fuel type TOYOTA RAV4 2015 XA40 / 4.G Owners Manual

17Pictorial index
RAV4_OM_OM42A78U_(U)Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 229
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 287
To prevent freezing (windshield wiper de-icer)
*. . . . . . . . . . . . P. 318
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 237
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 237
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 662
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 551
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . P. 669
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 287
Checking/rotation/tire pressure warning system
*. . . . . . . . P. 551
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 627
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 533
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 533
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 663
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 653
Camera
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 259
Headlights/daytime running lights . . . . . . . . . . . . . . . . . . . . P. 217
Parking lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
Fog lights
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 228
Turn signal lights
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 214
Tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
Stop/tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 207
Side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
4
5
6
7
8
Light bulbs of the exterior lights for driving
(Replacing method: P. 584, Watts: P. 670)
*: If equipped
9
10
11
12
13
14
15
16
17

RAV4_OM_OM42A78U_(U)
1674-1. Before driving
4
Driving
■Drum-in-disc type parking brake system
Your vehicle has a drum-in-disc type parking brake system. This type of brake
system needs bedding-down of the brake shoes periodically or whenever the
parking brake shoes and/or drum are replaced. Have your Toyota dealer per-
form the bedding down operation.
■ Operating your vehicle in a foreign country
Comply with the relevant vehicle registration laws and confirm the availability
of the correct fuel. ( P. 671)
■ Eco Driving Indicator
Eco Driving Indicator Zone Display availability can be customized at your
Toyota dealer. The default setting is off.
Zone of Eco driving
Eco driving ratio based on acceleration
If the acceleration exceeds Zone of Eco driving, the right side of Eco Driv-
ing Indicator Zone Display blinks.
Eco Driving Indicator will not operate in the following conditions:
● The shift lever is anything other than D.
● Neither normal mode nor Eco drive mode is selected. ( P. 209)
● The vehicle speed is approximately 80 mph (130 km/h) or higher.
Suggests Zone of Eco driving and Eco
driving ratio based on acceleration.
Eco Driving Indicator Light
During Eco-friendly acceleration (Eco
driving), Eco Driving Indicator Light will
turn on.
When the acceleration exceeds Zone of
Eco driving, or when the vehicle is
stopped, the light turns off.
Eco Driving Indicator Light availability
can be customized. The default setting
is on. ( P. 90)
Eco Driving Indicator Zone Display
1
2
3
4

237
RAV4_OM_OM42A78U_(U)
4-4. Refueling
4
Driving
Opening the fuel tank cap
●Close all the doors and windows, and turn the engine switch to the
“LOCK” position (vehicles without a smart key system) or off (vehi-
cles with a smart key system).
● Confirm the type of fuel.
■Fuel types
Unleaded gasoline (Octane rating 87 [Research Octane Number 91] or
higher)
Perform the following steps to open the fuel tank cap:
Before refueling the vehicle

662
RAV4_OM_OM42A78U_(U)
8-1. Specifications
■Engine number
The engine number is stamped
on the engine block as shown.
Engine
Model2.5 L 4-cylinder (2AR-FE)
Ty p e4-cylinder in line, 4-cycle, gasoline
Bore and stroke3.54  3.86 in. (90.0  98.0 mm)
Displacement152.2 cu.in. (2494 cm3)
Valve clearanceAutomatic adjustmentDrive belt tension
Fuel
Fuel typeUnleaded gasoline only
Octane Rating87 (Research Octane Number 91) or higher
Fuel tank capacity
(Reference)15.9 gal. (60 L, 13.2 Imp.gal.)

