fuel type TOYOTA PRIUS C 2020 Owners Manual

17Pictorial index
PRIUS c_UWindshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 214
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 274
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 221
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 221
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 538
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . P. 435
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . P. 543
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 274
Checking/rotation/tire pressur e warning system . . . . . . . . .P. 435
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 505
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 419
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 419
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 539
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 529
Headlights/daytime running lights . . . . . . . . . . . . . . . . . . . . P. 208
Parking lights/front turn signal lights . . . . . . . . . . . . . P. 206, 208
Side turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 206
Front fog lights
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 212
Front side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 208
Stop lights/tail lights /rear side marker lights/
rear turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . P. 206, 208
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 208
4
5
6
7
Light bulbs of the exterior lights for driving
(Replacing method: P. 458, Watts: P. 544)
*: If equipped
8
9
10
11
12
13
14
15

2104-3. Operating the lights and wipers
PRIUS c_U
■Daytime running light system
●The daytime running lights illuminate using the same lights as the headlights
and illuminate darker than the headlights.
● Type A: To make your vehicle more visible to other drivers during daytime
driving, the daytime running lights turn on automatically when all of the fol-
lowing conditions are met. (The daytime running lights are not designed for
use at night.)
• The hybrid system is started
• The parking brake is released
• The headlight switch is in the or position
The daytime running lights remain on after they illuminate, even if the parking
brake is set again.
● Type B: To make your vehicle more visible to other drivers during daytime
driving, the daytime running lights turn on automatically when all of the fol-
lowing conditions are met. (The daytime running lights are not designed for
use at night.)
• The hybrid system is started
• The parking brake is released
• The headlight switch is in the or position
The daytime running lights remain on after they illuminate, even if the parking
brake is set again.
● For the U.S.A.: Daytime running lights can be turned off by ope rating the
switch.
● Compared to turning on the headlights, the daytime running ligh t system
offers greater durability and consumes less electricity, so it can help improve
fuel economy.
■ Automatic light off system
Vehicles without a smart key system
● When the headlights are on: The headlights and tail lights turn off 30 sec-
onds after the power switch is turned to the “ACC” or “LOCK” po sition and a
door is opened and closed. (Vehicles with a wireless remote con trol: The
lights turn off immediately if on the key is pressed after all the doors
are locked.)
● When only the tail lights are on: The tail lights turn off automatically if the
power switch is turned to the “ACC” or “LOCK” position and the driver’s door
is opened.
To turn the lights on again, turn the power switch to “ON” posi tion, or turn the
light switch off once and then back to or .
If any of the doors or trunk lid is kept open, the lights automatically turn off
after 20 minutes.

221
4
Driving
PRIUS c_U
4-4. Refueling
●Vehicles without a smart key system:
Turn the power switch to the “LOCK” poison and ensure that all the
doors and windows are closed.
Vehicles with a smart key system:
Turn the power switch off and ensure that all the doors and win -
dows are closed.
● Confirm the type of fuel.
■Fuel types
P. 545
■ Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your vehicle has a fuel tank opening that
only accommodates the special nozzle on unleaded fuel pumps.
■ If the malfunction indicator lamp illuminates
The malfunction indicator lamp may illuminate erroneously if re fueling is per-
formed repeatedly when the fuel tank is nearly full.
Opening the fuel tank cap
Perform the following steps to open the fuel tank cap:
Before refueling the vehicle

4067-1. Maintenance and care
PRIUS c_U
Start the hybrid system and check that “MAINTENANCE
REQUIRED FOR TRACTION BATTERY COOLING PARTS SEE
OWNER’S MANUAL” is no longer displayed on the multi-infor-
mation display.
It may take approximately 20 minu tes for the warning message to
disappear after the hybrid syste m is started. If the warning mes-
sage does not disappear even th ough the filter has been cleaned,
have the vehicle inspect ed by your Toyota dealer.
■Caring for leather areas
Toyota recommends cleaning the interior of the vehicle at least twice a year to
maintain the quality of the vehicle's interior.
■ Shampooing the carpets
There are several commercial foaming-type cleaners available. U se a sponge
or brush to apply the foam. Rub in overlapping circles. Do not use water.
Wipe dirty surfaces and let them dry. Excellent results are obt ained by keep-
ing the carpet as dry as possible.
■ Air intake vent maintenance
●If the vehicle is driven with the air intake vent clogged, the hybrid battery
(traction battery) may overheat and the fuel consumption may in crease.
● Depending on the conditions under which the vehicle is used, th e air intake
vent may need to be cleaned more regularly.
■ Seat belts
Clean with mild soap and lukewarm water using a cloth or sponge . Also
check the belts periodically for excessive wear, fraying or cut s.
■ Cleaning the air intake vent filter
●Improper handling of the air intake vent cover and filter may result in dam-
age to them. If you have any concerns about cleaning the filter , contact your
Toyota dealer.
● If the vehicle is driven with the air intake vent filter clogged, the hybrid bat-
tery (traction battery) may overheat and the fuel consumption m ay increase.
● Depending on the conditions under which the vehicle is used, th e air intake
vent filter may need to be cleaned more regularly.
6

