1573-3. Adjusting the seats
3
Before driving
ten.
■Recall procedure
1 Check that the shift lever is in
P.
2 Turn the power switch to ON.
3 Press one of the buttons for
the driving position you want
to recall until the buzzer
sounds.
■To stop the position recall oper-
ation part-way through
Perform any of the following:
●Press the “SET” button.
●Press button “1” or “2”.
●Operate any of the seat adjust-
ment switches.
■Seat positions that can be
memorized ( P.153)
The adjusted positions other than
the position adjusted by lumbar sup-
port switch can be recorded.
■Operating the driving position
memory after turning the power
switch to OFF
Recorded seat positions can be
activated up to 180 seconds after
the driver’s door is opened and
another 60 seconds after it is closed
again.
■In order to corre ctly use the
driving position memory func-
tion
If a seat position is already in the
furthest possible position and the
seat is operated in the same direc-
tion, the recorded position may be
slightly different w hen it is recalled.
■When recalling the driving posi-
tion
Take care when recalling the driving
position so that the head restraint
does not touch the ceiling.
■If the 12-volt b attery is discon-
nected
The memorized positions are
erased.
■When the recorded seat posi-
tion cannot be recalled
The seat positi on may not be
recalled in some situations when the
seat position is recorded in a certain
range. For details, contact your
Toyota dealer.
WARNING
■Seat adjustment caution
Take care during seat adjustment
so that the seat does not strike
the rear passenger or squeeze
your body against the steering
wheel.

1623-4. Adjusting the steering wheel and mirrors
3-4.Adjusting the steering wheel and mirrors
1Hold the steering wheel and
push the lever down.
2 Adjust to the ideal position by
moving the steering wheel
horizontally and vertically.
After adjustment, pull the lever up
to secure the steering wheel.
To sound the horn, press on or
close to the mark.
Steering wheel
Adjustment procedure
WARNING
■Caution while driving
Do not adjust the steering wheel
while driving.
Doing so may cause the driver to
mishandle the vehicle and cause
an accident, resul ting in death or
serious injury.
■After adjusting the steering
wheel
Make sure that the steering wheel
is securely locked.
Otherwise, the steering wheel
may move suddenly, possibly
causing an accident, and resulting
in death or serious injury. Also,
the horn may not sound if the
steering wheel is not securely
locked.
Sounding the horn

1663-4. Adjusting the steering wheel and mirrors
Operate the lever to change
between digital mirror mode and
optical mirror mode.
1Digital mirror mode
Displays an image of the area
behind the vehicle.
will illuminate in this mode.
2Optical mirror mode
Turns off the disp lay of the Digital
Rear-view Mirror allows it to be
used as an optical mirror.
■Digital mirror mode operating
condition
The power switch is turned to ON.
When the power switch is changed
from ON to OFF or ACC, the image
will disappear afte r several seconds.
■When using the Digital Rear-
view Mirror in digital mirror
mode
●If it is difficult to see the displayed
image due to light reflected off the
Digital Rear-view Mirror, the cam-
era being dirty or covered with
water droplets, or if lights of a
vehicle behind your vehicle or the
displayed image are bothering
you, change to optical mirror
mode.
●When the back door is open, the
Digital Rear-view Mirror image
may not display properly. Before driving, make sure the back door
is closed.
●If the display is difficult to see due
to reflected light
, close the sun-
shade for the moon roof (if
equipped) or the electronic sun-
shade for the panoramic moon
roof (if equipped).
●Any of the following conditions
may occur when driving in the
dark, such as at night. None of
them indicates that a malfunction
has occurred.
• Colors of objects in the displayed
image may differ from their actual
color.
• Depending on the height of the
lights of the vehicle behind, the
area around the vehicle may
appear white and blurry.
• Automatic image adjustment for
brighter surrounding image may
cause flickering.
If it is difficult to see the displayed
image or flickering bothers you,
change to optical mirror mode.
●The Digital Rear-view Mirror may
become hot while it is in digital
mirror mode.
This is not a malfunction.
●Depending on your physical con-
dition or age, it may take longer
than usual to fo cus on the dis-
played image. In this case,
change to optical mirror mode.
●Do not let passengers stare at the
displayed image when the vehicle
is being driven, as doing so may
cause motion sickness.
■When the system malfunctions
If the symbol shown in the illustra-
tion is displayed when using the
Digital Rear-view Mirror in digital
mirror mode, the system may be
malfunctioning. The symbol will dis-
appear in a few seconds. Operate
the lever, change to optical mirror
mode and have the vehicle
inspected by your Toyota dealer.
Changing modes