672
RAV4_OM_OM42A78U_(U)
8-1. Specifications
■Recommendation of the use of gaso line containing detergent additives
● Toyota recommends the use of gasoline that contains detergent additives to
avoid the build-up of engine deposits.
● All gasoline sold in the U.S.A. contains minimum detergent additives to
clean and/or keep clean intake systems, per EPA’s lowest additives concen-
tration program.
● Toyota strongly recommends the use of Top Tier Detergent Gasoline. For
more information on Top Tier Detergent Gasoline and a list of marketers,
please go to the official website www.toptiergas.com.
■ Recommendation of the use of cleaner burning gasoline
Cleaner burning gasoline, including reformulated gasoline that contains oxy-
genates such as ethanol or MTBE (Methyl Tertiary Butyl Ether) is available in
many areas.
Toyota recommends the use of cleaner burning gasoline and appropriately
blended reformulated gasoline. These types of gasoline provide excellent
vehicle performance, reduce vehicle emissions and improve air quality.
■ Non-recommendation of the use of blended gasoline
●If you use gasohol in your vehicle, be sure that it has an octane rating no
lower than 87.
● Toyota does not recommend the use of gasoline containing methanol.
●
Use only gasoline containing up to 15%
ethanol.
DO NOT use any flex-fuel or gasoline
that could contain more than 15% etha-
nol, including from any pump labeled
E30, E50, E85 (which are only some
examples of fuel containing more than
15% ethanol).
DO NOT use gasoline
containing more than
15% ethanol.
(30% ethanol)
(50% ethanol)
(85% ethanol)

RAV4_OM_OM42A78U_(U)
6738-1. Specifications
8
Vehicle specifications
■Non-recommendation of the use of gasoline containing MMT
Some gasoline contains an octane enhancing additive called MMT (Methylcy-
clopentadienyl Manganese Tricarbonyl).
Toyota does not recommend the use of gasoline that contains MMT. If fuel
containing MMT is used, your emission control system may be adversely
affected.
The malfunction indicator lamp on the instrument cluster may come on. If this
happens, contact your Toyota dealer for service.
■ If your engine knocks
●Consult your Toyota dealer.
● You may occasionally notice light knocking for a short time while accelerat-
ing or driving uphill. This is normal and there is no need for concern.
NOTICE
■Notice on fuel quality
● Do not use improper fuels. If improper fuels are used, the engine will be
damaged.
● Do not use leaded gasoline.
Leaded gasoline can cause damage to your vehicle’s three-way catalytic
converters causing the emission control system to malfunction.
● Do not use gasohol other than the type previously stated.
Other gasohol may cause fuel system damage or vehicle performance
problems.
● Using unleaded gasoline with an octane number or rating lower than the
level previously stated will cause persistent heavy knocking.
At worst, this will lead to engine damage.
■ Fuel-related poor driveability
If poor driveability is encountered after using a different type of fuel (poor
hot starting, vaporization, engine knocking, etc.), discontinue the use of that
type of fuel.
■ When refueling with gasohol
Take care not to spill gasohol. It can damage your vehicle’s paint.

721Alphabetical index
RAV4_OM_OM42A78U_(U)
Entune Audio Plus*EPS (Electronic Power Steering)................................. 272 Function ................................ 272
Warning light ......................... 613
Event data recorder (EDR) ........ 11
Flat tire...................................... 627
Floor mats .................................. 26
Fluid Automatic transaxle .............. 667
Brake .................................... 668
Washer ................................. 550
Fog lights ................................. 228 Replacing light bulbs............. 592
Switch ................................... 228
Wattage ................................ 670
Front passenger occupant classification system .............. 51
Front passenger’s seat belt reminder light ................. 615
Front seats ............................... 136
Adjustment ............................ 136
Cleaning................................ 516
Correct driving posture ........... 28
Driving position memory ....... 142
Head restraints ..................... 146
Seat heaters ......................... 506
Seat position memory ........... 142
Front side marker lights.......... 217 Light switch ........................... 217
Replacing light bulbs............. 591
Wattage ................................ 670
Front turn signal lights ........... 214 Replacing light bulbs............. 590
Turn signal lever ................... 214
Wattage ................................ 670 Fuel ........................................... 662
Capacity................................ 662
Fuel gauge.............................. 85
Fuel pump shut off system .......... ...................... 610
Information............................ 671
Refueling .............................. 237
Type.............................. 237, 662
Warning light......................... 615
Fuel consumption information .............................. 92
Fuel filler door ......................... 237 Refueling .............................. 237
Fuel pump shut off system..... 610
Fuses ........................................ 573
Gauges ....................................... 85
Glove box ................................. 490
Grocery bag hooks.................. 494
Hands-free system
(for cellular phone) ....... 364, 442
HD Radio
® system*
Head restraints ........................ 146
Headlights ................................ 217 Automatic High Beam ........... 221
Light switch ........................... 217
Replacing light bulbs .... 586, 588
Wattage ................................ 670
Heaters Automatic air conditioning
system .......... ...................... 306
Manual air conditioning system .......... ...................... 300
Seat heaters ......................... 506
Outside rear view mirrors ..... 316
F
G
H
*: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

