− AUTOMATIC TRANSAXLE (A241E)AUTOMATIC TRANSAXLE UNIT
AX−17
1996 RAV4 (RM447U)
15. DISCONNECT FOLLOWING CONNECTORS
Shift solenoid valve SL connector
Park/neutral position switch connector
Vehicle speed sensor connector
16. DISCONNECT 2 OIL COOLER HOSES
Loosen the 2 clips and disconnect the 2 oil cooler hoses.
17. REMOVE 2 POWER STEERING GEAR MOUNTING
BOLTS AND NUTS
Torque: 113 N·m (1,150 kgf·cm, 83 ft·lbf)
NOTICE:
Support the power steering gear housing securely.
18. REMOVE FRONT SUSPENSION CROSSMEMBER AS-
SEMBLY WITH STABILIZER BAR
Remove the 10 bolts, 2 nuts and front suspension crossmem-
ber assembly with stabilizer bar.
Torque:
A bolt: 206 N·m (2,100 kgf·cm, 152 ft·lbf)
B bolt: 137 N·m (1,400 kgf·cm, 101 ft·lbf)
C bolt: 35 N·m (360 kgf·cm, 26 ft·lbf)
D bolt: 72 N·m (730 kgf·cm, 53 ft·lbf)
Nut: 73 N·m (740 kgf·cm, 54 ft·lbf)
19. REMOVE STIFFENER PLATE
Remove the 3 bolts and stiffener plate.
Torque: 37 N·m (380 kgf·cm, 27 ft·lbf)

BR02L−02
W01806
SST
W01807
− BRAKEBRAKE MASTER CYLINDER
BR−11
1996 RAV4 (RM447U)
REMOVAL
1. DISCONNECT LEVEL WARNING SWITCH CONNEC-
TOR
2. DRAW OUT FLUID WITH SYRINGE
NOTICE:
Do not let brake fluid remain on a painted surface. Wash it
off immediately.
3. DISCONNECT R/B NO.2
Remove the 2 bolts and disconnect R/B No.2.
4. REMOVE AIR CLEANER CAP WITH AIR CLEANER
HOSE
5. w/o ABS:
DISCONNECT BRAKE LINES
Using SST, disconnect the 5 brake lines from the master cylin-
der and 3−way.
SST 09023−00100
Torque: 15 N·m (155 kgf·cm, 11 ft·lbf)
6. w/ ABS:
DISCONNECT BRAKE LINES
Using SST, disconnect the 2 brake lines from the master cylin-
der.
SST 09023−00100
Torque: 15 N·m (155 kgf·cm, 11 ft·lbf)
7. M/T:
DISCONNECT CLUTCH RESERVOIR HOSE
8. w/o ABS:
REMOVE MASTER CYLINDER
Remove the 2 nuts and pull out the master cylinder, 3−way and
gasket.
Torque: 13 N·m (130 kgf·cm, 9 ft·lbf)
9. w/ ABS:
REMOVE MASTER CYLINDER
Remove the 2 nuts, and pull out the master cylinder and gasket.
Torque: 13 N·m (130 kgf·cm, 9 ft·lbf)

BR02S−02
R10718
BR−18
− BRAKEBRAKE BOOSTER ASSEMBLY
1996 RAV4 (RM447U)
REMOVAL
1. REMOVE MASTER CYLINDER (See page BR−9)
2. REMOVE CHARCOAL CANISTER
3. DISCONNECT VACUUM HOSE FROM BRAKE
BOOSTER
4. REMOVE PEDAL RETURN SPRING
5. REMOVE CLIP AND CLEVIS PIN
6. REMOVE BRAKE BOOSTER
(a) Remove the 4 nuts and clevis.
(b) Pull out the brake booster and gasket.

