ad blue TOYOTA RAV4 HYBRID 2021 Owners Manual

4TABLE OF CONTENTS
Status icon ....................390
“Setup” screen .............. 392
5-2. Basic information before operation
Initial screen .................. 393
Touch screen ................ 394
Home screen................. 396
Entering letters and num- bers/list screen operation
.................................... 397
Screen adjustment ........ 400
Linking multi-information dis- play and the system .... 401
5-3. Connectivity settings Registering/Connecting a Bluetooth
® device ....... 402
Setting Bluetooth
® details
.................................... 406
Wi-Fi
® Hotspot .............. 414
5-4. Apple CarPlay/Android Auto
Apple CarPlay
®/Android
Auto
™.......................... 419
5-5. Other settings General settings ............ 426
Voice settings................ 430
Vehicle settings ............. 431
5-6. Using the audio/visual sys- tem
Quick reference............. 432
Some basics ................. 433
5-7. Radio operation AM/FM/SiriusXM (SXM) radio.................................... 437
5-8. Media operation USB memory................. 444iPod/iPhone (Apple CarPlay)
.................................... 446
Android Auto.................. 449
Bluetooth
® audio ........... 450
5-9. Audio/visual remote con- trols
Steering switches .......... 454
5-10.Audio settings Setup ............................. 456
5-11.Tips for operating the
audio/visual system
Operating information .... 458
5-12.Voice command system operation
Voice command system 470
Command list ................ 473
5-13.Mobile Assistant operation Mobile Assistant ............ 477
5-14.Phone operation (Hands- free system for cellular
phones)
Quick reference ............. 479
Some basics .................. 480
Placing a call using the Bluetooth
® hands-free sys-
tem .............................. 484
Receiving a call using the Bluetooth
®hands-free sys-
tem .............................. 487
Talking on the Bluetooth
®
hands-free system ....... 488
Bluetooth
® phone message
function ........................ 490
5-15.Phone settings Setup ............................. 495

5TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9
10
5-16.What to do if... (Bluetooth
®)
Troubleshooting ............ 505
5-17.Connected Services over- view
Connected Services ...... 509
Type A: Function achieved by using a smartphone or DCM.................................... 510
Type B: Function achieved by using DCM and the system
.................................... 512
Type C: Function achieved by using DCM.............. 513
Type D: Function achieved by using DCM and a smart-
phone .......................... 516
5-18.Connected Services opera- tion
Toyota Apps .................. 518
5-19.Setup Toyota Apps settings .... 522
6-1. Using the air conditioning
system and defogger
Automatic air conditioning system ......................... 524
Heated steering wheel/seat heaters/seat ventilators 531
6-2. Using the interior lights Interior lights list ............ 534
6-3. Using the storage features List of storage features . 537
Luggage compartment fea- tures ............................ 5416-4. Using the other interior fea-
tures
Other interior features ... 546
Garage door opener ...... 557
7-1. Maintenance and care Cleaning and protecting the vehicle exterior ............ 566
Cleaning and protecting the vehicle interior ............. 569
7-2. Maintenance Maintenance requirements.................................... 572
General maintenance .... 573
Emission inspection and maintenance (I/M) programs
.................................... 576
7-3. Do-it-yourself maintenance Do-it-yourself service precau-tions ............................. 577
Hood .............................. 579
Positioning a floor jack .. 580
Engine compartment ..... 582
12-volt battery................ 588
Tires .............................. 590
Tire inflation pressure .... 605
Wheels .......................... 607
Air conditioning filter ...... 609
Cleaning the hybrid battery (traction battery) air intake
vent and filter ............... 611
Wiper insert replacement .................................... 615
Wireless remote control/elec- tronic key battery ......... 618
6Interior features
7Maintenance and care

691-3. Emergency assistance
1
For safety and security
(“SOS”)
Connects drivers to response-cen-
ter support. (
P.70)
Enhanced Roadside Assis-
tance
Provides drivers various on-road
assistance. ( 
P.71)
After you have signed the
Telematics Subscription Ser-
vice Agreement and are
enrolled, you can begin receiv-
ing services.
A variety of subscription terms
are available for purchase. Con-
tact your Toyota dealer, call the
following appropriate Customer
Experience Center or push the
“SOS” button in your vehicle for
further subscription details.
The United States
1-800-331-4331
Canada
1-888-869-6828
Puerto Rico
1-877-855-8377
■Safety Connect Services Infor-
mation
●Phone calls using the vehicle’s
Bluetooth® technology will not be
possible when Safety Connect is
active and in use.
●Safety Connect is available begin-
ning Fall 2009 on select Toyota
models (in the contiguous United
States only). Contact with the
Safety Connect response center is dependent upon
the telematics
device being in operative condi-
tion, cellular connection availabil-
ity, and GPS satellite signal
reception, which can limit the abil-
ity to reach the response center or
receive emergency service sup-
port. Enrollment and Telematics
Subscription Service Agreement
are required. A variety of subscrip-
tion terms are available; charges
vary by subscription term selected
and location.
●Automatic Collision Notification,
Emergency Assistance and Stolen
Vehicle Location are available in
the United States, including
Hawaii and Alaska , Puerto Rico
and Canada, and Enhanced
Roadside Assistance are avail-
able in the United States, Puerto
Rico and Canada.
●Automatic Collision Notification,
Emergency Assistance, Stolen
Vehicle and Enhanced Road
Assistance are not available in the
U.S. Virgin Islands.
For vehicles first sold in the U.S.
Virgin Islands, no Safety Connect
services will function in or outside
the U.S. Virgin Islands.
●Safety Connect services are not
subject to section 255 of the Tele-
communications Act and the
device is not TTY compatible.
■Languages
The Safety Connect response cen-
ter will offer suppor t in multiple lan-
guages. The Safety Connect system
will offer voice prompts in English,
Spanish, and French. Please indi-
cate your language of choice when
enrolling.
■When contacting the response
center
You may be unable to contact the
response center if the network is
busy.
Subscription