5188-2. Steps to take in an emergency
PRIUS c_U
One of the following may be the cause of the problem:
● Vehicles with a smart key system: The electronic key may not be
functioning properly. ( P. 520)
● There may not be sufficient f uel in the vehicle’s tank.
Refuel the vehicle. ( P. 221)
● Vehicles with immobilizer syste m: There may be a malfunction in
the immobilizer system. ( P. 8 8 )
● There may be a malfunction i n the steering lock system.
● Vehicles with a smart key system : The hybrid system may be mal-
functioning due to an electrical problem such as an open circui t or a
blown fuse. However, depending on the type of malfunction, an
interim measure is available to start the hybrid system. (P. 519)
One of the following may be the cause of the problem:
● The 12-volt battery may be discharged. ( P. 522)
● The 12-volt battery terminal conn ections may be loose or corroded.
(  P. 431)
If the hybrid system will not start
Reasons for the hybrid system not starting vary depending on
the situation. Check the followi ng and perform the appropriate
procedure:
The hybrid system will not start even though the correct starting
procedure is being followed. ( P. 188, 192)
The interior lights and headlights are dim, or the horn does no t
sound or sounds at a low volume.

5389-1. Specifications
PRIUS c_U■
Engine number
The engine number is stamped
on the engine block as shown.
Engine
Model
1NZ-FXE
Type4-cylinder in line, 4-cycle, gasoline
Bore and stroke 2.95  3.33 in. (75.0  84.7 mm)
Displacement 91.3 cu. in. (1496 cm3)
Valve clearance
(engine cold)Intake: 0.006  0.010 in. (0.15  0.25 mm)
Exhaust: 0.010
 0.014 in. (0.25  0.35 mm)
Fuel
Fuel type Unleaded gasoline only
Octane rating 87 (Research octane number 91) or higher
Fuel tank capacity
(Reference)9.5 gal. (36 L, 7.9 Imp. gal.)
Electric motor (traction motor)
Type
Permanent magnet synchronous motor
Maximum output 45 kW
Maximum torque 125 ft•lbf (169 N•m, 17.2 kgf•m)

5399-1. Specifications
9
Vehicle specifications
PRIUS c_U
*: The engine oil capacity is a reference quantity to be used when changing
the engine oil. Warm up the engine and turn off the hybrid system, wait
more than 5 minutes, and check the oil level on the dipstick.
■
Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat isfy
the following grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice
for good fuel economy and
good starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.
Hybrid battery (traction battery)
Type Nickel-metal hydride battery
Voltage7.2 V/module
Capacity 6.5 Ah (3HR)
Quantity20 modules
Nominal voltage 144 V
Lubrication system
Oil capacity (Drain and
refill reference
*)
With filter
Without filter 3.9 qt. (3.7 L, 3.3 Imp. qt.)
3.6 qt. (3.4 L, 3.0 Imp. qt.)
Outside temperature

5479-1. Specifications
9
Vehicle specifications
PRIUS c_U
NOTICE
■Notice on fuel quality
● Do not use improper fuels. If improper fuels are used, the engi ne will be
damaged.
● Do not use leaded gasoline.
Leaded gasoline can cause damage to your vehicle’s three-way ca talytic
converters causing the emission control system to malfunction.
● Do not use gasohol other than the type previously stated.
Other gasohol may cause fuel system damage or vehicle performan ce
problems.
● Using unleaded gasoline with an octane number or rating lower than the
level previously stated will cause persistent heavy knocking.
At worst, this will lead to engine damage.
■ Fuel-related poor driveability
If poor driveability (poor hot starting, vaporization, engine k nocking, etc.) is
encountered after using a different type of fuel, discontinue the use of that
type of fuel.
■ When refueling with gasohol
Take care not to spill gasohol. It can damage your vehicle's paint.

591Alphabetical index
PRIUS c_U
Floor mat .................................... 26
FluidBrake .................................... 542
Washer ................................. 430
Fog lights
Replacing light bulbs............. 464
Switch ................................... 212
Front fog lights
Replacing light bulbs............. 464
Switch ................................... 212
Front passenger occupant
classification system .............. 52
Front passenger’s seat belt reminder light ................. 482
Front seats Adjustment ............................ 150
Front sensor............................. 226
Automatic High Beam ........... 226
LDA (Lane Departure Alert)........ 226
PCS (Pre-Collision System)........ 226
Precautions ........................... 227 Front side marker lights
Replacing light bulbs ............ 465
Switch ................................... 208
Wattage ................................ 544
Front turn signal lights
Replacing light bulbs ............ 460
Switch ................................... 206
Wattage ................................ 544
Fuel Capacity................................ 538
Fuel gauge.............................. 99
Information............................ 545
Refueling .............................. 221
Type...................................... 538
Fuel door .................................. 221
Fuel filler door ......................... 221
Fuses ........................................ 454
F

600
PRIUS c_U
GAS STATION INFORMATION
Auxiliary catch leverFuel filler door
P. 419 P. 221
Hood lock release
leverFuel filler
door openerTire inflation pressure
P. 419 P. 221P. 543
Fuel tank capacity
(Reference)9.5 gal. (36 L, 7.9 Imp. gal.)
Fuel type
P. 538
Cold tire inflation
pressureP. 5 4 3
Engine oil capacity
(Drain and refill —
reference) P. 539
Engine oil type
“Toyota Genuine Motor Oil” or equivalent
P. 539
