do not use any coolant additive.

5338-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_U
Shift the shift lever to P and set the parking brake. Stop the hybrid
system.
Remove the mud, snow or sand from around the stuck tire.
Place wood, stones or some other material under the tires to help
provide traction.
Restart the hybrid system.
Shift the shift lever to the D or R position and carefully appl y the
accelerator to free the vehicle.
■ When it is difficult to free the vehicle
If the vehicle becomes stuck
Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Press to turn off TRAC.
WARNING
■When attempting to f ree a stuck vehicle
If you choose to push the vehicle back and forth to free it, ma ke sure the
surrounding area is clear to avoid striking other vehicles, obj ects or people.
The vehicle may also lunge forward or lunge back suddenly as it becomes
free. Use extreme caution.
■ When shifting the shift lever
Be careful not to shift the shift lever with the accelerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle t hat may
cause an accident resulting in death or serious injury.
1
2
3
4
5

590Alphabetical index
PRIUS c_U
Eco drive mode ........................ 203
Electric power steering ........... 265
Electronic keyIf the electronic key does not operate properly ........... 520
Emergency flashers Switch ................................... 468
Emergency, in case of
If a warning buzzer sounds ........................ 480, 488
If a warning light
turns on .............................. 480
If a warning message is displayed ............................ 488
If the electronic key does not operate properly ........... 520
If the hybrid system will
not start .............................. 518
If the vehicle becomes stuck ................................... 533
If the vehicle 12-volt battery is discharged .......... 522
If the vehicle is trapped
in rising water ..................... 471
If you have a flat tire ............ 505
If you lose your keys ............. 122
If you think something is wrong.................................. 479
If your vehicle has to be stopped in an
emergency.......................... 469
If your vehicle needs to be towed ............................. 472
If your vehicle overheats ....... 529 Engine
Compartment ........................ 422
Hood ..................................... 419
How to start the hybrid system ....... ................. 188, 192
Identification number ............ 537
If the hybrid system will not start .............................. 518
Ignition switch ............... 188, 192
Overheating .......................... 529
Power switch ................ 188, 192
Engine coolant Capacity................................ 540
Checking............................... 426
Preparing and checking before winter ...................... 274
Engine oil
Capacity................................ 539
Checking............................... 423
Preparing and checking before winter ...................... 274
Engine/power control unit coolant
Capacity................................ 540
Checking............................... 426
Preparing and checking before winter ...................... 274
EPS ........................................... 265
EV drive mode ......................... 199
Event data recorder................... 11
Exclusive jump starting terminal .................... 522