1062-1. Instrument cluster
range for using the accelerator
pedal according to driving condi-
tions, and a score result that
evaluates the current driving
status.ECO Accelerator Guidance
“Eco Score”
ECO Accelerator GuidanceECO area
Shows that the vehicle is being
driven in an Eco-friendly manner.
Power area
Shows that an Eco-friendly driving
range is being exceeded (during full
power driving etc.).
Current acceleration
Reference operation range
A zone is display ed in blue under
the Eco area which can be used as
a reference operation range for
using the accelerator pedal accord- ing to driving conditions such as
starting off and cruising.
The ECO Accelerator Guidance
display changes according to the
driving status, such as when start-
ing off or cruising.
It is easier to drive in an Eco-
friendly manner by driving accord-
ing to the display showing the
accelerator pedal operations and
staying within the reference opera-
tion range.
“Eco Score”
The driving status for the follow-
ing 3 situations are evaluated in
5 levels: Smooth start-off accel-
eration (“Start”), driving without
sudden acceleration (“Cruise”)
and smooth stopping (“Stop”).
Each time the vehicle is
stopped, a score result is dis-
played out of a perfect score of
100 points.
Score result
“Start”
“Cruise”
“Stop”
A
B
A
B
C
D
A
B
C
D

3154-5. Using the driving support systems
4
Driving
This line indicates the estimated
vehicle center on the ground.
Distance guide line
Shows distance behind the vehicle.
• Displays a point approximately
1.5 ft. (0.5 m) (red) from the edge
of the bumper.
Distance guide line
Shows distance behind the vehicle.
• Displays a point approximately 3 ft. (1 m) (blue) from the edge of
the bumper.
The rear view monitor system is
canceled when the shift lever is
shifted into any position other
than the “R” position.
The rear view monitor system
displays an image of the view
from the bumper of the rear area
of the vehicle. Corners of bumper
 The area around both corners
of the bumper will not be dis-
played.
●The image adjustment procedure
for the rear view monitor system
screen is the same as the proce-
dure for adjusting the screen.
( P.400)
●The area displayed on the screen
may vary according to vehicle ori-
entation conditions.
●Objects which are close to either
corner of the bumper or under the
bumper cannot be displayed.
●The camera uses a special lens.
The distance of the image that
appears on the screen differs from
the actual distance.
●Items which are located higher
than the camera may not be dis-
played on the monitor.
The camera for the rear view
Canceling rear view moni-
tor system
Rear view monitor system
precautions
Area displayed on screen
C
D
7KHFDPHUD
A

3244-5. Using the driving support systems
those who are comfortable with
parking the vehicle without the
aid of the estimated course
lines.
Distance guide line display
mode (P.326)
Distance guide lines only are
displayed.
This mode is recommended for
those who are comfortable with
parking the vehicle without the
aid of the guide lines.
Rear view
Vehicle width guide line
Displays a guide path when the
vehicle is being backed straight up.
Estimated course lines
Show an estimated course when
the steering wheel is turned.
Distance guide lines
Show distance behind the vehicle
when the steering wheel is turned.
• The guide lines move in conjunc- tion with the estimated course
lines.
• The guide lines display points approximately 1.5 ft. (0.5 m) (red)
and approximately 3 ft. (1 m) (yel-
low) from the ce nter of the edge
of the bumper.
Distance guide line
Shows distance behind the vehicle.
• Displays a point approximately 1.5 ft. (0.5 m) (blue) from the
edge of the bumper.
Vehicle center guide line
Indicates the es timated vehicle
center on the ground.
Estimated course line dis-
play mode
Screen description
A
B
C
D
E

