bluetooth TOYOTA RAV4 2007 XA30 / 3.G Quick Reference Guide

1
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
INDEX
ItemPage no.
OVERVIEWEngine maintenance8Fuel tank door release and cap 6Hood release 7Indicator symbols 4-5Instrument cluster 4Instrument panel 2-3
Keyless entry16-7
FEATURES/OPERATIONSActive torque control 4WD10Air Conditioning/Heating16-17Audio18-19Auto LSD(Limited Slip Differential)21Automatic transmission9Bottle holders17Clock17Cruise control 23Cup holders 23
Door locks 21Light control-Instrument panel 22Lights & turn signals14Moonroof 20Parking brake15Power outlets 22Rear seat entertainment system 20Seat adjustments-Front10Seat adjustments-Second row seats11Seat heaters16Seats-Head restraints11Seats-Folding down second row seats12Seats-Stowing third row seats13Te l e p h o n e controls (Bluetooth®)21Tilt and telescopic steering wheel15Windows15
Windshield wiper & washer13
SAFETY AND EMERGENCY FEATURESDoors-Child safety locks 24Seat belts 24Seat belts-Shoulder belt anchor 24Spare tire & tools 25
Tire Pressure Wa r n i n g System 24
1Visit your Toyota dealer for information on
customizing this feature.

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
20
FEATURES/OPERATIONS
Door locks
UnlockLock
Moonroof (if equipped)
Tilting operation
Sliding operation
NOTE:If battery is disconnected, the moonroof
needs to be reinitialized. Refer to the Owner’s
Manualfor more details.
21
Open
Close
Close Tilt
Recommended
driving position
to minimize
wind noise.
Rear seat entertainment system (if equipped)
Front audio system
DVD player
DVD screen
Remote control
A/V input adapter
115V AC Power outlet
115V AC Power outlet ON/OFF switch
Auto LSD (Limited Slip Differential)
(2WD models)
Push the “AUTO LSD” switch when the vehicle is
stopped. To deactivate, push the switch again.
NOTE: It will ONLY work for 2-wheel drive models. It
should ONLY be used when wheel spinning occurs on
slippery or unpaved surfaces.
Refer to the Owner‘s Manualfor more details on
this system before attempting to
use it.
Bluetooth®technology allows dialing or receipt of
calls without taking your hands from the steering
wheel or using a cable to connect the telephone and
the system.
Refer to the Owner’s Manualfor more details.
Telephone controls (Bluetooth®)*
(if equipped)