BR0M3−01
F03521
SST
Gasket
N00744
SST
− BRAKEBRAKE BOOSTER ASSEMBLY
BR−19
1996 RAV4 (RM447U)
INSTALLATION
1. INSTALL BRAKE BOOSTER
(a) Install the booster and a new gasket.
(b) Install the clevis to the operating rod.
(c) Install and torque the booster installation nuts.
Torque:
13 N·m (130 kgf·cm, 9 ft·lbf)
(d) Insert the clevis pin into clevis, brake pedal, and install the
clip to the clevis pin.
(e) Install the pedal return spring.
2. ADJUST LENGTH OF BOOSTER PUSH ROD
(a) Install a new gasket on the master cylinder.
(b) Set the SST on the gasket, and lower the pin until its tip
slightly touches the piston.
SST 09737−00010
(c) Turn the SST upside down, and set it on the booster.
SST 09737−00010
(d) Measure the clearance between the booster push rod
and pin head (SST).
Clearance: 0 mm (0 in.)
(e) Adjust the booster push rod length until the push rod
slightly touches the pin head.
3. INSTALL CHARCOAL CANISTER TO ORIGINAL POSI-
TION
4. INSTALL MASTER CYLINDER
5. CONNECT VACUUM HOSE TO BRAKE BOOSTER
6. FILL BRAKE RESERVOIR WITH BRAKE FLUID AND
BLEED BRAKE SYSTEM (See page BR−4)
7. M/T:
BLEED CLUTCH SYSTEM
8. CHECK FOR LEAKS
9. CHECK AND ADJUST BRAKE PEDAL
(See page BR−6)
Check and adjust the brake pedal, then tighten the clevis lock
nut.
Torque:
25 N·m (260 kgf·cm, 19 ft·lbf)
10. DO OPERATIONAL CHECK (See page BR−16)

BR0M4−01
R10627
R10628
− BRAKEFRONT BRAKE PAD
BR−21
1996 RAV4 (RM447U)
REPLACEMENT
1. REMOVE FRONT WHEEL
Remove the wheel and temporarily fasten the disc with the hub
nuts.
2. INSPECT PAD LINING THICKNESS
Check the pad thickness through the caliper inspection hole
and replace the pads if they are not within the specification.
Minimum thickness: 1.0 mm (0.039 in.)
3. LIFT UP CALIPER
(a) Remove the flexible hose from the shock absorber brack-
et.
(b) Hold the sliding pin on the bottom and loosen the installa-
tion bolt.
(c) Remove the installation bolt.
(d) Lift up the caliper and suspend it securely.
HINT:
Do not disconnect the flexible hose from the caliper.
4. REMOVE THESE PARTS:
2 brake pads
4 anti−squeal shims
4 pad support plates
NOTICE:
The support plates can be used again provided that they
have sufficient rebound, no deformation, cracks or wear,
and have had all rust, dirt and foreign particles cleaned off.
5. CHECK DISC THICKNESS AND RUNOUT
(See page BR−26)
6. INSTALL 4 PAD SUPPORT PLATES

R10629
BR−22
− BRAKEFRONT BRAKE PAD
1996 RAV4 (RM447U)
7. INSTALL NEW PADS
NOTICE:
When replacing worn pads, the anti−squeal shims must be
replaced together with the pads.
(a) Apply disc brake grease to both side of the inner anti−
squeal shims (See page BR−20).
(b) Install the anti−squeal shim to the inner pad.
(c) Install the inner pad with pad wear indicator plate facing
upward.
(d) Install the outer pad.
NOTICE:
There should be no oil or grease adhering to the friction
surfaces of the pads or the disc.
8. INSTALL CALIPER
(a) Draw out a small amount of brake fluid from the reservoir.
(b) Press in the piston with a hammer handle or an equiva-
lent.
HINT:
If the piston is difficult to push in, loosen the bleeder plug and
push in the piston while letting some brake fluid escape.
(c) Install the caliper.
(d) Hold the sliding pin and torque the installation bolt.
Torque: 26 N·m (270 kgf·cm, 20 ft·lbf)
(e) Install the flexible hose bracket.
Torque: 33 N·m (340 kgf·cm, 25 ft·lbf)
9. INSTALL FRONT WHEEL
10. CHECK THAT FLUID LEVEL IS AT MAX LINE

BR0M5−01
R10630
BR−24
− BRAKEFRONT BRAKE CALIPER
1996 RAV4 (RM447U)
REMOVAL
1. DISCONNECT FLEXIBLE HOSE
(a) Remove the union bolt and 2 gaskets from the caliper,
then disconnect the flexible hose from the caliper.
Torque: 30 N·m (310 kgf·cm, 22 ft·lbf)
HINT:
At the time of installation, please refer to the following item.
Install the flexible hose lock securely in the lock hole in the cali-
per.
(b) Use a container to catch the brake fluid as it drains out.
2. REMOVE CALIPER
(a) Hold the sliding pin and loosen the 2 installation bolts.
Torque: 26 N·m (270 kgf·cm, 20 ft·lbf)
(b) Remove the 2 installation bolts.
(c) Remove the caliper from the torque plate.
3. REMOVE THESE PARTS:
2 brake pads with anti−squeal shims
4 pad support plates

