TOYOTA PRIUS PLUG-IN 2014 Owners Manual

685
What to do if...
PRIUS PHV_OM_OM47856U_(U)
■Warning lights
P. 5 4 0
or
P. 5 3 7
or
P. 5 3 5P. 5 3 7
P. 5 3 6P. 5 3 8
P. 5 3 6P. 5 3 8
P. 5 3 8
or
P. 5 3 7P. 5 3 8
P. 5 3 7P. 5 3 8
Master warning light ABS warning light
Brake system warning
light (red indicator)
Electric power steering
system warning light
Charging system
warning light
Pre-collision system
warning light*
High coolant
temperature warning
light
Slip indicator light
Brake system warning
light (yellow indicator)Malfunction indicator
lamp
Automatic headlight
leveling system
warning light
SRS warning lightCruise control indicator
light*

686
What to do if...
PRIUS PHV_OM_OM47856U_(U)
P. 5 3 8P. 5 3 9
P. 5 3 9P. 5 4 0
P. 5 3 9
P. 5 3 9
*: The light flashes to indicate a malfunction.
Radar cruise control
indicator light*
Driver’s belt reminder
light
Open door warning lightTire pressure warning
light
Low fuel level warning
light
Front passenger’s seat
belt reminder light

687
What to do if...
PRIUS PHV_OM_OM47856U_(U)

688
PRIUS PHV_OM_OM47856U_(U)
GAS STATION INFORMATION
Fuel filler door
P. 1 7 8
Auxiliary catch lever
P. 4 4 5
Fuel filler door opener
P. 1 7 8
Tire inflation pressure
P. 6 2 3
Hood lock release lever
P. 4 4 5
Fuel tank capacity
(Reference)10.6 gal. (40 L, 8.8 Imp.gal.)
Fuel type Unleaded gasoline only P. 617
Cold tire inflation
pressureP. 6 2 3
Engine oil capacity(Drain and refill ⎯
reference)
qt. (L, Imp.qt.)With filter 4.4 (4.2, 3.7)
Without filter 4.1 (3.9, 3.4)
Engine oil typeTo y o t a G e n u i n e M o t o r O i l o r e q u i v a l e n tOil grade: ILSAC GF-5 multigrade engine oil
P. 6 1 8
