Rav4(U)
1722000 RAV4 (OM42479U)
3. Look for obvious coolant leaks from the
radiator, hoses, and under the vehicle.
However, note that water draining from
the air conditioning is normal if it has
been used.
CAUTION
When the engine is running, keep
hands and clothing away from the
moving fan and engine drive belts.
4. If the coolant is leaking, stop the en-
gine immediately. Call a Toyota dealer
for assistance.
5. If there are no obvious leaks, check
the coolant reservoir. If it is dry, add
coolant to the reservoir while the en-
gine is running. Fill it about half full.
CAUTION
Do not attempt to remove the radiator
cap when the engine and radiator are
hot. Serious injury could result from
scalding hot fluid and steam blown
out under pressure.
6. After the engine coolant temperature
has cooled to normal, again check the
coolant level in the reservoir. If neces-
sary, bring it up to half full again. Seri-
ous coolant loss indicates a leak in the
system. You should have it checked as
soon as possible at your Toyota dealer.
If you have a flat tire—
1. Reduce your speed gradually, keeping
a straight line. Move cautiously off the
road to a safe place well away from
the traffic. Avoid stopping on the center
divider of a highway. Park on a level
spot with firm ground.
2. Stop the engine and turn on your
emergency flashers.
3. Firmly set the parking brake and put
the transmission in ”P” (automatic) or
reverse (manual).
4. Have everyone get out of the vehicle
on the side away from traffic.
5. Read the following instructions thor-
oughly.
CAUTION
When jacking, be sure to observe the
following to reduce the possibility of
personal injury:
Follow jacking instructions.
Do not put any part of your body
under the vehicle supported by the
jack. Personal injury may occur.
Do not start or run the engine while
your vehicle is supported by the
jack.
ProCarManuals.com

Rav4(U)
2362000 RAV4 (OM42479U)
Instrument panel
19. ECU−IG 10 A: Electronically controlled
automatic transmission system, rear
window defogger, center differential
lock system, electric moon roof, multi-
port fuel injection system/sequential
multiport fuel injection system, electric
cooling fan, anti−lock brake system,
cruise control system
20. TURN & GAUGE 10 A: Turn signal
lights, gauges and meters, back−up
lights, service reminder indicators, air
conditioning system, daytime running
light system
Passenger’s side kick panel
21. STOP 10 A: stoplights, high mounted
stoplight, electronically controlled auto-
matic transmission system, anti−lock
brake system
22. TAIL 15 A: Gauges and meters, emer-
gency flashers, cigarette lighter, center
differential lock system, clock, rear win-
dow defogger, air conditioning system,
electronically controlled automatic
transmission system, car audio system,
tail lights, license plate lights, parking
lights, instrument panel light control,
side marker lights
23. OBD 10 A: On−board diagnosis system
24. SRS−B 10 A: SRS warning light25. HORN 10 A: Horn
26. DEFOG 20 A: Rear window defogger
27. AM1 10 A: ”CIG”, ”PWR OUTLET”,
”SRS−ACC”, ”WIPER”, ”ECU−IG” and
”TURN & GAUGE” fuses
28. A/C 10 A: Air conditioning system
Fuses (type B)
29. MAIN No.1 40 A: Starting system, ”H−
LP (RH)”, ”H−LP (LH)”, ”H−LP RH−H”,
”H−LP LH−H”, ”H−LP RH−L” and ”H−LP
LH−L” fuses
30. CDS FAN 30 A: Electric cooling fans
31. RDI FAN 30 A: Electric cooling fans
32. PWR 30 A: Power door lock system,
electric moon roof, power windows
