dimensions TOYOTA PRIUS PLUG-IN HYBRID 2014 1.G Owners Manual

614
PRIUS PHV_OM_OM47856U_(U)
6-1. Specifications
Maintenance data (fuel, oil level, etc.)
Dimensions and weight
*: Unladen vehicle
Overall length176.4 in. (4480 mm)
Overall width68.7 in. (1745 mm)
Overall height*58.7 in. (1490 mm)
Wheelbase106.3 in. (2700 mm)
TreadFront60.0 in. (1525 mm)
Rear59.8 in. (1520 mm)
Vehicle capacity weight
(Occupants + luggage) 825 lb. (370 kg)

631
6-1. Specifications
6
Vehicle specifications
PRIUS PHV_OM_OM47856U_(U)
Tire size
■ Typical tire size information
The illustration indicates typical tire size. Tire use
(P = Passenger car,
T = Temporary use)
Section width (millimeters)
Aspect ratio
(tire height to section width)
Tire construction code
(R = Radial, D = Diagonal)
Wheel diameter (inches)
Load index (2 digits or 3 digits)
Speed symbol
(alphabet with one letter)
■ Tire dimensions
Section width
Tire height
Wheel diameter

675
Alphabetical index
PRIUS PHV_OM_OM47856U_(U)
Daytime running light
system ................................... 297
Deck board............................... 405
Defogger
Rear window......................... 377
Side mirrors .......................... 377
Dimensions .............................. 614
Dinghy towing ......................... 357
Display Dynamic radar cruise control ................................ 314
Multi-information ................... 268
Warning messages............... 548
Do-it-yourself maintenance .... 442
Door lock Back door ............................. 144
Side doors ............................ 138
Smart key system ... .............. 112
Wireless remote control........ 136
Doors Back door ............................. 144
Door glasses ........................ 175
Door lock .............. 112, 136, 138
Rear door child-protector...... 139
Side doors ............................ 138
Driver’s seat belt reminder light ........................................ 539
Driving
Break-in tips ......................... 228
Correct posture..................... 185
Procedures ........................... 226
Winter driving tips ................. 351 Eco drive mode switch ............249
Electric power steering ...........330
Electronic key
If the electronic key does not operate properly..................594
Replacing battery ..................496
Emergency, in case of If a warning buzzer sounds ................................535
If a warning light turns on ......535
If the electronic key does not operate properly..................594
If the hybrid system will not start .....................................591
If the 12-volt battery is
discharged ..........................597
If you have a flat tire .............569
If you lose your keys .............593
If you think something is wrong ..................................534
If your vehicle becomes stuck ...................................608
If your vehicle has to be stopped in an
emergency ..........................610
If your vehicle needs to be towed ..................................527
If your vehicle overheats .......603
Emergency flashers Switch....................................526DE
