TONE AND BALANCE
For details about your system’s tone and
balance controls, see the description of
your own system.
Tone
How good an audio program sounds to
you is largely determined by the mix of
the treble, midrange and bass levels. In
fact, different kinds of music and vocal
programs usually sound better with differ-
ent mixes of treble, midrange and bass.
Balance
A good balance of the left and right stereo
channels and of the front and rear sound
levels is also important.
Keep in mind that if you are listening to
a stereo recording or broadcast, changing
the right/left balance will increase the vol-
ume of one group of sounds while de-
creasing the volume of another.YOUR RADIO ANTENNA
Your vehicle has a mast type antenna.
To remove the antenna, carefully turn it
counterclockwise.
NOTICE
To prevent damage to the antenna,
make sure it is removed before driv-
ing your Toyota through an automatic
car wash.
YOUR CASSETTE PLAYER
When you insert a cassette, the exposed
tape should be to the right.
NOTICE
Do not oil any part of the player and
do not insert anything other than cas-
sette tapes into the slot, or the tape
player may be damaged.
YOUR COMPACT DISC PLAYER
When you insert a disc, gently push it in
with the label side up. (The player will
automatically eject a disc if the label side
is down.) The compact disc player will
play from track 1 through the end of the
disc. Then it will play from track 1 again.
NOTICE
Never try to disassemble or oil any
part of the compact disc player. Do
not insert anything except a compact
disc into the slot.
8 cm (3 in.) compact disc singles
Your compact disc player does not need
an adaptor to play compact disc singles.
Compact disc singles are about 8 cm (3
in.) in diametersmaller than standard
discs.
After you eject a compact disc single, do
not insert a standard 12 cm (4.7 in.) disc
until “DISC” disappears from the display.
NOTICE
Do not use an adaptor for compact
disc singles
—it could cause tracking
errors or interfere with the ejection of
compact discs.

’02 Rav4_U (L/O 0108)
11 72002 MY RAV4_U (OM42503U)
After the end of the tape is reached,
the player will automatically reverse
sides and start playing the other side.
There must be at least 3 seconds of blank
space between tracks for the track button
to work correctly. In addition, the feature
may not work well with some spoken
word, live, or classical recordings.
ST (Stereo reception) display
Your radio automatically changes to stereo
reception when a stereo broadcast is re-
ceived. “ST” appears on the display. If the
signal becomes weak, the radio reduces
the amount of channel separation to prev-
ent the weak signal from creating noise.
If the signal becomes extremely weak, the
radio switches from stereo to mono recep-
tion.
TA P E
Push “TAPE” to switch from radio or com-
pact disc operation to cassette operation.
If the audio system is off, you can turn
on the cassette player by pushing “TAPE”.
In both cases, a cassette must already be
loaded in the player. TRACK (Track up/down button):
Compact disc player
By using this button, you can skip up or
down to a different track.
Push either side of the track button until
the number of the track you want to listen
to appears on the display. If you want to
return to the beginning of the current
track, push the down side of the button
one time, quickly.
TUNE (Tuning)
Your Toyota has an electronic tuning radio
(ETR). Turn the knob clockwise to step up
the frequency. Turn the knob counterclock-
wise to step down the frequency.

’02 Rav4_U (L/O 0108)
1232002 MY RAV4_U (OM42503U)
TUNE (Tuning)
Your Toyota has an electronic tuning radio
(ETR). Turn the knob clockwise to step up
the frequency. Turn the knob counterclock-
wise to step down the frequency.NOTICE
To ensure the correct audio system
operation:
Be careful not to spill beverages
over the audio system.
 Do not put anything other than a
cassette tape or Compact Disc into
the slot.
 The use of cellular phone inside or
near the vehicle may cause a noise
from the speakers of the audio sys-
tem which you are listening to.
However, this does not indicate a
malfunction.
RADIO RECEPTION
Usually, a problem with radio reception
does not mean there is a problem with
your radio—it is just the normal result of
conditions outside the vehicle.
For example, nearby buildings and terrain
can interfere with FM reception. Power
lines or telephone wires can interfere with
AM signals. And of course, radio signals
have a limited range. The farther you are
from a station, the weaker its signal will
be. In addition, reception conditions
change constantly as your vehicle moves. Here are some common reception prob-
lems that probably do not indicate a prob-
lem with your radio:
FM
Fading and drifting stations—Generally, the
effective range of FM is about 40 km (25
miles). Once outside this range, you may
notice fading and drifting, which increase
with the distance from the radio transmit-
ter. They are often accompanied by distor-
tion.
Multipath—FM signals are reflective,
making it possible for two signals to reach
your antenna at the same time. If this
happens, the signals will cancel each oth-
er out, causing a momentary flutter or
loss of reception.
Static and fluttering—These occur when
signals are blocked by buildings, trees, or
other large objects. Increasing the bass
level may reduce static and fluttering.
Station swapping—If the FM signal you
are listening to is interrupted or weak-
ened, and there is another strong station
nearby on the FM band, your radio may
tune in the second station until the origi-
nal signal can be picked up again.
Car audio system operating
hints

