engine coolant TOYOTA RAV4 2023 Owner's Manual

4817-2. Steps to take in an emergency
7
When trouble arises
3After the engine has cooled
down sufficiently, inspect the
hoses and radiator core (radi-
ator) for any leaks.
Radiator
Cooling fan
If a large amount of coolant leaks,
immediately contact your Toyota
dealer.
4The coolant level is satisfac-
tory if it is between the
“FULL” and “LOW” lines on
the reservoir.
Reservoir
“FULL” line
“LOW” line
5 Add coolant if necessary.
Water can be us ed in an emer-
gency if coolant is unavailable.
If water was added in an emer-
gency, have the vehicle inspected at your Toyota dealer as soon as
possible.
6
Start the engine and turn the
air conditioning system on to
check that the radiator cool-
ing fan operates and to check
for coolant leaks from the
radiator or hoses.
The fan operates when the air con-
ditioning system is turned on imme-
diately after a cold start. Confirm
that the fan is operating by check-
ing the fan sound and air flow. If it is
difficult to check th ese, turn the air
conditioning system on and off
repeatedly. (The fa n may not oper-
ate in freezing temperatures.)
7 If the fan is not operating:
Stop the engine immediately
and contact your Toyota
dealer.
If the fan is operating:
Have the vehicle inspected at
the nearest Toyota dealer.
8 Check if “Engine Coolant
Temp High Stop in a Safe
Place See Owner’s Manual”
is shown on the multi-infor-
mation display.
If the message does not disappear:
Stop the engine and contact your
Toyota dealer.
If the message is not displayed:
Have the vehicle inspected at the
A
B
A
B
C

4827-2. Steps to take in an emergency
nearest Toyota dealer.
1Stop the engine. Set the
parking brake and shift the
shift lever to P.
2 Remove the mud, snow or
sand from around the stuck
tire.
3 Place wood, stones or some
other material to help provide
traction under the tires.
4 Restart the engine.
5 Shift the shift lever to D or R
and release the parking
brake. Then, while exercising
caution, depress the acceler-
ator pedal.
■When it is difficult to free the
vehicle
Press to turn off TRAC.
(  P.320)
WARNING
■When inspecting under the
hood of your vehicle
Observe the following precau-
tions.
Failure to do so may result in seri-
ous injury such as burns.
●If steam is seen coming from
under the hood, do not open the
hood until the steam has sub-
sided. The engine compart-
ment may be very hot.
●Keep hands and clothing (espe-
cially a tie, a scarf or a muffler)
away from the fan and belts.
Failure to do so m ay cause the
hands or clothing to be caught,
resulting in serious injury.
●Do not loosen the coolant reser-
voir cap while the engine and
radiator are hot. High tempera-
ture steam or coolant could
spray out.
NOTICE
■When adding engine coolant
Add coolant slowly after the
engine has cooled down suffi-
ciently. Adding cool coolant to a
hot engine too quickly can cause
damage to the engine.
■To prevent damage to the
cooling system
Observe the following precau-
tions:
●Avoid contaminating the coolant
with foreign matter (such as
sand or dust etc.).
●Do not use any coolant additive.
If the vehicle becomes
stuck
Carry out the following pro-
cedures if the tires spin or
the vehicle becomes stuck
in mud, dirt or snow:
Recovering procedure

4898-1. Specifications
8
Vehicle specifications
Outside temperature
Oil viscosity (0W-16 is explained
here as an example):
• The 0W in 0W-16 indicates the characteristic of the oil
which allows cold startability.
Oils with a lower value before
the W allow for easier starting
of the engine in cold weather.
• The 16 in 0W-16 indicates the viscosity characteristic of the oil when the oil is at high tem-
perature. An oil with a higher
viscosity (one with a higher
value) may be better suited if
the vehicle is operated at high
speeds, or under extreme
load conditions.
How to read oil container label:
API registered mark is added to
some oil containers to help you
select the oil you should use.
*: The coolant capacity is the quantity of reference. If replacement is necessary, contact y our Toyota dealer.
A
Cooling system
Capacity*
Without engine oil
cooler7.3 qt. (6.9 L, 6.1 Imp. qt.)
With engine oil
cooler7.4 qt. (7.0 L, 6.2 Imp. qt.)
Coolant type
Use either of the following:
“Toyota Super Long Life Coolant”
 Similar high-quality ethylene gly-
col-based non-silicate, non-amine,
non-nitrite, and non-borate cool-
ant with long-life hybrid organic
acid technology
Do not use plain water alone.

