TOYOTA RAV4 HYBRID 2021 (in English) Owner's Manual

21Pictorial index
■Switches
Driving position memory switches*.................................P.156
Window lock switch ............................................. ..............P.178
Power window switches ....... .............................................P.176
Door lock switches ............................................................P.131
Outside rear view mirror swi tches ...................................P.174
“ODO TRIP” switch .............................................. ........P.96, 101
Instrument panel light cont rol dial .............................P.96, 102
Automatic High Beam switch ..................................... ......P.232
Windshield wiper de-icer switch
*.....................................P.529
Camera switch
*............................................................... ....P.336
Heated steering wheel switch
*..........................................P.531
Power back door switch
*...................................................P.137
*: If equipped
A
B
C
D
E
F
G
H
I
J
K
L

22Pictorial index
Meter control switches ......................................................P.104
Vehicle-to-vehicle distance switch ...................................P.277
Cruise control switches
Dynamic radar cruise control with full-speed range ............. P.271
Audio remote control switches
*.......................................P.454
LTA (Lane Tracing Assist) sw itch ....................................P.258
Phone switch
*............................................................... ......P.482
Talk switch
*............................................................... ..........P.470
*: Vehicles with Audio Plus or Premium Audio, refer to “NAVIGATION AND
MULTIMEDIA SYSTEM O WNER’S MANUAL”.
A
B
C
D
E
F
G

23Pictorial index
VSC OFF switch .................................................................P.370
Front seat heater switches
*...............................................P.531
Front seat heater/seat ventilator switches
*.....................P.532
Parking brake switch ........................................... ..............P.224
Applying/releasing............................................. ...................P.224
Precautions against winter season .............................. ........P.379
Warning buzzer/message ... .........................................P.648, 654
Brake hold switch .............................................. ................P.227
Trail Mode switch ...............................................................P.367
Driving mode select switch ..................................... ..........P.366
EV drive mode switch ........................................... .............P.217
*: If equipped
A
B
C
D
E
F
G
H

24Pictorial index
■Interior
SRS airbags .................................................... ......................P.35
Floor mats..................................................... ........................P.28
Front seats .................................................... ......................P.153
Rear seats ..................................................... ......................P.154
Head restraints ...................................................................P.159
Seat belts ..................................................... .........................P.31
Console box .................................................... ...................P.538
Inside lock buttons ............................................ ................P.131
Cup holders ........................................................................P.538
Assist grips ................................................... .....................P.556
Rear seat heater switches
*................................................P.531
*: If equipped
A
B
C
D
E
F
G
H
I
J
K

25Pictorial index
■Ceiling
“SOS” button*1............................................................... ......P.67
Auxiliary box .................................................. ....................P.539
Moon roof switches
*1.........................................................P.179
Interior lights
*2............................................................... ....P.534
Personal lights ................................................ ...................P.535
Electronic sunshade switch
*1...........................................P.182
Vanity mirrors.....................................................................P.546
Sun visors..................................................... ......................P.546
Inside rear view mirror
*1....................................................P.163
Digital Rear-view Mirror
*1..................................................P.165
Garage door opener switches
*1........................................P.557
*1: If equipped
*2: The illustration shows the fron t, but they are also equipped i n the rear.
A
B
C
D
E
F
G
H
I

26Pictorial index

27
1
1
For safety and security
For safety and security
1-1. For safe useBefore driving ................. 28
For safe driving .............. 29
Seat belts ....................... 31
SRS airbags ................... 35
Front passenger occupant classification system .... 45
Exhaust gas precautions 50
1-2. Child safety Riding with children ........ 51
Child restraint systems... 52
1-3. Emergency assistance Safety Connect .............. 67
1-4. Hybrid system Hybrid system features .. 72
Hybrid system precautions ..................................... 76
1-5. Theft deterrent system Immobilizer sys tem ........81
Alarm.............................. 84

281-1. For safe use
1-1.For safe use
Use only floor mats designed
specifically for vehicles of the
same model and model year as
your vehicle. Fix them securely
in place onto the carpet.
1 Insert the retaining hooks
(clips) into the floor mat eye-
lets.
2 Turn the upper knob of each
retaining hook (clip) to secure
the floor mats in place.
Always align the marks . The shape of the retaining hooks
(clips) may differ from that shown in
the illustration.
Before driving
Observe the following
before starting off in the
vehicle to ensure safety of
driving.
Installing floor mats
A
WARNING
Observe the following precau-
tions.
Failure to do so may cause the
driver’s floor mat to slip, possibly
interfering with t
he pedals while
driving. An unexpectedly high
speed may result or it may
become difficult to stop the vehi-
cle. This could lead to an acci-
dent, resulting in death or serious
injury.
■When installing the driver’s
floor mat
●Do not use floor mats designed
for other models or different
model year vehicles, even if
they are Toyota Genuine floor
mats.
●Only use floor mats designed
for the driver’s seat.
●Always install the floor mat
securely using the retaining
hooks (clips) provided.
●Do not use two or more floor
mats on top of each other.
●Do not place the floor mat bot-
tom-side up or upside-down.

291-1. For safe use
1
For safety and security
Adjust the angle of the seat-
back so that you are sitting
straight up and so that you do
not have to lean forward to
steer. (P.153)
Adjust the seat so that you
can depress the pedals fully
and so that your arms bend
slightly at the elbow when
gripping the steering wheel.
( P.153)
Lock the head restraint in
place with the center of the
head restraint closest to the
top of your ears. ( P.159)
Wear the seat belt correctly.
( P.32)
WARNING
■Before driving
●Check that the floor mat is
securely fixed in the correct
place with all the provided
retaining hooks (clips). Be espe-
cially careful to perform this
check after cleaning the floor.
●With the hybrid system stopped
and the shift lever in P, fully
depress each pedal to the floor
to make sure it does not inter-
fere with the floor mat.
For safe driving
For safe driving, adjust the
seat and mirror to an appro-
priate position before driv-
ing.
Correct driving posture
A
B
C
D

301-1. For safe use
Make sure that all occupants are
wearing their seat belts before
driving the vehicle. (P.32)
Use a child restraint system
appropriate for the child until the
child becomes large enough to properly wear the vehicle’s seat
belt. (
P.52)
Make sure that you can see
backward clearly by adjusting
the inside rear view mirror (if
equipped), Digital Rear-view
Mirror (if equipped) and outside
rear view mirrors properly.
( P.163, 165, 174)
WARNING
Observe the following precau-
tions.
Failure to do so m ay result in
death or serious injury.
●Do not adjust the position of the
driver’s seat while driving.
Doing so could cause the driver
to lose control of the vehicle.
●D o n ot pla ce a cu sh ion b etw ee n
the driver or passenger and the
seatback. A cushion may pre-
vent correct pos ture from being
achieved, and reduce the effec-
tiveness of the seat belt and
head restraint.
●Do not place anything under the
front seats.
Objects placed u nder the front
seats may become jammed in
the seat tracks and stop the
seat from locking in place. This
may lead to an accident and the
adjustment mechanism may
also be damaged.
●Always observe the legal speed
limit when driving on public
roads.
●When driving over long dis-
tances, take regular breaks
before you start to feel tired.
Also, if you feel tired or sleepy
while driving, do not force your-
self to continue driving and take
a break immediately.
Correct use of the seat
belts
Adjusting the mirrors
