TOYOTA PRIUS V 2012 (in English) User Guide

11
PRIUS v_U (OM47674U)
A
Anti-glare inside rear view mirror Garage door opener switches

P. 105
P. 330
Sun visors P. 312
SRS curtain shield airbags P. 121
Interior light P. 300
Panoramic roof shades switch P. 320
Vanity mirrors P. 313
Interior light
Personal light P. 300
P. 301
: If equipped
*: Refer to “Display Audio System Owner’s Manual” or “Navigation System Owner’s Manual”.
Microphone* P. 338
“SOS” button
Auxiliary box

P. 338
P. 310

12
PRIUS v_U (OM47674U)
B
Window lock switch P. 109
Power window switches P. 109
Outside rear view mirror switches P. 107
Door lock switch P. 71
Inside lock button P. 71
Pictorial indexInterior

13
PRIUS v_U (OM47674U)
C
Cup holders P. 307
EV drive mode switch
Eco drive mode switch
Power mode switch P. 180
P. 185
P. 185
Console box P. 306

14
PRIUS v_U (OM47674U)
Pictorial indexInstrument panel
Headlight switch
Turn signal lever Fog light switch P. 211
P. 192
P. 219
Pre-collision braking off switch P. 257
Parking brake pedal P. 193
Fuel filler door opener P. 112
Tire pressure warning reset switch P. 389
Windshield wipers and washer switch
Rear window wiper and washer switch P. 221
P. 226
Gauges and meters
Trip-information display P. 195
P. 199
Audio system*2 P. 294
Navigation system*1
SRS driver airbag
Horn P. 121
P. 194
Card holder P. 311
Tilt and telescopic steering control lever P. 104
SRS knee airbag P. 121

15
PRIUS v_U (OM47674U)
A
Instrument panel light control dial P. 197
Headlight cleaner switch P. 228
Hood lock release lever P. 364
APGS pre-support switch*1
: If equipped
*1: Refer to “Navigation System Owner’s Manual”.
*2: Refer to “Display Audio System Owner’s Manual”.

16
PRIUS v_U (OM47674U)
Pictorial indexInstrument panel
B
Telephone switches*
“DISP” button P. 198Audio remote
control switches
*
Cruise control switch
Dynamic radar cruise control
switch

P. 229
P. 233
Vehicle-to-vehicle distance button P. 233
Talk switch*
“TRIP” button P. 198
Climate remote control switches P. 291

17
PRIUS v_U (OM47674U)
C
Clock adjustment buttons P. 314
MPH or km/h button P. 197
Shift lever P. 183
Emergency flasher switch P. 434
: If equipped
*: Refer to “Display Audio System Owner’s Manual” or “Navigation System Owner’s Manual”.
P position switch P. 186
Power (ignition) switch P. 173

18
PRIUS v_U (OM47674U)
AUX port/USB port*
Power outlet P. 315
Seat heater switches P. 317
Air conditioning system P. 278
Rear window and outside
rear view mirror defoggers
P. 293
Pictorial indexInstrument panel
D

19
PRIUS v_U (OM47674U)
: If equipped
*: Refer to “Display Audio System Owner’s Manual” or “Navigation System Owner’s Manual”.

20
PRIUS v_U (OM47674U)
For your information
Main Owner’s Manual
Please note that this manual applies to all models and explains all equip-
ment, including options. Therefore, you may find some explanations for
equipment not installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of color and equipment.
Noise from under vehicle after turning off the hybrid system
Approximately five hours after the hybrid system is turned off, you may hear
sound coming from under the vehicle for several minutes. This is the sound
of a fuel evaporation leakage check and, it does not indicate a malfunct\
ion.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota vehi-
cles are currently available in the market. You should know that Toyota does
not warrant these products and is not responsible for their performance,
repair, or replacement, or for any damage they may cause to, or adverse
effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products. Mod-
ification with non-genuine Toyota products could affect its performance,
safety or durability, and may even violate governmental regulations. In addi-
tion, damage or performance problems resulting from the modification may
not be covered under warranty.
