TOYOTA RAV4 2011 XA30 / 3.G Navigation Manual

AUDIO SYSTEM
161
(d) Operating an audio CD
Playing an audio CD
Push the “AUDIO” button to display
this screen.
Selecting a desired track
“TUNE·SEEK/TRACK” button: Use for a
direct access to a desired track.
Push “
” or “” sides of the
“TUNE·SEEK/TRACK” button and repeat
it until the desired track number appears
on the screen. As you release the button,
the CD player will start playing the selected
track from the beginning.
“TRACK LIST”: The desired track can be
selected from a list. This function is avail-
able only when the vehicle is not moving.
Touch “TRACK LIST”. The track list is
displayed.

AUDIO SYSTEM
162
Touch the desired track number. The
CD player will start playing the selected
track from the beginning.
: By touching this button, the list moves
up by 6 track groups. If this button is
touched when the top page of the list is dis-
played, the last page is displayed.
: By touching this button, the list moves
down by 6 track groups. If this button is
touched when the last page of the list is
displayed, the top page is displayed.
Fast forward: Push “
” sides of the
“TUNE·SEEK/TRACK” button and hold it
to fast forward the disc. When you release
the button, the CD player will resume play-
ing from that position.
Reverse: Push “
” sides of the
“TUNE·SEEK/TRACK” button and hold it
to reverse the disc. When you release the
button, the CD player will resume playing.
Searching for a desired track
While the disc is playing, touch
“SCAN” briefly.
“SCAN” appears on the screen. The CD
player will play the next track for 10 sec-
onds, then scan again. To select a track,
touch “SCAN” once again. If the CD
player reaches the end of the disc, it will
start playing at track 1.
After all the tracks are scanned in one
pass, normal play resumes.

AUDIO SYSTEM
163

Other functions
“RPT”:
Use it for automatic repeat of the
track or disc you are currently listening to.
While the track is playing, touch “RPT”
briefly.
“RPT” appears on the screen. When the
track is finished, the CD player will auto-
matically go back to the beginning of the
track and play the track again. To cancel
it, touch “RPT” once again. “RAND”:
Use it for automatic and random
selection.
While the disc is playing, touch
“RAND” briefly.
“RAND” appears on the screen. The sys-
tem selects a track on the disc being lis-
tened to in random order. To cancel it,
touch “RAND” once again.
If a CD −TEXT disc is inserted, the title of
the disc and track will be displayed. Up to
29 letters can be displayed.

AUDIO SYSTEM
164
(e) Operating a MP3/WMA disc
Playing a MP3/WMA disc
Push the “AUDIO” button and touch a
MP3/WMA disc number to display this
screen.
Selecting a desired folder
“FOLDER ”: Touch this button to go to
the next folder.
“FOLDER ”: Touch this button to go to
the previous folder.
“FOLDER LIST”: The desired folder can
be selected in a list. This function is avail-
able only when the vehicle is not moving.
Touch “FOLDER LIST”. The folder list is
displayed.
Touch the desired folder number. The
changer will start playing the first file of
the selected folder.
: By touching this button, the list moves
up by 6 folder groups. If this button is
touched when the top page of the list is dis-
played, the last page is displayed.
: By touching this button, the list moves
down by 6 folder groups. If this button is
touched when the last page of the list is
displayed, the top page is displayed.
“FILE”: The file list is displayed.
“DETAIL”: Details of the file currently
playing is displayed. This function is avail-
able only when the vehicle is not moving.

AUDIO SYSTEM
165

Selecting a desired file
“TUNE·SEEK/TRACK” button: Use for
direct access to a desired file.
Push
“
” or “” sides of the
“TUNE·SEEK/TRACK” button and repeat
it until the desired file number appears on
the display. As you release the button, the
CD player will start playing the selected file
from the beginning. When “RAND” or
“FLD.RPT” is on, the file number within the
folder you are currently being listened to
appears.
Fast forward: Push “
” sides of the
“TUNE·SEEK/TRACK” button and hold it
to fast forward the disc. When you release
the button, the CD player will resume play-
ing from that position.
Reverse: Push “
” sides of the
“TUNE·SEEK/TRACK” button and hold it
to reverse the disc. When you release the
button, the CD player will resume playing.
“FILE”: The desired file can be selected in
a list. This function is available only when
the vehicle is not moving.
Touch “FILE” . The file list is displayed.

AUDIO SYSTEM
166
Touch the desired file number. The CD
player will start playing the selected file
from the beginning.
: By touching this button, the list moves
up by 6 file groups. If this button is touched
when the top page of the list is displayed,
the last page is displayed.
: By touching this button, the list moves
down by 6 file groups. If this button is
touched when the last page of the list is
displayed, the top page is displayed.
“FOLDER”: The folder list is displayed.
“DETAIL”: Details of the file currently
playing is displayed. This function is avail-
able only when the vehicle is not moving.
Searching for a desired file
While the disc is playing, touch
“SCAN” briefly.
“SCAN” appears on the screen. The
changer will play the next file in the folder
for 10 seconds, then scan again. To select
a file, touch “SCAN” once again. If the
changer reaches the end of the folder, it
will start playing from file 1.
After all the files are scanned in one pass,
normal play resumes.

