TOYOTA RAV4 1998 Owners Manual

'98 Rav4.U121
Fan speed selector
Move the lever to adjust the fan
speedÐto the right to increase, to the left
to decrease.
Temperature selector
Move the lever to adjust the temperatu-
reÐto the right to warm, to the left to
cool.
Air flow selector
Move the lever to select the vents used
for air flow.
1. PanelÐ Air flows mainly from the
instrument panel vents.
2. Bi- levelÐ Air flows from both the floor
vents and the instrument panel vents.
3. FloorÐ Air flows mainly from the floor
vents.
4. Floor/WindshieldÐ Air flows mainly
from the floor vents and windshield
vents.
5. WindshieldÐ Air flows mainly from the
windshield vents. For details about air flow selector settings,
see the illustration after ºA/Cº button.
Vehicles with ºA/Cº buttonÐ
Moving the air flow control lever to wind-
shield position turns on the defroster-
linked air conditioning. At this time, the
ºA/Cº button indicator comes on regard-
less of whether or not the ºA/Cº button is
pressed in. This is to clean up the front
view more quickly.
When the ºA/Cº button is not pressed in,
moving the air flow control lever to anoth-
er position turns off the air conditioning.

'98 Rav4U
122
Air intake selector
Move the lever to select the air source. 1. RecirculateÐ Recirculates the air inside
the vehicle.
2. FreshÐ Draws outside air into the sys-
tem. ºA/Cº button
To turn on the air conditioning, press the
ºA/Cº button. The ºA/Cº button indicator
will come on. To turn the air conditioning
off, press the button again.
If the ºA/Cº button indicator flashes, there
is a problem in the air conditioning system
and the air conditioning automatically
shuts off. If this happens, take your ve-
hicle to a Toyota dealer for service.

'98 Rav4.U123
ÐAir flow selector settings
1: For air conditioning ÐOperating tips
To cool off your Toyota after it has
been parked in the hot sun, drive with
the windows open for a few minutes.
This vents the hot air, allowing the air
conditioning to cool the interior more
quickly.
Make sure the air intake grilles in front
of the windshield are not blocked (by
leaves or snow, for example).
On humid days, do not blow cold air
on the windshield. The windshield could
fog up because of the difference in air
temperature on the inside and outside
of the windshield.
Keep the area under the front seats
clear to allow air to circulate through-
out the vehicle.
On cold days, move the fan speed to
ºHIº for a minute to help clear the in-
take ducts of snow or moisture. This
can reduce the amount of fogging on
the windows.

'98 Rav4U
124
Heating
For best results, set controls to:
Fan speedÐ Any setting except ºOFFº
TemperatureÐ To w a r d s WARM
(red zone)
Air intakeÐFRESH (outside air)
Air flowÐFLOOR
Air conditioningÐOFF
For quick heating, select recirculated
air for a few minutes. To keep the
windows from fogging, select fresh af-
ter the vehicle interior has been
warmed.
Press the ºA/Cº button on for dehumidi-
fied heating.
Choose floor/windshield air flow to heat
the vehicle interior while defrosting or
defogging the windshield. Air conditioning
For best results, set controls to:
Fan speedÐ Any setting except ºOFFº
TemperatureÐ To w a r d s COLD
(blue zone)
Air intakeÐFRESH (outside air)
Air flowÐPANEL
Air conditioningÐON For quick cooling, move the air intake
selector to recirculate for a few min-
utes.
Ventilation
For best results, set controls to:
Fan speedÐ Any setting except ºOFFº
TemperatureÐ To w a r d s COLD
(blue zone)
Air intakeÐFRESH (outside air)
Air flowÐPANEL
Air conditioningÐOFF
Defogging
The inside of the windshield
For best results, set controls to:
Fan speedÐ Any setting except ºOFFº
TemperatureÐ To w a r d s WARM
(red zone) to heat; COLD (blue zone) to
cool
Air intakeÐFRESH (outside air)
Air flowÐWINDSHIELD
Air ConditioningÐON
Vehicles with ºA/Cº buttonÐ
Moving the air flow control lever to wind-
shield position turns on the defroster-
linked air conditioning. At this time, the
ºA/Cº button indicator comes on regard-
less of whether or not the ºA/Cº button is
pressed in. This is to clean up the front
view more quickly.
When the ºA/Cº button is not pressed in,
moving the air flow control lever to anoth-
er position turns off the air conditioning.
On humid days, do not blow cold air
on the windshieldÐthe difference be-
tween the outside and inside tempera-
tures could make the fogging worse.