BR0MA−03
BR−40
− BRAKEABS ACTUATOR
1996 RAV4 (RM447U)
REMOVAL
1. DISCONNECT BRAKE LINES
Using SST, disconnect the 6 brake lines from the ABS actuator.
SST 09023−00100
Torque: 15 N·m (155 kgf·cm, 11 ft·lbf)
2. DISCONNECT POWER STEERING FLUID RES-
ERVOIR
(a) Remove the bolt and disconnect the PS hose from the ac-
tuator bracket.
(b) Disconnect the PS fluid reservoir.
3. REMOVE ABS ACTUATOR ASSEMBLY
(a) Disconnect the 2 connectors.
(b) Remove the 3 bolts and ABS actuator assembly.
Torque: 19 N·m (195 kgf·cm, 14 ft·lbf)
4. 2WD
REMOVE ABS ACTUATOR
Remove the 2 nuts and actuator from the actuator bracket.
Torque: 5 N·m (55 kgf·cm, 48 in.·lbf)
5. 4WD
REMOVE ABS ACTUATOR
Remove the 3 nuts and actuator from the actuator bracket.
Torque: 5 N·m (55 kgf·cm, 48 in.·lbf)
6. 2WD
REMOVE 2 CUSHION BOLTS AND 3 CUSHIONS
7. 4WD
REMOVE 3 HOLDERS AND 3 CUSHIONS

Proper and Efficient Work Procedures
REMOVAL
NUMBER OF SPOT WELDS AND PANEL POSITIONS
The number of spot welds and the panel positions
to be removed are shown for your reference.
HINT: See ºSymbolsº on page IN-4, 5.
PRE-REMOVAL MEASURING
Before removal or cutting operaœ
tions, take measurements in acœ
cordance with the dimension diaœ
gram. Always use a puller to
straighten a damaged body or
frame.
REMOVAL OF ADJACENT COMPONENTS
When removing adjacent components, apply
protective tape to the surrounding body and
your tools to prevent damage.
HINT: See ºHandling Precautions on
Related Componentsº on page IN-6.
CUTTING AREA
Always cut in a straight
line and avoid
reinforced area. PRECAUTIONS FOR DRILLING OR
CUTTING
Check behind any area to be drilled or
cut to insure that there are no hoses,
wires, etc., that may be damaged.
HINT: See ºHandling Precautions on
Related Componentsº on page IN-6.
Cutting Okay
Corners
Reinforcement
WRONG
INTRODUCTIONINÅ“10

CodeMaterial
nameHeat*
resistant
temperature
limit °C (°F)Resistance to
alcohol or gasolineNotes
AASAcrylonitrile
Acrylic Styrene80
(176)Alcohol is harmless if applied
only for short time in small
amounts (e.g., quick wiping to
remove grease.)Avoid gasoline and
organic or aromatic
solvents.
ABSAcrylonitrile
Butadiene Styrene80
(176)Alcohol is harmless if applied
only for short time in small
amounts (e.g., quick wiping to
remove grease.)Avoid gasoline and
organic or aromatic
solvents.
AESAcrylonitrile
Ethylene Styrene80
(176)Alcohol is harmless if applied
only for short time in small
amounts (e.g., quick wiping to
remove grease).Avoid gasoline and
organic or aromatic
solvents.
BMCBulk
Moulding
Compound150
(302)Alcohol and gasoline are
harmless.Most solvents are
harmless.
CABCellulose
Acetate80
(176)Alcohol is harmless if applied
only for short time in small
amounts (e.g., quick wiping to
remove grease).Avoid gasoline and
organic or aromatic
solvents.
EPDM100
(212) Ethylene
PropyleneAlcohol is harmless.
Gasoline is harmless if applied
only for short time in small
amounts.Most solvents are
harmless but avoid
dipping in gasoline,
solvents, etc.
PAPolyamide
(Nylon)80
(176)Alcohol and gasoline are
harmless.Avoid battery acid.
PBTPolybutylene
Terephthalate160
(320)Alcohol and gasoline are
harmless.Most solvents are
harmless.
PC
Polycarbonate120
(248)Alcohol is harmless.Avoid gasoline brake
fluid, wax, wax removers
and organic solvents.
Avoid alkali.
PE
Polyethylene80
(176)Alcohol and gasoline are harmless.Most solvents are
harmless.
PETPolyethylene
Terephthalate75
(167)Alcohol and gasoline are
harmless.Avoid dipping in water.
HANDLING PRECAUTIONS
1. The repair procedure for plastic body parts must conform with the type of plastic material.
2. Plastic body parts are identified by the codes in the following chart.
3. When repairing metal body parts adjoining plastic body parts (by brazing, frame cutting, welding,
painting etc.), consideration must given to the property of the plastic.
*Temperatures higher than those listed here may result in material deformation during repair.
PLASTIC BODY PARTSPPÅ“2
