TOYOTA RAV4 2010 XA30 / 3.G User Guide

11
C
Shift lever P. 150
Outside rear view mirror switches P. 79
Parking brake lever
P. 154
AUX adapter
P. 262
Cup holders P. 308

12
Tilt and telescopic steering lock release lever P. 76
Headlight switch
Turn signal lever
Fog light switch

P. 165
P. 153
P. 168
Windshield wiper and washer switch
Rear window wiper and washer switch P. 169
P. 171
Fuel filler door opener
P. 88
Emergency flasher
switch
P. 406
Four-wheel drive lock switch  P. 192
Pictorial indexInstrument panel
Gauges and meters P. 156
Audio system
Navigation system *P. 236
Hood release lever P. 346
Horn P. 155

13
A
Instrument panel light control dial P. 157
“DAC” switch  P. 189
Power outlet main switch  P. 315
: If equipped
*: Refer to “Navigation System Owner’s Manual”.

14
B
Cruise control switch P. 172
“DISP” switch P. 163Audio remote control switches ,* P. 263
Without hands-free phone system
Engine (ignition) switch
(without smart key system)
P. 147
Instrument panelPictorial index
With hands-free phone system
Cruise control switch P. 172
“DISP” switch P. 163Audio remote control switches P. 263
Talk switch P. 271
Telephone switch P. 271
Engine (ignition) switch
(without smart key system)
P. 147

15
With an automatic air conditioning system
With a manual air conditioning system
C
Air conditioning system P. 220
Rear window defogger switch
Outside rear view mirror defogger switch

P. 233
P. 233
Engine (ignition) switch
(with smart key system)
P. 143
Air conditioning system P. 225
Rear window and outside rear view mirror defogger switch P. 233
Security indicator P. 92
Security indicator P. 92
: If equipped
*: Refer to “Navigation System Owner’s Manual”.

16
D
Windshield wiper de-icer switch  P. 235
Cup holders P. 308
Seat heater switch  P. 318
Power outlet P. 315
Enhanced VSC
OFF switch
P. 183
Instrument panelPictorial index

17
Luggage compartmentPictorial index
Luggage cover  P. 325
Second seatback release lever 
P. 57
Grocery bag hooks
P. 323
Storage boxes  P. 323
Cargo hooks P. 323
: If equipped
Power outlet P. 315

18
For your information
Main Owner’s Manual
Please note that this manual covers all models and all equipment, including
options. Therefore, you may find some explanations for equipment not
installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound
coming from under the vehicle for several minutes. This is the sound of a fuel
evaporation leakage check and it does not indicate a malfunction.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota
vehicles are currently available on the market. You should know that these
parts are not covered by Toyota warranty and that Toyota is not responsible
for their performance, repair, or replacement, or for any damage they may
cause to, or adverse effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products.
Modification with non-genuine Toyota products may affect performance,
safety or durability, and may even violate governmental regulations. In
addition, damage or performance problems resulting from the modification
may not be covered under warranty.

19
Installation of a mobile two-way radio system
As the installation of a mobile two-way radio system in your vehicle may
affect electronic systems such as the multi-port fuel injection system/sequen-
tial multi-port fuel injection system, cruise control system, anti-lock brake
system, SRS airbag system or seat belt pretensioner system, be sure to
check with your Toyota dealer for precautionary measures or special instruc-
tions regarding installation.
Scrapping of your Toyota
The SRS airbag and seat belt pretensioner devices in your Toyota contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt pretensioner
removed and disposed of by a qualified service shop or by your Toyota
dealer before you scrap your vehicle.
Perchlorate Material
Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These compo-
nents may include airbag, seat belt pretensioners, and wireless remote con-
trol batteries.

20
CAUTION
■General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ-
ence of alcohol or drugs that have impaired your ability to operate your vehi-
cle. Alcohol and certain drugs delay reaction time, impair judgment and
reduce coordination, which could lead to an accident that could result in
death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other
drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that dis-
tracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.
■ General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the windows, the moon roof, or other features of the vehicle. In addition, heat
build-up or extremely cold temperatures inside the vehicle can be fatal to
children.