'98 Rav4.U125
Defrosting
The outside of the windshield
For best results, set controls to:
Fan speedÐ Any setting except ºOFFº
TemperatureÐ To w a r d s WARM
(red zone)
Air intakeÐFRESH (outside air)
Air flowÐWINDSHIELD
Vehicles with ºA/Cº buttonÐ
Moving the air flow control lever to wind-
shield position turns on the defroster-
linked air conditioning. At this time, the
ºA/Cº button indicator comes on regard-
less of whether or not the ºA/Cº button is
pressed in. This is to clean up the front
view more quickly.
When the ºA/Cº button is not pressed in,
moving the air flow control lever to anoth-
er position turns off the air conditioning.
To heat the vehicle interior while de-
frosting the windshield, choose
floor/windshield air flow. ÐInstrument panel vents
Side vents
Lower vent If air flow control is not satisfactory, check
the instrument panel vents. The instrument
panel vents may be opened or closed as
shown.

'98 Rav4U
126
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1- 8
Other equipment
Clock
Cigarette lighter and ashtray
Power outlet
Glovebox
Auxiliary box
Floor mat
Clock
The digital clock indicates the time.
The key must be in the ºACCº or ºONº
position.
To reset the hour: Push the ºHº button.
To reset the minutes: Push the ºMº button.
If quick adjustment to a full hour is de-
sired, push the º:00º button.
For example, if the º:00º button is de-
pressed when the time is between
1:01Ð1:29, the time will change to 1:00.
If the time is between 1:30Ð1:59, the
time will change to 2:00.
If the electrical power source has been
disconnected from the clock, the time dis-
play will automatically be set to 1:00 (one
o'clock).
When the instrument panel lights are
turned on, the brightness of the time in-
dication will be reduced.

'98 Rav4.U127
Cigarette lighter and ashtray
CIGARETTE LIGHTER
To use the cigarette lighter, press it in.
When it becomes heated, it automatical-
ly pops out ready for use.
If the engine is not running, the key must
be in the ºACCº position.
Do not hold the cigarette lighter pressed
in.
Use a Toyota genuine cigarette lighter or
equivalent for replacement.
ASHTRAY
To use the ashtray, open the cover.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, close the
ashtray cover completely.
To remove the ashtray, open the ashtray
cover and pull it out.
CAUTION
To reduce the of injury in case of an
accident or sudden stop while driv-
ing, always close the ashtray cover
completely after using.
Power outlet (4- door hardtop)
The power outlet is designed for power
supply for car accessories.
The key must be in the ºACCº or ºONº
position for the power outlets to be used.

'98 Rav4U
128
NOTICE
To prevent the fuse from being blown, do not use the electricityover the total vehicle capacity of 12V/120W.
To prevent the battery from beingdischarged, do not use the power outlet longer than necessary when
the engine is not running.
Close the power outlet lid when thepower outlet is not in use. Insertinga foreign object other than the ap- propriate plug that fits the outlet,
or allowing any liquid into the out-let may cause electrical failure or
short circuits.
Glovebox
To use the glovebox, do this.
To open: Pull the lever.
To lock: Insert the master key and turn it
clockwise.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glovebox door closed
while driving.
Auxiliary box
2- door hardtop and soft- top (left side)
2- door hardtop and soft- top (right side),
and 4- door hardtop

'98 Rav4.U129
To open the box, turn the knob.
You can hold the objects in the box
with the holding belt.
1. To loosen: Pull the buckle forward.
2. To tighten: Pull on the belt.
Make sure the objects are securely held. Floor matUse a floor mat of the correct size.
If the floor carpet and floor mat have a
hole, then it is designed for use with a
locking clip. Fix the floor mat with locking
clip into the hole in the floor carpet.

'98 Rav4U
130
CAUTION
Make sure the floor mat is properly
placed on the floor carpet. If the floor
mat slips and interferes with the
movement of the pedals during driv-
ing, it may cause an accident.