1743-4. Adjusting the steering wheel and mirrors
■Defogging the mirrors (if
equipped)
The outside rear v iew mirrors can
be cleared using the mirror defog-
gers. Turn on the rear window
defogger to turn on the outside rear
view mirror defoggers.
(  P.526)
1 To select a mirror to adjust,
press the switch.
Left
Right
2 To adjust the mirror, press
the switch.
Up
Right
Down
Left
■Mirror angle can be adjusted
when
The power switch is in ACC or ON.
Push the mirror back in the
direction of the vehicle’s rear.
Outside rear view mir-
rors
The rear view mirror’s posi-
tion can be adjusted to
enable sufficient confirma-
tion of the rear view.
WARNING
■Important points while driving
Observe the following precautions
while driving.
Failing to do so may result in loss
of control of the vehicle and cause
an accident, resul ting in death or
serious injury.
●Do not adjust the mirrors while
driving.
●Do not drive with the mirrors
folded.
●Both the driver and passenger
side mirrors must be extended
and properly adjusted before
driving.
■When the mirror defoggers
are operating (if equipped)
Do not touch the rear view mirror
surfaces, as they can become
very hot and burn you.
Adjustment procedure
Folding the mirrors
A
B
A
B
C
D

6518-2. Steps to take in an emergency
8
When trouble arises
ing valve and transmitter. If a tire
goes flat, the tire pressure warning
light will not turn o ff even though the
flat tire has been replaced with the
spare tire. Replace the spare tire
with the standard tire and adjust the
tire inflation pressure. The tire pres-
sure warning light will go off after a
few minutes.
■Conditions that the tire pres-
sure warning system may not
function properly (vehicles with
tire pressure warning system)
 P.593
WARNING
■If a warning light comes on or
a warning buzzer sounds
when a warning message is
shown on the multi-informa-
tion display
*
Check and follow the message
shown on the multi-information
display.
Failure to do so m ay result in
death or serious injury.
*: Warning lights illuminate in red
or yellow and the warning
buzzer beeps on ce or sounds
continuously.
WARNING
■When the electric power
steering system warning light
comes on
When the light comes on yellow,
the assist to the power steering is
restricted. When the light comes
on red, the assist to the power
steering is lost and handling oper-
ations of the steering wheel
become extremely heavy.
If the steering wheel becomes
heavier than usual when operat-
ing, hold firmly a nd operate using
more force than usual.
■If the tire pr essure warning
light comes on ( vehicles with
tire pressure warning system)
Be sure to observe the following
precautions. Failure to do so
could cause a loss of vehicle con-
trol and result in death or serious
injury.
●Stop your vehicle in a safe
place as soon as possible.
Adjust the tire inflation pressure
immediately.
●If the tire pressure warning light
comes on even after tire infla-
tion pressure adjustment, it is
probable that you have a flat
tire. Check the tires. If a tire is
flat, change it with the spare tire
and have the flat tire repaired by
the nearest Toyota dealer.
●Avoid abrupt maneuvering and
braking. If the vehicle tires dete-
riorate, you could lose control of
the steering wheel or the
brakes.
■If a blowout or sudden air
leakage should occur (vehi-
cles with tire pressure warn-
ing system)
The tire pressure warning system
may not activate immediately.