AUDIO SYSTEM
167

Searching for a desired folder
While the disc is playing, touch
“SCAN” and hold it until the
“FLD.SCAN” appears on the screen.
The program at the beginning of each fold-
er will be played for
10 seconds. To contin-
ue listening to the program of your choice,
touch “SCAN” once again.
After all the folders are scanned in one
pass, normal play resumes.
Other functions
“RPT”: Use it for automatic repeat of the
file or folder you are currently listening to.
Repeating a file —
While the file is playing, touch“RPT”
briefly.
“RPT” appears on the screen. When the
file is finished, the CD player will automati-
cally go back to the beginning of the file
and play the file again. To cancel it, touch
“RPT” once again.
Repeating a folder —
While the folder is playing, touch “RPT”
and hold it until the “FLD.RPT” appears
on the screen.
When the folder is finished, the CD player
will automatically go back to the beginning
of the folder and play the folder again. To
cancel it, touch “RPT” once again.

AUDIO SYSTEM
168
“RAND”: Use it for automatic and random
selection of the folder or the disc which you
are currently listening to.
Playing the files in one folder in random
order —
While the disc is playing, touch
“RAND” briefly.
“RAND” appears on the screen. The sys-
tem selects a file in the folder you are cur-
rently listening to. To cancel it, touch
“RAND” once again.
Playing the files in all the folders on one
disc in random order —
While the disc is playing, touch
“RAND” and hold it until the
“FLD.RAND” appears on the screen.
The system selects a file in all the folders.
To cancel it, touch the button once again.
When a file is skipped or the system is in-
operative, touch “RAND” to reset. (f) If the player malfunctions
If the player or another unit equipped with
the player malfunctions, your audio sys-
tem will display following messages.
If “No CD” appears on the display:
It in-
dicates that there is no disc in the CD play-
er.
If “CD Check” appears on the display:
It indicates that the disc dirty, damaged, or
it was inserted upside down. Clean the
disc or insert it correctly. If a disc which is
not playable is inserted, “CD Check” will
also appear on the screen. For appropri-
ate discs for this player, see “Audio system
operating hints” on page 170.
If “CD Error” appears on the display:
The following causes are possible.
There is a trouble inside the system.
Eject the disc.
The inside of the player unit may be too
hot due to the very high ambient tem-
perature. Eject the disc and allow the
player to cool down.
If “NO MUSIC FILE” appears on the dis-
play: It indicates that the disc has no play-
able data.
If the malfunction is not rectified: Take
your vehicle to your dealer.
If an MP3/WMA disc contains CD −DA
files, only CD−DA files are played. If an
MP3/WMA disc contains files other than
CD−DA, only MP3/WMA files are played.

AUDIO SYSTEM
169
Some parts of the audio system can be ad-
justed with the switches on the steering
wheel.
Details of the specific switches, controls,
and features are described below.
1Volume control switch
2“” “” switches
3“MODE” switch
1Volume control switch
Push “+” side to increase the volume. The
volume continues to increase while the
switch is being pressed.
Push “” side to decrease the volume.
The volume continues to decrease while
the switch is being pressed.
2“” “” switches
Radio
To select a preset station:
Quickly push and release the “
” or “”
switch. Do this again to select the next pre-
set station.
To seek a station:
Push and hold the “
” or “” switch until
you hear a beep. Do this again to find the
next station. If you push either the “
” or
“” switch in seek mode, the seek mode
will cancel.
CD player
Use this button to skip up or down to a dif-
ferent track or file in either direction.
To select a desired track or file:
Quickly push and release the “
” or “”
switch until the track or file you want to play
is set. If you want to return to the beginning
of the current track or file, push the “
”
switch once, quickly.
3“MODE” switch
Each time you push the “MODE” switch,
the system changes the audio mode.
To turn the audio system on, push the
“MODE” switch.
To turn the audio system off, push and hold
the “MODE” switch until you hear a beep.
Audio remote controls —
— Steering switches

AUDIO SYSTEM
170
NOTICE
To ensure correct audio system op-
erations:
Be careful not to spill beverages
over the audio system.
Do not put anything other than ap-
propriate discs into the CD player.
The use of a cellular phone inside
or near the vehicle may cause a
noise from the speakers of the
audio system which you are
listening to. However, this does
not indicate a malfunction.
Radio reception
Usually, the problem with radio reception
does not mean there is a problem with your
radio − it is just the normal result of condi-
tions outside the vehicle.
For example, nearby buildings and terrain
can interfere with FM reception. Power
lines or telephone wires can interfere with
AM signals. And of course, radio signals
have a limited range, and the farther you
are from a station, the weaker its signal will
be. In addition, reception conditions
change constantly as your vehicle moves.
Here are some common reception prob-
lems that probably do not indicate a prob-
lem with your radio: FM
Fading and drifting stations — General-
ly, the effective range of FM is about 25
miles (40 km). Once outside this range,
you may notice fading and drifting, which
increase with the distance from the radio
transmitter. They are often accompanied
by distortion.
Multipath
— FM signals are reflective,
making it possible for two signals to reach
your antenna at the same time. If this hap-
pens, the signals will cancel each other
out, causing a momentary flutter or loss of
reception.
Static and fluttering — These occur
when signals are blocked by buildings,
trees, or other large objects. Increasing
the bass level may reduce static and flut-
tering.
Station swapping — If the FM signal you
are listening to is interrupted or weakened,
and there is another strong station nearby
on the FM band, your radio may tune in the
second station until the original signal can
be picked up again.
AM
Fading — AM broadcasts are reflected by
the upper atmosphere — especially at
night. These reflected signals can inter-
fere with those received directly from the
radio station, causing the radio station to
sound alternately strong and weak.
Station interference — When a reflected
signal and a signal received directly from
a radio station are very nearly the same
frequency, they can interfere with each
other, making it difficult to hear the broad-
cast.
Static — AM is easily affected by external
sources of electrical noise, such as high
tension power lines, lightening, or electri-
cal motors. This results in static.
Audio system operating
hints
