audio TOYOTA RAV4 2007 XA30 / 3.G Quick Reference Guide

1
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
INDEX
ItemPage no.
OVERVIEWEngine maintenance8Fuel tank door release and cap 6Hood release 7Indicator symbols 4-5Instrument cluster 4Instrument panel 2-3
Keyless entry16-7
FEATURES/OPERATIONSActive torque control 4WD10Air Conditioning/Heating16-17Audio18-19Auto LSD(Limited Slip Differential)21Automatic transmission9Bottle holders17Clock17Cruise control 23Cup holders 23
Door locks 21Light control-Instrument panel 22Lights & turn signals14Moonroof 20Parking brake15Power outlets 22Rear seat entertainment system 20Seat adjustments-Front10Seat adjustments-Second row seats11Seat heaters16Seats-Head restraints11Seats-Folding down second row seats12Seats-Stowing third row seats13Te l e p h o n e controls (Bluetooth®)21Tilt and telescopic steering wheel15Windows15
Windshield wiper & washer13
SAFETY AND EMERGENCY FEATURESDoors-Child safety locks 24Seat belts 24Seat belts-Shoulder belt anchor 24Spare tire & tools 25
Tire Pressure Wa r n i n g System 24
1Visit your Toyota dealer for information on
customizing this feature.

3
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Clock and Air Conditioning display
12V DC Power outlet
Seat heater switch
1
Downhill Assist Control (DAC) switch
Front passenger seat belt reminder light
Engine immobilizer indicator
1
Ignition switch
Tilt and telescopic steering release
115V AC Power outlet ON/OFF switch
1
1
If equipped
2
OVERVIEW
Instrument panel
Steering wheel audio control
Te l e p h o n e controls1
Speech command button1
Cruise control
Instrument panel light control
Headlight, turn signal and front fog light
1control
Wiper and washer controls
Four-wheel drive lock switch (4WD models) or
“AUTO LSD” switch (2WD models)
Audio system
Emergency flasher switch
Front passenger occupant classification indicator
Air Conditioning controls
Rear window and outside rear view mirror defogger
switch
1
With manual Air
Conditioning system
Steering wheel
controlsWith automatic Air
Conditioning system

19
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
18
FEATURES/OPERATIONS
“”
Vo l u m e control
“MODE”
Push to turn audio ON and select an audio mode.
Push and hold to turn the audio OFF.
“”
-In radio modePush to select a preset station.
Push and hold to seek the next strong station.
-In CD modePush to skip up or down to next/
previous
track.
By inserting a mini plug into the AUX audio jack, you
can listen to music from a portable audio device
through the vehicle’s speaker system.
>>
Steering wheel controls (if equipped)
CD PLAYER
To scan tracks on a disc Push “SCAN.” Push again to
hold selection.
CDChanger (Ty p e 2)
-To load one disc Push “LOAD” and insert one disc.
-To load multiple discs Push and hold “LOAD” until
you hear a beep. Insert one disc. Wait until the
green indicator illuminates and shutter
opens to
insert next disc.
To select a file (MP3/WMA only) Tu r n “TUNE.
FILE.”
To select a folder (MP3/WMA only) Push either side
of “FOLDER.”
AUX audio jack
Audio
View CD text Eject CD Push to turn
ON/OFF
Push to
adjust
tone &
balance
Push to
skip
up/down
folder Seek
station/
CD track
select
Station/CD
track scanMode
Load CD(s) Preset buttons - functions in other
modes indicated above number.
RADIO
To preset stations Tune in the desired station and
hold down a preset button (1-6) until you hear a
beep. Push desired preset button (1-6) to select.
To scan stations Push “SCAN.” Push and hold to scan
preset stations. Push again to hold selection.
-+
Ty p e 1
Ty p e 2 additional functions
Ty p e 2 (with JBL speakers)

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
20
FEATURES/OPERATIONS
Door locks
UnlockLock
Moonroof (if equipped)
Tilting operation
Sliding operation
NOTE:If battery is disconnected, the moonroof
needs to be reinitialized. Refer to the Owner’s
Manualfor more details.
21
Open
Close
Close Tilt
Recommended
driving position
to minimize
wind noise.
Rear seat entertainment system (if equipped)
Front audio system
DVD player
DVD screen
Remote control
A/V input adapter
115V AC Power outlet
115V AC Power outlet ON/OFF switch
Auto LSD (Limited Slip Differential)
(2WD models)
Push the “AUTO LSD” switch when the vehicle is
stopped. To deactivate, push the switch again.
NOTE: It will ONLY work for 2-wheel drive models. It
should ONLY be used when wheel spinning occurs on
slippery or unpaved surfaces.
Refer to the Owner‘s Manualfor more details on
this system before attempting to
use it.
Bluetooth®technology allows dialing or receipt of
calls without taking your hands from the steering
wheel or using a cable to connect the telephone and
the system.
Refer to the Owner’s Manualfor more details.
Telephone controls (Bluetooth®)*
(if equipped)
