17Pictorial index
PRIUS c_UWindshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 214
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 274
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 221
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 221
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 538
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . P. 435
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . P. 543
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 274
Checking/rotation/tire pressur e warning system . . . . . . . . .P. 435
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 505
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 419
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 419
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 539
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 529
Headlights/daytime running lights . . . . . . . . . . . . . . . . . . . . P. 208
Parking lights/front turn signal lights . . . . . . . . . . . . . P. 206, 208
Side turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 206
Front fog lights
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 212
Front side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 208
Stop lights/tail lights /rear side marker lights/
rear turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . P. 206, 208
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 208
4
5
6
7
Light bulbs of the exterior lights for driving
(Replacing method: P. 458, Watts: P. 544)
*: If equipped
8
9
10
11
12
13
14
15

2064-2. Driving procedures
PRIUS c_U
Right turn
Lane change to the right (push
and hold the lever partway)
The right hand signals will flash
until you release the lever.
Lane change to the left (push
and hold the lever partway)
The left hand signals will flash until
you release the lever.
Left turn
■Turn signals can be operated when
Vehicles without a smart key system
The power switch is in the “ON” position.
Vehicles with a smart key system
The power switch is in ON mode.
■ If the indicator flashes faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned
out.
Turn signal lever
Operating instructions
1
2
3
4

4597-3. Do-it-yourself maintenance
7
Maintenance and care
PRIUS c_U■
Front
Front turn signal light/parking light
■Rear
Bulb locations
1
Rear turn signal light
Back-up light License plate lights1
2
3

4607-3. Do-it-yourself maintenance
PRIUS c_U■
Front turn signal li
ghts/parking lights
Turn the bulb base counter-
clockwise.
Remove the light bulb.
When installing, reverse the steps listed.
Replacing light bulbs
1
2
3

4617-3. Do-it-yourself maintenance
7
Maintenance and care
PRIUS c_U■
Rear turn signal light
s and back-up lights
Open the back door and
remove the bolts. Pull the
lamp assembly straight back
to disengage the clip and 2
pins. Guide (where the clip
attaches)
Pin
Turn the bulb base counter-
clockwise. Rear turn signal light
Back-up light
Remove the light bulb. Rear turn signal light
Back-up light
1
1
2
2
1
2
3
1
2

4657-3. Do-it-yourself maintenance
7
Maintenance and care
PRIUS c_U
■LED light bulbs
The headlights/daytime running lights, front fog lights (if equipped), side
marker lights, side turn signal lights, stop/tail lights and hi gh mounted stop-
light consist of a number of LEDs. If any of the LEDs burn out, take your vehi-
cle to your Toyota dealer to have the light replaced.
■ Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the headlight lens does not
indicate a malfunction. Contact your Toyota dealer for more information in the
following situations:
● Large drops of water have built up on the inside of the lens.
● Water has built up inside the headlight.
WARNING
■Replacing light bulbs
● Turn off the lights. Do not attempt to replace the bulb immedia tely after
turning off the lights.
The bulbs become very hot and may cause burns.
● Do not touch the glass portion of the light bulb with bare hands. When it is
unavoidable to hold the glass portion, use and hold with a clea n dry cloth
to avoid getting moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.
● Fully install light bulbs and any parts used to secure them. Fa ilure to do so
may result in heat damage, fire, or water entering the headligh t unit. This
may damage the headlights or cause condensation to build up on the lens.
■ To prevent damage or fire
Make sure bulbs are fully seated and locked.

5449-1. Specifications
PRIUS c_U
*: If equipped
Light bulbs
Light bulbsBulb No.WTy p e
ExteriorFront turn signal lights/
parking lights

28/8 B
License plate lights 5A
Back-up lights 16 A
Rear turn signal lights 21 B
InteriorInterior lights/personal
lights

5A
Luggage compartment
light
* 5A
A: Wedge base bulbs (clear) B: Wedge base bulbs (amber)

591Alphabetical index
PRIUS c_U
Floor mat .................................... 26
FluidBrake .................................... 542
Washer ................................. 430
Fog lights
Replacing light bulbs............. 464
Switch ................................... 212
Front fog lights
Replacing light bulbs............. 464
Switch ................................... 212
Front passenger occupant
classification system .............. 52
Front passenger’s seat belt reminder light ................. 482
Front seats Adjustment ............................ 150
Front sensor............................. 226
Automatic High Beam ........... 226
LDA (Lane Departure Alert)........ 226
PCS (Pre-Collision System)........ 226
Precautions ........................... 227 Front side marker lights
Replacing light bulbs ............ 465
Switch ................................... 208
Wattage ................................ 544
Front turn signal lights
Replacing light bulbs ............ 460
Switch ................................... 206
Wattage ................................ 544
Fuel Capacity................................ 538
Fuel gauge.............................. 99
Information............................ 545
Refueling .............................. 221
Type...................................... 538
Fuel door .................................. 221
Fuel filler door ......................... 221
Fuses ........................................ 454
F

593Alphabetical index
PRIUS c_U
Keyless entry ................... 127, 136
KeysElectronic key ....................... 120
If the electronic key does not operate properly ........... 520
If you lose your keys ............. 122
Ignition switch ............... 188, 192
Key battery............................ 451
Key number .......................... 120
Keyless entry ........................ 121
Keys ...................................... 120
Mechanical key ..................... 121
Power switch................. 188, 192
Wireless remote control key ...................................... 121
Knee airbag ................................ 39 Lane Departure Alert (LDA) .... 241
Language (multi-information
display) .................................. 108
LDA (Lane Departure Alert) .... 241
License plate lights Replacing light bulbs ............ 463
Wattage ................................ 544
Light bulbs
Replacing.............................. 458
Wattage ................................ 544
Lights
Automatic High Beam system .......... ...................... 246
Emergency flasher switch..... 468
Fog light switch ..................... 212
Hazard light switch ............... 468
Headlight switch ................... 208
Instrument panel light
switch ................................. 208
Interior lights switch .............. 386
Parking light switch ............... 208
Personal light switch ............. 386
Replacing light bulbs ............ 458
Side marker light switch........ 208
Tail light switch ..................... 208
Turn signal lever ................... 206
Wattage ................................ 544
Load capacity .......................... 185
Lock steering column ..... 190, 195
Luggage compartment light Wattage ................................ 544
Luggage cover ......................... 397
KL

595Alphabetical index
PRIUS c_U
Radiator .................................... 428
Radio......................................... 298
Rear seatFolding down ........................ 151
Rear turn signal lights
Replacing light bulbs............. 461
Wattage ................................ 544
Rear view monitor
system
*.................................. 255
Rear window defogger ............ 378
Rear window wiper .................. 218
Resetting the message indicating maintenance
is required .............................. 410
Replacing Fuses .................................... 454
Key battery............................ 451
Light bulbs ............................ 458
Tires ...................................... 505
Reporting safety defects
for U.S. owners ...................... 568 Seat belts
Adjusting the seat belt ............ 30
Automatic Locking
Retractor (ALR) .................... 34
Child restra int system
installation ............................ 59
Cleaning and maintaining the seat belts ...................... 406
Emergency Locking Retractor (ELR) ................... 34
How to wear your seat belt ..... 28
How your child should
wear the seat belt ................. 34
Pregnant women,
proper seat belt use ............. 36
Reminder light ...................... 482
Seat belt extenders................. 35
Seat belt pretensioners........... 34
Seat cushion airbag .................. 39
Seat heaters ............................. 384
Seating capacity ...................... 185
RS
*: For vehicles with a navigation system, refer to the “NAVIGATION SYSTEM OWNER'S MANUAL”.