5038-1. Specifications
8
Vehicle specifications
■Temperature A, B, C
The temperature grades are A
(the highest), B, and C, repre-
senting the tire’s resistance to
the generation of heat and its
ability to dissipate heat when
tested under controlled condi-
tions on a specified indoor labo-
ratory test wheel.
Sustained high temperature can
cause the material of the tire to
degenerate and reduce tire life, and
excessive temperature can lead to
sudden tire failure.
Grade C corresponds to a level of performance which all passenger
car tires must meet under the Fed-
eral Motor Vehicle Safety Standard
No. 109.
Grades B and A represent higher
levels of performance on the labo-
ratory test wheel than the minimum
required by law.
Warning: The temperature grades
of a tire assume tha
t it is properly
inflated and not overloaded.
Excessive speed, underinflation, or
excessive loading, either sepa-
rately or in combination, can cause
heat buildup and possible tire fail-
ure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sureTire pressure when the vehicle has been parked
for three hours or more, or has not been driven
more than 1 mile or 1.5 km under that condition
Maximum inflation pres-
sureThe maximum cold inflated pressure to which a
tire may be inflated, shown on the sidewall of
the tire
Recommended inflation
pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weight
The combined weight (in excess of those stan-
dard items which may be replaced) of transmis-
sion, power steering, power brakes, power
windows, power seats, radio and heater, to the
extent that these items are available as factory-
installed equipment (whether installed or not)
Curb weight
The weight of a motor vehicle with standard
equipment, including th e maximum capacity of
fuel, oil and coolant, and if so equipped, air con-
ditioning and additional weight optional engine

546Alphabetical Index
Dynamic radar cruise control with full-speed rangeFunction ............................... 264
Warning message ................ 459
Dynamic Torque Control AWD system ................................... 319
Dynamic Torque Vectoring AWD system ................................... 319
E
Eco drive mode ...................... 310
Eco Driving Indicator ....... 96, 105
Eco Driving Indicator Light ... 96, 105
EDR (Event data recorder)......... 8
Elapsed time ............................. 97
Electric Power Steering (EPS) Function ............................... 319
Warning light ........................ 451
Electronic key Battery-saving function......... 141
If the electronic key does not operate properly ................. 474
Replacing the battery ........... 425
Electronic sunshade .............. 173 Jam protection function ........ 174
Operation ............................. 173
Emergency, in case of If a warning buzzer sounds .. 449
If a warning light turns on ..... 449
If a warning message is dis-played................................. 459
If the electronic key does not operate properly ................. 474
If the engin e will not start ..... 472
If the vehicle battery is dis- charged .............................. 476
If the vehicle is submerged or water on the road is rising .. 441
If you have a flat tire ............. 463
If you lose your keys ............ 474
If you think something is wrong ...........................................447
If your vehicle becomes stuck ...........................................482
If your vehicle has to be stopped in an emergency .................440
If your vehicle needs to be towed ...........................................443
If your vehicle ove rheats ......480
Emergency flashers ...............440
Engine Compartment........................398
Engine switch ...............203, 204
Fuel pump shut off system ...448
Hood .....................................395
How to start the engine 203, 204
Identification number ............487
If the engine will not start......472
If your vehicle has to be stopped in an emergency .................440
Ignition switch (Engine switch) ...................................203, 204
Overheating ..........................480
Tachometer ......................83, 88
Engine coolant Capacity ...............................489
Checking ..............................400
Preparing and checking before winter ..................................325
Warning light ........................450
Engine coolant temperature ..83, 88
Engine immobilizer system .....70
Engine oil Capacity ...............................488
Checking ..............................398
Preparing and checking before winter ..................................325
Warning light ........................450
Engine switch .................203, 204 Auto power off fun ction.........207
Changing the engine switch modes.................................207

Alphabetical Index555
Trailer towing .......................... 189
TransmissionAutomatic transmission ........ 209
Driving mode select switch... 310
S mode ................................. 211
Trip meters .......................... 83, 92
Turn signal lights Replacing light bulbs ............ 432
Turn signal lever................... 212
Wattage ................................ 496
U
USB charging ports................ 361
Utility vehicle precautions ..... 328
V
Vanity lightsVanity lights .......................... 359
Vanity mirrors ......................... 359
Vehicle data recordings ............. 7
Vehicle identification number487
Vehicle Stability Control (VSC) ............................................... 318
Ventilators (seat ventilators) . 345
VSC (Vehicle Stability Control) ............................................... 318
W
Warning buzzers Approach warning ................ 271
Brake hold ............................ 454
Brake Override System ........ 454
Brake system ....................... 449
Downshifting......................... 212
Drive-Start Control ............... 454
Electric power steering ......... 451
High coolant temperature ..... 450
Intuitive parking assist OFF indi-cator ................................... 452
Intuitive parking assist .......... 280 Low engine oil pressure .......450
LTA (Lane Tracing Assist) ..250,
452
LTA indicator ........................452
Open door ............................124
Open hood............................124
Open window........................168
PKSB OFF indicator .............453
Pre-collision warn ing ............451
RCTA OFF indicator .............453
Seat belt reminder ........455, 456
Vehicle sway warning ...........254
Warning lights ABS ......................................451
Brake hold operated indicator...........................................454
Brake Override System ........454
Brake system ........................449
Charging system ..................449
Drive-Start Control ................454
Electric power steering .........451
Engine ..................................450
High coolant temperature .....450
Inappropriate pedal operation ...........................................454
Intuitive parking assist OFF indi- cator ...................................452
Low engine oil pressure .......450
Low fuel level........................455
LTA indicator ........................452
Malfunction indica tor lamp ....450
Parking brake indicator.........454
PCS warning light .................451
PKSB (Parking Support Brake) ...........................................453
PKSB OFF indicator .............453
RCTA OFF indicator .............453
Seat belt reminder light 455, 456
Slip indicator .........................453
SRS ......................................450
Stop & Start cancel indicator 452
Tire pressure ...... ..................455