’02 Rav4_U (L/O 0108)
1362002 MY RAV4_U (OM42503U)
The digital clock indicates the time.
The key must be in the “ACC” or “ON”
position.
To reset the hour: Push the “H” button.
To reset the minutes: Push the “M” button.
If quick adjustment to a full hour is de-
sired, push the “:00” button.
For example, if the “:00” button is de-
pressed when the time is between
1:01—1:29, the time will change to 1:00.
If the time is between 1:30—1:59, the
time will change to 2:00.If the electrical power source has been
disconnected from the clock, the time dis-
play will automatically be set to 1:00 (one
o’clock).Cigarette lighter and front ashtray
Rear ashtray
Clock
Cigarette lighter and ashtrays

’02 Rav4_U (L/O 0108)
2662002 MY RAV4_U (OM42503U)
A
Adding washer fluid243
. . . . . . . . . . . . . . . . . .
Adjustment
Front seats 29
. . . . . . . . . . . . . . . . . . . . . . . . .
Rear seats 30
. . . . . . . . . . . . . . . . . . . . . . . . .
Seat belt 40
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Air cleaner 230
. . . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioning system 128
. . . . . . . . . . . . . . .
Airbags 50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheel precautions 237
. . . . . . . . . .
Antiglare inside rear view mirror 76 . . . . . . .
Antilock brake system warning light 90 . . . .
Antitheft steering column lock 98
. . . . . . . . .
Appearance care
Cleaning the interior 209
. . . . . . . . . . . . . . . .
Protecting your Toyota from corrosion 206
. . . . . . . . . . . . . . . . . . .
Washing and waxing 207
. . . . . . . . . . . . . . . .
Automatic transmission
Driving with an automatic transmission 99
. . . . . . . . .
Shift lock override button 202
. . . . . . . . . . . .
Shift pattern 99
. . . . . . . . . . . . . . . . . . . . . . . .
Shifting speed 99
. . . . . . . . . . . . . . . . . . . . . .
Automatic transmission fluid temperature warning light 90
. . . . . . . . . . . .
Auxiliary boxes 141
. . . . . . . . . . . . . . . . . . . . . .
Auxiliary catch, Engine hood 22
. . . . . . . . . . .
B
Back door 21
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Back door lock 21
. . . . . . . . . . . . . . . . . . . . . . . . Battery
Checking battery condition 240
. . . . . . . . . .
Gas caution 240
. . . . . . . . . . . . . . . . . . . . . . .
Handling safety 240
. . . . . . . . . . . . . . . . . . . .
Recharging precautions 241
. . . . . . . . . . . . .
Winter driving tips 173
. . . . . . . . . . . . . . . . . .
Before starting the engine 170
. . . . . . . . . . . . .
Brake pad wear limit indicators 164 . . . . . . . .
Brake system 161
. . . . . . . . . . . . . . . . . . . . . . . .
Brake system warning light 90
. . . . . . . . . . . . .
Brakes
Fluid level 229
. . . . . . . . . . . . . . . . . . . . . . . . .
Pad wear limit indicators 164
. . . . . . . . . . . .
Parking 104
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Breakin tips 155
. . . . . . . . . . . . . . . . . . . . . . . .
Brightness control 82
. . . . . . . . . . . . . . . . . . . . .
C
Car audio system 110
. . . . . . . . . . . . . . . . . . . .
Carbon monoxide caution 159
. . . . . . . . . . . . .
Cassette player 110
. . . . . . . . . . . . . . . . . . . . . .
Checking and replacing fuses 242
. . . . . . . . .
Checking brake fluid 229
. . . . . . . . . . . . . . . . . .
Checking the engine oil level 226
. . . . . . . . . .
Checking the radiator and condenser 228
. . . . . . . . . . . . . . . . . . . . . . . . .
Child restraint
Child restraint system 58
. . . . . . . . . . . . . . .
Installation 60
. . . . . . . . . . . . . . . . . . . . . . . . .
Installation with ISOFIX rigid anchor 72
. . . . . . . . . . . . . . . . . . . . . .
Precautions 57
. . . . . . . . . . . . . . . . . . . . . . . . Types of child restraint system 59
. . . . . . . .
Using a top strap 69
. . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtrays 136
. . . . . . . . .
Cleaning the interior 209
. . . . . . . . . . . . . . . . . .
Clock 136
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cold weather
Operation 173
. . . . . . . . . . . . . . . . . . . . . . . . .
Compact disc auto changer controller 110
. . . . . . . . . . . . . . . . . .
Compact disc player 110
. . . . . . . . . . . . . . . . . .
Condenser
Checking the condenser 228
. . . . . . . . . . . .
Controls, Instrument panel 2,4
. . . . . . . . . . . .
Cooling system
Coolant level 227
. . . . . . . . . . . . . . . . . . . . . .
Engine overheating 188
. . . . . . . . . . . . . . . . .
Radiator and reservoir 227
. . . . . . . . . . . . . .
Radiator cap 188
. . . . . . . . . . . . . . . . . . . . . . .
Winter driving tips 173
. . . . . . . . . . . . . . . . . .
Corrosion prevention 206
. . . . . . . . . . . . . . . . .
Cruise control 105
. . . . . . . . . . . . . . . . . . . . . . .
Cup holder
Front 143
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear 143
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D
Defogger
Out side rear view mirror 85 . . . . . . . . . . . . .
Rear window 85
. . . . . . . . . . . . . . . . . . . . . . . .
Differential, Limited slip 165
. . . . . . . . . . . . . . .
Dimmer switch, Headlight 80
. . . . . . . . . . . . . .
Dinghy towing 174,175
. . . . . . . . . . . . . . . . . . .
Directional signals 80
. . . . . . . . . . . . . . . . . . . .
