TOYOTA PRIUS V 2012 (in English) User Guide

11
PRIUS v_U (OM47784U)
A
Anti-glare inside rear view mirror Garage door opener switches

P. 108
P. 332
Sun visors P. 314
SRS curtain shield airbags P. 124
Interior light P. 302
Panoramic roof shades switch P. 322
Vanity mirrors P. 315
Interior light
Personal light P. 302
P. 303
: If equipped
*: Refer to “Display Audio System Owner’s Manual” or “Navigation System Owner’s Manual”.
Microphone* P. 340
“SOS” button
Auxiliary box

P. 340
P. 312

12
PRIUS v_U (OM47784U)
B
Window lock switch P. 112
Power window switches P. 112
Outside rear view mirror switches P. 110
Door lock switch P. 74
Inside lock button P. 74
Pictorial indexInterior

13
PRIUS v_U (OM47784U)
C
Cup holders P. 309
EV drive mode switch
Eco drive mode switch
Power mode switch P. 182
P. 187
P. 187
Console box P. 308

14
PRIUS v_U (OM47784U)
Pictorial indexInstrument panel
Headlight switch
Turn signal lever Fog light switch P. 213
P. 194
P. 221
Pre-collision braking off switch P. 259
Parking brake pedal P. 195
Fuel filler door opener P. 115
Tire pressure warning reset switch P. 391
Windshield wipers and washer switch
Rear window wiper and washer switch P. 223
P. 228
Gauges and meters
Trip-information display P. 197
P. 201
Audio system*2 P. 296
Navigation system*1
SRS driver airbag
Horn P. 124
P. 196
Card holder P. 313
Tilt and telescopic steering control lever P. 107
SRS knee airbag P. 124

15
PRIUS v_U (OM47784U)
A
Instrument panel light control dial P. 199
Headlight cleaner switch P. 230
Hood lock release lever P. 366
APGS pre-support switch*1
: If equipped
*1: Refer to “Navigation System Owner’s Manual”.
*2: Refer to “Display Audio System Owner’s Manual”.

16
PRIUS v_U (OM47784U)
Pictorial indexInstrument panel
B
Telephone switches*
“DISP” button P. 200Audio remote
control switches
*
Cruise control switch
Dynamic radar cruise control
switch

P. 231
P. 235
Vehicle-to-vehicle distance button P. 235
Talk switch*
“TRIP” button P. 200
Climate remote control switches P. 293

17
PRIUS v_U (OM47784U)
C
Clock adjustment buttons P. 316
MPH or km/h button P. 199
Shift lever P. 185
Emergency flasher switch P. 436
: If equipped
*: Refer to “Display Audio System Owner’s Manual” or “Navigation System Owner’s Manual”.
P position switch P. 188
Power (ignition) switch P. 175

18
PRIUS v_U (OM47784U)
AUX port/USB port*
Power outlet P. 317
Seat heater switches P. 319
Air conditioning system P. 280
Rear window and outside
rear view mirror defoggers
P. 295
Pictorial indexInstrument panel
D

19
PRIUS v_U (OM47784U)
: If equipped
*: Refer to “Display Audio System Owner’s Manual” or “Navigation System Owner’s Manual”.

20
PRIUS v_U (OM47784U)
For your information
Main Owner’s Manual
Please note that this manual applies to all models and explains all equip-
ment, including options. Therefore, you may find some explanations for
equipment not installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of color and equipment.
Noise from under vehicle after turning off the hybrid system
Approximately five hours after the hybrid system is turned off, you may hear
sound coming from under the vehicle for several minutes. This is the sound
of a fuel evaporation leakage check and, it does not indicate a malfunct\
ion.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota vehi-
cles are currently available in the market. You should know that Toyota does
not warrant these products and is not responsible for their performance,
repair, or replacement, or for any damage they may cause to, or adverse
effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products. Mod-
ification with non-genuine Toyota products could affect its performance,
safety or durability, and may even violate governmental regulations. In addi-
tion, damage or performance problems resulting from the modification may
not be covered under warranty.
