mirror TOYOTA RAV4 HYBRID 2022 Owners Manual

2TABLE OF CONTENTS
For your information...................8
Reading this manual ................ 13
How to search .......................... 14
Pictorial index .......................... 16
1-1. For safe use Before driving ................... 28
For safe driving ................ 29
Seat belts ......................... 31
SRS airbags ..................... 35
Front passenger occupant classification system ...... 45
Exhaust gas precautions.. 50
1-2. Child safety Riding with children .......... 51
Child restraint systems..... 52
1-3. Emergency assistance Safety Connect ................ 67
1-4. Hybrid system Hybrid system features .... 72
Hybrid system precautions ....................................... 76
1-5. Theft deterrent system Immobilizer system .......... 81
Alarm................................ 82
2-1. Instrument cluster Warning lights and indicators....................................... 86
Gauges and meters (with 4.2- inch display) ................... 92Gauges and meters (with 7-
inch display) ................... 96
Multi-information display 101
Energy monitor/ consumption
screen.......................... 111
3-1. Key information Keys .............................. 118
3-2. Opening, closing and lock- ing the doors
Side doors ..................... 123
Back door ...................... 129
Smart key system .......... 143
3-3. Adjusting the seats Front seats .................... 148
Rear seats ..................... 149
Driving position memory 151
Head restraints .............. 154
3-4. Adjusting the steering wheel and mirrors
Steering wheel............... 157
Inside rear view mirror ... 158
Digital Rear-view Mirror . 160
Outside rear view mirrors .................................... 169
3-5. Opening, closing the win- dows and moon roof
Power windows ............. 171
Moon roof ...................... 174
Panoramic moon roof .... 177
1For safety and security
2
Vehicle status
information and
indicators
3Before driving

16Pictorial index
Pictorial index
■Exterior
The shape of the headlights may differ depending on the grade, etc.
Side doors ......... ................................. ................................P.123
Locking/unlocking ................................................................P.123
Opening/closing the side windows ............................... ........P.171
Locking/unlocking by using the mechanical key ..........P.124, 652
Warning messages ..............................................................P.635
Back door ...................................................... .....................P.129
Locking/unlocking ................................................................P.130
Opening from inside the cabin
*............................................P.133
Opening from outside........................................... ........P.131, 133
Warning messages ..............................................................P.635
Outside rear view mirrors .................................................P.169
Adjusting the mirror angle ..................................... ...............P.169
Folding the mirrors ...............................................................P.169
Defogging the mirrors
*.........................................................P.516
Windshield wipers .............................................. ...............P.231
A
B
C
D

21Pictorial index
■Switches
Driving position memory switches*.................................P.151
Window lock switch ............................................. ..............P.173
Power window switches ....... .............................................P.171
Door lock switches ............................................................P.127
Outside rear view mirror swi tches ...................................P.169
“ODO TRIP” switch .............................................. ..........P.94, 99
Instrument panel light cont rol dial .............................P.94, 100
Automatic High Beam switch ..................................... ......P.227
Windshield wiper de-icer switch
*.....................................P.519
Camera switch
*............................................................... ....P.328
Heated steering wheel switch
*..........................................P.521
Power back door switch
*...................................................P.133
*: If equipped
A
B
C
D
E
F
G
H
I
J
K
L

25Pictorial index
■Ceiling
“SOS” button*1............................................................... ......P.67
Auxiliary box .................................................. ....................P.529
Moon roof switches
*1.........................................................P.174
Interior lights
*2............................................................... ....P.524
Personal lights ................................................ ...................P.525
Electronic sunshade switch
*1...........................................P.177
Vanity mirrors.....................................................................P.536
Sun visors..................................................... ......................P.536
Inside rear view mirror
*1....................................................P.158
Digital Rear-view Mirror
*1..................................................P.160
Garage door opener switches
*1........................................P.546
*1: If equipped
*2: The illustration shows the fron t, but they are also equipped i n the rear.
A
B
C
D
E
F
G
H
I

291-1. For safe use
1
For safety and security
Adjust the angle of the seat-
back so that you are sitting
straight up and so that you do
not have to lean forward to
steer. (P.148)
Adjust the seat so that you
can depress the pedals fully
and so that your arms bend
slightly at the elbow when
gripping the steering wheel.
( P.148)
Lock the head restraint in
place with the center of the
head restraint closest to the
top of your ears. ( P.154)
Wear the seat belt correctly.
( P.32)
WARNING
■Before driving
●Check that the floor mat is
securely fixed in the correct
place with all the provided
retaining hooks (clips). Be espe-
cially careful to perform this
check after cleaning the floor.
●With the hybrid system stopped
and the shift lever in P, fully
depress each pedal to the floor
to make sure it does not inter-
fere with the floor mat.
For safe driving
For safe driving, adjust the
seat and mirror to an appro-
priate position before driv-
ing.
Correct driving posture
A
B
C
D

301-1. For safe use
Make sure that all occupants are
wearing their seat belts before
driving the vehicle. (P.32)
Use a child restraint system
appropriate for the child until the
child becomes large enough to properly wear the vehicle’s seat
belt. (
P.52)
Make sure that you can see
backward clearly by adjusting
the inside rear view mirror (if
equipped), Digital Rear-view
Mirror (if equipped) and outside
rear view mirrors properly.
( P.158, 160, 169)
WARNING
Observe the following precau-
tions.
Failure to do so m ay result in
death or serious injury.
●Do not adjust the position of the
driver’s seat while driving.
Doing so could cause the driver
to lose control of the vehicle.
●Do not place a cushion between
the driver or passenger and the
seatback. A cushion may pre-
vent correct pos ture from being
achieved, and reduce the effec-
tiveness of the seat belt and
head restraint.
●Do not place anything under the
front seats.
Objects placed under the front
seats may become jammed in
the seat tracks and stop the
seat from locking in place. This
may lead to an accident and the
adjustment mechanism may
also be damaged.
●Always observe the legal speed
limit when driving on public
roads.
●When driving over long dis-
tances, take regular breaks
before you start to feel tired.
Also, if you feel tired or sleepy
while driving, do not force your-
self to continue driving and take
a break immediately.
Correct use of the seat
belts
Adjusting the mirrors

