82 1-3. Charging
■Pre-climate operations automatic shut-off
Pre-climate will automatically shut off under the following conditions:
●After about 15 minutes have passed since operations began
● If any one of the operating conditions are not met
● If there is only a slight difference between the air conditioning set temper-
ature and the inside temperature.
● When a door is opened.
■ While pre-climate is operating
●The effectiveness of the pre-climate operations may differ according to
outside temperature. Pre-climate operations may be unable to reach the
set temperature during very cold or very hot weather.
● Sometimes during normal operation of the pre-climate schedule, the
electric fan may spin and an operating noise may be heard. However,
this does not indicate a malfunction.
■ Safety functions
●For safety purposes, the EV system cannot be started while the charging
cable is connected to the vehicle, even if the “POWER” switch is oper-
ated. ( P. 443)
● If the charging cable is connected while the “READY” indicator light is\
illuminated, the EV system will stop automatically and driving will not be
possible. ( P. 443)
● When the charging cable is connected to the vehicle, the shift position
cannot be shifted out of P.
● For safety reasons, even if the charging cable is connected, charging will
not start while the latch release button is being pressed.
However, if the latch release button is pressed and held for a few seconds or
more while charging, charging will be canceled. To recommence charging,
reinsert the charging cable.

515
Alphabetical index
Safety Connect ........................ 326
Seat belts
Adjusting the seat belt .......... 131
Automatic Locking Retractor ............................ 134
Child restraint system installation .......................... 176
Cleaning and maintaining
the seat belts...................... 338
Emergency Locking Retractor ............................ 120
How to wear your seat belt ... 131
How your child should wear the seat belt ....................... 135
Pregnant women, proper seat belt use ........... 136
Reminder light ...................... 419
Seat belt extenders .............. 135
Seat belt pretensioners ........ 134
Seat heaters ............................. 310
Seating capacity ...................... 267
Seats Adjustment ................... 118, 121
Adjustment
precaution .................. 120, 125
Child seats/child restraint
system installation.............. 176
Cleaning ............................... 337
Head restraints ..................... 127
Properly sitting in the seat .... 152
Seat heaters ......................... 310
Service reminder
indicators .............................. 223
Shift lever Transmission ........................ 206
Side airbags ............................. 154
Side marker lights Replacing light bulbs ............ 400
Switch ................................... 234
Wattage ................................ 488
Side mirrors
Adjusting and folding ............ 143 Side turn signal lights
Replacing light bulb ...............400
Wattage .................................488
Smart key system Entry function ..........................96
Starting the EV system..........200
“SOS” button............................326
Specifications...........................482
Speedometer ............................218
Steering Column lock release..............204
Steering wheel Adjustment ............................140
Stop lights
Replacing light bulbs .............400
Storage feature.........................296
Storage precautions ................265
Stuck If your vehicle becomes stuck ...................................477
Sun visors.................................304
Switch Cruise control ........................243
“DISP” switch ........................227
Emergency flasher switch .....412
Hazard light switch ................412
Light switches........................234
Power door lock switch .........110
“POWER” switch ...................200
Power window switches ........146
SPORT mode switch .............208
VSC OFF switch....................252
Window lock switch ...............146
Wiper and washer switch ..........................238, 241S
