TOYOTA PRIUS PLUG-IN HYBRID 2014 1.G Owners Manual

641
6-1. Specifications
6
Vehicle specifications
PRIUS PHV_OM_OM47856U_(U)
Tire related termMeaning
Section width The linear distance between the exteriors of
the sidewalls of an inflated tire, excluding ele-
vations due to labeling, decoration, or protec-
tive bands
Sidewall That portion of a tire between the tread and
bead
Sidewall separation The parting of the rubber compound from the
cord material in the sidewall
Snow tire A tire that attains a traction index equal to or
greater than 110, compared to the ASTM E-
1136 Standard Reference Test Tire, when
using the snow traction test as described in
ASTM F-1805-00, Standard Test Method for
Single Wheel Driving Traction in a Straight Line
on Snow-and Ice-Covered Surfaces, and which
is marked with an Alpine Symbol ( ) on at
least one sidewall
Te s t r i m The rim on which a tire is fitted for testing, and
may be any rim listed as appropriate for use
with that tire
Tread That portion of a tire that comes into contact
with the road
Tread rib A tread section running circumferentially
around a tire

642 6-1. Specifications
PRIUS PHV_OM_OM47856U_(U)
*: Table 1  Occupant loading and distri bution for vehicle normal load
for various designated seating capacities
Tire related termMeaning
Tread separation Pulling away of the tread from the tire carcass
Treadwear indicators
(TWI) The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixture The fixture used to hold the wheel and tire
assembly securely
during testing
Designated seating
capacity, Number of occupantsVehicle normal load,
Number of occupantsOccupant distribution in a normally loaded vehi- cle
2 through 4 2 2 in front
5 through 10 3 2 in front, 1 in second
seat
11 through 15 5 2 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 7 2 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

643
6
Vehicle specifications
PRIUS PHV_OM_OM47856U_(U)
6-2. Customization
Customizable features
Customizable featuresVehicles with a Display Audio system: Settings that can be
changed using the Display Audio system
(For further information on custom izing settings using the Display
Audio system, refer to the “D ISPLAY AUDIO SYSTEM OWNER’S
MANUAL”.)
Vehicles with a navigation syst em: Settings that can be changed
using the navi gation system
(For further information on cust omizing settings using the naviga-
tion system, refer to the “NAVIGATION SYSTEM OWNER’S MAN-
UAL”.)
Settings that can be chan ged by your Toyota dealer
Definition of symbols: O = Available, — = Not available
Your vehicle includes a variety of electronic features that can be per-
sonalized to suit your prefer ences. Programming these preferences
requires specialized equipment and may be performed by your
Toyota dealer.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.

644 6-2. Customization
PRIUS PHV_OM_OM47856U_(U)
ItemFunctionDefault settingCustom- ized
setting
Smart key
system
( P. 1 1 2 ) Smart key
system
ON OFF O O O
Select doors to
unlock Driver’s
door All doors O O O
Wireless
remote
control
( P. 136) Wireless remote
control
ON OFF – – O
Unlocking
operation Driver’s
door
unlocked in 1-step, all doors
unlocked in 2-step All doors
unlocked in 1-step OOO
Panic function ON OFF – – O
Buzzer sounds
when pushing with any
door not closed ON OFF – – O

645
6-2. Customization
6
Vehicle specifications
PRIUS PHV_OM_OM47856U_(U)
ItemFunctionDefault
settingCustom- ized
setting
Smart key
system
( P. 1 1 2 )
and wire-
less remote
control
( P. 136) Operation
signals
(Emergency
flashers)
ON OFF – O O
Operation
signals
(Buzzers) Level 7Level 1 to 6
OOO
OFF
Time elapsed
before
automatic door
lock function is
activated if door
is not opened
after being
unlocked 60 seconds
OFF
–OO
30
seconds
120
seconds

646 6-2. Customization
PRIUS PHV_OM_OM47856U_(U)
*: This function cannot be customized for vehicles sold in Canada.
ItemFunctionDefault set-tingCustom-ized
setting
Door lock
( P. 138,
594) Unlocking using
a key
Driver’s
door
unlocked in 1-step, all doors
unlocked in 2-step All doors
unlocked in 1-step –OO
Speed-detecting
automatic door
lock function OFF ON OOO
Shifting the shift
position to any
position other
than P locks all
doors ON OFF O O O
Shifting the shift
position to P
unlocks all doors ON OFF O O O
Opening driver’s
door unlocks all
doors OFF ON – O O
Automatic
light control
system
( P. 294) Light sensor
sensitivity
Level 3Levels 1 to
5 OOO
Time elapsed
before head-
lights automati-
cally turn off after
doors are closed 30 seconds
0 seconds
OOO
60 seconds
90 seconds
Daytime running
lights
*ON OFF O O O

647
6-2. Customization
6
Vehicle specifications
PRIUS PHV_OM_OM47856U_(U)
ItemFunctionDefault set-
tingCustom-ized
setting
Power
windows
( P. 175) The one-touch
closing operation
except for
driver’s seat
ON OFF – – O
Illumination
( P. 384) Time elapsed
before lights turn
off
15 secondsOFF
–OO
7.5
seconds
30 seconds
Operation when
the doors are
unlocked ON OFF – – O
Operation after
the “POWER”
switch turned
OFF ON OFF – – O
Operation when
you approach
the vehicle with
the electric key
on your person
(When the per-
sonal/interior
light main switch
is door position) ON OFF – – O
Foot lights ON OFF – – O
Foot lights oper-
ation when the
vehicle is run-
ning ON OFF – – O

648 6-2. Customization
PRIUS PHV_OM_OM47856U_(U)
ItemFunctionDefault set-tingCustom-ized
setting
Meter and
instrument
panel
( P. 259) Sensor sensitiv-
ity for darkening
the brightness of
the meter, navi-
gation system
and instrument
panel depend-
ing on the out-
side brightness
0 -2 to +2 – – O
Sensor sensitiv-
ity for returning
the brightness of
the meter, navi-
gation system
and instrument
panel to the orig-
inal level
depending on
the outside
brightness 0 -2 to +2 – – O
Automatic
air
conditioning
system
( P. 360) Enable/disable
automatic
operation of the
air conditioning
compressor
when the
“AUTO” switch
ON
ON OFF – O O
Heating/cooling
operation mini-
mized in Eco
drive mode ON OFF – – O

649
6-2. Customization
6
Vehicle specifications
PRIUS PHV_OM_OM47856U_(U)
ItemFunctionDefault set-
tingCustom-ized
setting
Remote Air
Condition-
ing System
( P. 373) Operation using
the
“A/C” button on
the wireless
remote control
Push and
hold for 0.8 seconds Push once
––O
Push twice
Push and
hold for 2.4 seconds
OFF
Stopping the
operation using
the “A/C” button
on the wireless
remote control Push twicePush once
––O
Push and
hold for 0.8 seconds
Push and
hold for 2.4 seconds
OFF

650 6-2. Customization
PRIUS PHV_OM_OM47856U_(U)
Multi-information display (P. 268)
ItemFunctionDefault set-
tingCustom-ized
setting
Reverse
warning
buzzer
( P. 252) Operation sig-
nals (Buzzer)
when shifting
into R
Beeps
repeatedly Beeps
once ––O
Seat belt
reminder
( P. 541) Vehicle speed
linked seat belt
reminder buzzer
ON OFF – – O
Available languagesEnglish, French and Spanish