862-1. Instrument cluster
2-1.Instrument cluster
For the purpose of explanation, the following illustrations display all
warning lights and indicators illuminated.
■With 4.2-inch display
The units used on the meters and some indicators may differ dep ending on
the target region.
■With 7-inch display
The display of the speedometer can be selected from two types,
analog or digital. ( P.107)
Warning lights and indicators
The warning lights and indicators on the instrument cluster,
center panel and outside rear view mirrors inform the driver
of the status of the vehicle’s various systems.
Instrument cluster

902-1. Instrument cluster
*1: This light illuminates on the multi-information display with a
message.
*2: Depending on the operating con-ditions of the system, the color
and state (illuminat ed/blinking) of
the indicator change.
*3: The light comes on when the system is turned off.
*4: Intuitive parking assist OFF indi-cator turns on wh en the power
switch is turned t o ON while the
Intuitive parking assist function is
on. It will turn off after a few sec-
onds.
*5: These lights tu rn on when the
power switch is turned to ON to
indicate that a system check is
being performed. They will turn
off after the hybrid system is on,
or after a few seconds. There
may be a malfunction in a sys-
tem if the lights do not turn on, or
turn off. Have the vehicle
inspected by your Toyota dealer.
*6: This light illuminates on the out- side rear view mirrors.
*7: When the outside temperature is approximately 37°F (3°C) or
lower, the indicator will flash for
approximately 10 seconds, then
stay on.
*8: This light illuminates on the cen-ter panel.
(Flashes)
Slip indicator light*5
(  P.362)
VSC OFF indicator
*3,
5
(  P.362)
PCS warning light
*3, 5
(  P.246)
BSM outside rear view
mirror indicators
*5, 6 ( i f
equipped) ( P.277)
BSM indicator (if
equipped) ( P.277)
RCTA OFF indica-
tor
*3, 5 (if equipped)
(  P.277)
Brake hold standby
indicator
*5 (  P.221)
Brake hold operated
indicator
*5 (  P.221)
Security indicator
(  P.81, 83)
“READY” indicator
(  P.204, 206)
Low outside tempera-
ture indicator
*7
(  P.93, 99)
EV indicator ( P.73)
(U.S.A.)
Parking brake indica-
tor ( P.218)
(Canada)
Parking brake indica-
tor ( P.218)
EV drive mode indica-
tor ( P.211)
Eco drive mode indi-
cator ( P.358)
Sport mode indicator
( P.358)
Trail Mode indicator
(  P.359)
“AIR BAG ON/OFF”
indicator
*5, 8 (  P.45)

912-1. Instrument cluster
2
Vehicle status information and indicators
■BSM (Blind Spot Monitor) out-
side rear view mirror indicators
(if equipped)
In order to confirm operation, the
BSM outside rear view mirror indica-
tors illuminate in the following situa-
tions:
●When the power switch is turned
to ON while the BSM function is
enabled on the screen of the
multi-informat ion display.
●When the BSM function is
enabled on the screen of the
multi-information display while the
power switch is in ON.
If the system is functioning correctly,
the BSM outside rear view mirror
indicators will turn off afte r a few
seconds.
If the BSM outside rear view mirror
indicators do not illuminate or do not
turn off, there may be a malfunction
in the system. If this occurs, have
the vehicle insp ected by your
Toyota dealer.

1082-1. Instrument cluster
■ BSM (Blind Spot Moni-
tor) (if equipped) ( P.276)
Select to set up the following
items.
 BSM (Blind Spot Monitor)
on/off
Select to enable/disable the BSM
system.
“Brightness”
Select to switch the brightness of
the outside rear view mirror indica-
tors. ( P.277)
 “Sensitivity”
Select to change the alert timing for
an approaching vehicle.
■ (Intuitive parking
assist) (if equipped)
( P.287)
Select to set up the following
items.
 Intuitive parking assist on/off
Select to enable/disable the Intui-
tive parking assist.
“Volume”
Select to set the volume of the
buzzer which sounds when the
Intuitive parking assist is operated.
■RCTA (Rear Cross Traffic
Alert) (if equipped)
(P.276)
 RCTA (Rear Cross Traffic
Alert) on/off
Select to enable/disable the RCTA
system.
“Volume”
Select to change t he RCTA buzzer volume.
■ PKSB (Parking Sup-
port Brake System) (if
equipped) ( P.295)
Select to enable/disable the
Parking Support Brake function.
■ RSA (Road Sign
Assist) (if equipped)
( P.262)
Select to set up the following
items.
 Road Sign Assist on/off
Select to enable /disable the RSA
system.
 “Notification method”
Select to change each notification
method used to notify the driver
when the system recognizes
excess speed and Do Not Enter
sign.
“Notification Level”
Select to change each notification
level used to notify the driver when
the system recognizes a speed limit
sign.
■ Vehicle Settings
 PBD (Power Back Door)
(if equipped) ( P.133)
Select to set up t he following items.
• System settings
Select to enable/disable the power
back door system.
• “Hands Free”
*
Select to enable/d isable the Hands
Free Power Back Door.
• “Opening Adjustment”