725Alphabetical index
RAV4_OM_OM42A78U_(U)
Refueling .................................. 237Capacity ................................ 662
Fuel types ..................... 237, 662
Opening the fuel tank cap ..... 239
Replacing
Electronic key battery ........... 570
Fuses .................................... 573
Light bulbs ............................ 584
Tires ...................................... 627
Wireless remote control battery ................................ 570
Reporting safety defects for U.S. owners ...................... 698
Resetting the maintenance
required reminder light ......... 521
Seat belts.................................... 30 Adjusting the seat belt ............ 33
Automatic Locking Retractor............................... 34
Child restra int system
installation ............................ 63
Cleaning and maintaining the seat belt ........................ 517
Emergency Locking Retractor............................... 34
How to wear your seat belt ..... 30
How your child should wear the seat belt ................. 34
Pregnant women, proper seat belt use ......................... 35
Reminder light and buzzer .... 615
Seat belt extender................... 34
Seat belt instructions for Canadian owners ............... 699
Seat belt pretensioners ........... 33
SRS warning light ................. 612
Seat heaters ............................. 506
Seat position memory ............. 142
Seating capacity ...................... 180 Seats ................................. 136, 138
Adjustment.................... 136, 138
Adjustment
precautions................. 137, 140
Child seats/child restraint
system installation ................ 63
Cleaning ............................... 516
Driving position memory ....... 142
Folding down the rear seatbacks ........................... 139
Head restraint ....................... 146
Properly sitting in the seat ...... 28
Seat heaters ......................... 506
Seat position memory ........... 142
Sensor Automatic headlight system .......... ...................... 219
Inside rear view mirror .......... 152
Intuitive parking assist .......... 253
LDA (Lane Departure Alert)................................... 245
Service reminder indicators ..... 80
Shift lever Automatic transmission ........ 207
If the shift lever cannot be shifted from P ..................... 645
Shift lock system ..................... 645
Shopping bag hooks ............... 494
Side airbags ............................... 38
Side marker lights ................... 217
Light switch ........................... 217
Replacing light bulbs .... 591, 594
Wattage ................................ 670
S
*: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

732
RAV4_OM_OM42A78U_(U)
GAS STATION INFORMATION
Auxiliary catch leverFuel filler door
P. 533
P. 239
Hood lock release leverFuel filler door openerTire inflation pressure
P. 533 P. 239P. 669
Fuel tank capacity
(Reference)15.9 gal. (60 L, 13.2 Imp.gal.)
Fuel typeUnleaded gasoline with an Octane Rating of 87
(Research Octane Number 91) or higher
P. 237, 662
Cold tire inflation
pressure P. 6 6 9
Engine oil capacity
(Drain and refill —
reference)qt. (L, Imp.qt.)
With filter 4.6 (4.4, 3.9)
Without filter 4.2 (4.0, 3.5)
Engine oil type “Toyota Genuine Motor Oil” or equivalent
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
P. 663
