64
High-Low beamsÐFor high beams,
turn the headlights on and push the lever away from you (position 1). Pull the lever
toward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will tell
you that the high beams are on.
Flashing the high beam headlights
(position 3) ÐPull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights with knob turned to OFFº.TURN SIGNAL
To signal a turn, push the headlight/
turn signal lever up or down to posi-
tion 1. The key must be in the ONº position. The lever automatically returns after you make a turn, but you may have to return it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position 2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal bulb
is burned out. See Replacing light bulbsº
in chapter 7-3.To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn other drivers if your vehicle must be
stopped where it might be a traf fic hazard.
Always pull as far off the road as possible.
The turn signal light switch will not work
when the emergency flashers are operat- ing. Emergency flashers

186
Horizontal movement gauges: The red
mark on the gauge should be within two
marks from the center on both sides.
If a gauge reading is not within the accept-
able range, have the aiming adjusted by
your Toyota dealer.The following illustrations show how to
gain access to the bulbs. When replacing
a bulb, make sure the ignition switch and
light switch are off. Use bulbs with the wattage ratings given in the table.
Halogen bulbs have pressurized
gas inside and require special
handling. They can burst or shatter
if scratched or dropped. Hold a bulb
only by its plastic or metal case. Do
not touch the glass part of a bulb
with bare hands.
CAUTION
!
NOTICE
Only use a bulb of the listed type.
Light bulbsBulb
No.WType
HeadlightHB260/55A
Parking and front turn signal lights115727/8B
Front side marker lights1943.8C
Rear side marker lights1943.8C
Rear turn signal lights115627B
Stop and tail lights115727/8B
Back-up lights115627B
Licenses plate lightÐ5C
High mounted stop light92118C
Interior lightÐ10D
Personal lightÐ8B
A: HB1 halogen bulbs B: Single end bulbs
C: Wedge base bulbsD: Double end bulbs
Replacing light bulbsÐ

188
4. Install the rubber cover andsnuggle on the boss.
Make sure the rubber cover fits snugly on
the connector and the headlight body.5. Install the plastic cover with the TOPº mark upward and turn it
clockwise. Insert the connector.
Aiming is not necessary after replacing
the bulb. When aiming adjustment is nec-
essary, contact your Toyota dealer.Use a Philips-head screwdriver.
ÐParking and front turn signal lights