3254-5. Using the driving support systems
4
Driving
Wide rear viewVehicle width guide line
Displays a guide path when the
vehicle is being b acked straight up.
Estimated course lines
Show an estimate d course when
the steering wheel is turned.
Distance guide lines
Show distance behind the vehicle
when the steering wheel is turned.
• The guide lines move in conjunc- tion with the estimated course
lines.
• The guide lines display points approximately 1.5 ft. (0.5 m) (red)
and approximately 3 ft. (1 m) (yel-
low) from the cent er of the edge
of the bumper.
Distance guide line
Shows distance behind the vehicle.
• Displays a point approximately 1.5 ft. (0.5 m) (blue) from the
edge of the bumper.
Vehicle center guide line
Indicates the estimated vehicle
center on the ground.
Rear view
Vehicle width guide line
Displays a guide path when the
vehicle is being backed straight up.
• The displayed width is wider than the actual veh icle width.
Parking assist guide lines
Show the path of th e smallest turn
possible behind the vehicle.
Distance guide line
Shows distance behind the vehicle.
• Displays points approximately 1.5 ft. (0.5 m) (red) fr om the edge of
the bumper.
Vehicle center guide line
Indicates the es timated vehicle
center on the ground.
A
B
C
D
E
WARNING
●If the steering wheel is straight
and the vehicle width guide
lines and the estimated course
lines are not in alignment, have
the vehicle inspected by your
Toyota dealer.
Parking assist guide line
display mode
Screen description
A
B
C
D

3494-5. Using the driving support systems
4
Driving
Estimated course lines
Shows an estimated course when the steering wheel is turned.
Distance guide lines
Shows the distance behind the vehicle when the steering wheel i s turned.
• The guide lines move in conjunc tion with the estimated course lines.
• The guide lines display points approximately 1.5 ft. (0.5 m) (red) and
approximately 3 ft. (1 m) (yello w) from the center of the edge of the
bumper.
Distance guide line
Shows the distance behind the vehicle.
• Displays a point approximately 1.5 ft. (0.5 m) (blue) from the edge of the
bumper.
Vehicle width guide lines
Displays a guide path w hen the vehicle is being backed straight up.
Vehicle center guide line
Indicates the estimated vehicle center on the ground.
Parking assist guide line
The steering wheel return points (parking assist guide lines) are dis-
played.
This mode is recommended for those who are comfortable with par k-
ing the vehicle without the aid of the estimated course lines.
Distance guide lines
Shows distance in front of the vehicle.
• Display points approximately 3 ft. (1 m) from the edge of the bumper.
Distance guide line
Shows the distance behind the vehicle.
• Displays a point approximately 1.5 ft. (0.5 m) (red) from the edge of the
bumper.
B
C
D
E
F
A
B

385
5
5
Audio
Audio
5-1. Basic functionButtons overview......... 387
Menu screen ............... 389
Status icon .................. 390
“Setup” screen ............ 392
5-2. Basic information before operation
Initial screen ................ 393
Touch screen .............. 394
Home screen............... 396
Entering letters and num- bers/list screen operation.................................. 397
Screen adjustment ...... 400
Linking multi-information display and the system
.................................. 401
5-3. Connectivity settings Registering/Connecting a Bluetooth
® device ..... 402
Setting Bluetooth
® details
.................................. 406
Wi-Fi
® Hotspot ............ 414
5-4. Apple CarPlay/Android Auto
Apple CarPlay
®/Android
Auto
™........................ 419
5-5. Other settings General settings .......... 426
Voice settings.............. 430Vehicle settings ...........
431
5-6. Using the audio/visual system
Quick reference ........... 432
Some basics................ 433
5-7. Radio operation AM/FM/SiriusXM (SXM) radio .......................... 437
5-8. Media operation USB memory ............... 444
iPod/iPhone (Apple Car- Play) .......................... 446
Android Auto ............... 449
Bluetooth
® audio ......... 450
5-9. Audio/visual remote con- trols
Steering switches ........ 454
5-10.Audio settings Setup ........................... 456
5-11.Tips for operating the audio/visual system
Operating information.. 458
5-12.Voice command system operation
Voice comm and system
.................................. 470
Command list .............. 473
5-13.Mobile Assistant opera- tion
Mobile Assistant .......... 477

386
5-14.Phone operation (Hands-free system for cellular
phones)
Quick reference........... 479
Some basics ............... 480
Placing a call using the Bluetooth
® hands-free sys-
tem ............................ 484
Receiving a ca ll using the
Bluetooth
®hands-free sys-
tem ............................ 487
Talking on the Bluetooth
®
hands-free system..... 488
Bluetooth
® phone message
function...................... 490
5-15.Phone settings Setup........................... 495
5-16.What to do if... (Bluetooth
®)
Troubleshooting .......... 505
5-17.Connected Services over- view
Connected Services .... 509
Type A: Function achieved by using a smartphone or
DCM .......................... 510
Type B: Function achieved by using DCM and the sys-
tem ............................ 512
Type C: Function achieved by using DCM............ 513Type D: Function achieved
by using DCM and a
smartphone ............... 516
5-18.Connected Services oper- ation
Toyota Apps ................ 518
5-19.Setup Toyota Apps settings... 522