740Alphabetical Index
reminder light ....................... 649
Front passenger occupant clas- sification system .................... 45
Front position lights Light switch .......................... 229
Front seat heaters .................. 531
Front seats .............................. 153 Adjustment ........................... 153
Cleaning ............................... 569
Correct driving posture ........... 29
Driving position memory....... 156
Head restraints ..................... 159
Memory recall function ......... 158
Seat heaters ......................... 531
Seat position memory .......... 156
Seat ventilators .................... 531
Front side marker lights ........ 229 Light switch .......................... 229
Replacing light bulbs ............ 624
Wattage ................................ 692
Front turn signal lights Replacing light bulbs ............ 624
Turn signal lever................... 223
Wattage ................................ 692
Fuel Capacity ............................... 685
Fuel gauge ....................... 94, 98
Gas station information ........ 752
Information ........................... 694
Refueling .............................. 241
Type ............................. 685, 694
Warning light ........................ 649
Fuel consumption information Average fuel consumption.... 115
Current fuel consumption ..... 115
Fuel filler door ..... ................... 242
If the fuel filler door cannot be opened ............................... 669
Refueling .............................. 241
Fuel gauge .......................... 94, 98
Fuses ....................................... 621G
Garage door opene r ...............557
Gas station information .........752
Gauges ................................94, 98
General button (Setup screen) .......................................392, 426
General settings .....................426 Displaying the general settings screen.................................426
General settings screen .......426
Glove box ................................537
H
Hands-free system .................479
Headlights ...............................229 Adaptive Front-lighting System (AFS) ..................................232
Automatic headlight leveling sys- tem .....................................231
Automatic High Beam system ...........................................232
Light switch...........................229
Replacing light bulbs ............624
Wattage ................................692
Head restraints .......................159
Heated steering wheel............531
Heaters Automatic air conditioning sys-tem .....................................524
Heated steering wheel..........531
Outside rear view mirrors .....526
Seat heaters ....... ..................531
High mounted stoplight Replacing light bulbs ............624
Hill-start assist control...........369
HOME button...........................396
Home screen ...........................396
Hood ........................................579
Hooks Cargo hooks .........................541
Coat hooks ...........................557

Alphabetical Index747
from P................................. 221
Shift lock system .................... 221
Side airbags .............................. 35
Side auxiliary box ................... 543
Side doors ............................... 127
Side marker lights Light switch .......................... 229
Replacing light bulbs ............ 624
Wattage ................................ 692
Side mirrors ............................ 174 Adjustment ........................... 174
BSM (Blind Spot Monitor)..... 283
Folding ................................. 174
Heaters................................. 526
Side turn signal lights Replacing light bulbs ............ 624
Turn signal lever................... 223
Side windows ...... ................... 176
Smart key system ................... 147 Antenna location .................. 147
Entry functions ............. 127, 134
Starting the hybrid system.... 212
Warning message ................ 654
Snow tires ............................... 378
Spare tire Storage location ................... 659
Specifications ......................... 684
Speedometer ...................... 94, 98
Sport mode ............................. 366
Status icon .............................. 390 Status icon explanation ........ 390
Steering lock Column lock release..... 210, 213
Steering lock system warning message............................. 213
Steering switch ............... 454, 483 Audio switch ......................... 454
Steering wheel Adjustment ........................... 162
Heated steering wheel ......... 531
Meter control switches ......... 104
Stop lights Replacing light bulbs ............624
Storage feature .. .....................537
Storage precaution s ...............537
Stuck If the vehicle becomes stuck 680
Suggestion functi on ...............112
Sunglass holder.... ..................539
Sunshade ........................179, 182
Sun visors ...............................546
Switches “ODO TRIP” switch .........96, 101
“SOS” button ..........................67
Automatic High Beam switch 232
Brake hold switch .................227
BSM (Blind Spot M onitor) .....284
Digital Rear-view Mirror control switches..............................165
Door lock switch ...................131
Driving mode select switch ...366
Driving position memory switches..............................156
Dynamic radar cruise control with full-speed range ..........272
Electronic sunshade switch ..182
Emergency flashers switch...634
EV drive mode switch ...........217
Fog light switch .....................235
Garage door opener switches ...........................................557
Heated steering wheel..........531
Ignition switch (power switch) ...................................210, 212
Intuitive parking assist ..........293
Light switch...........................229
LTA switch ............................263
Meter control switches..........104
Moon roof switches ..............179
Outside rear v iew mirror
switches..............................174
Panoramic moon roof switches ...........................................182
Parking brake switch ............224
