odometer TOYOTA RAV4 HYBRID 2022 Owners Manual

922-1. Instrument cluster
The units used on the meter and display may differ depending on the target
region.
Hybrid System Indicator
Displays the Hybrid System Indicator ( P.93)
Outside temperature ( P.93)
Clock ( P.95)
Multi-information display
Presents the driver with a variety of driving-related data ( P.101)
Displays warning messages if a malfunction occurs (P.635)
Speedometer
Displays the vehicle speed
Fuel gauge
Displays the quantity of fu el remaining in the tank
Odometer and trip meter
Odometer:
Displays the total distance th at the vehicle has been driven
Trip meter:
Displays the distance the vehicle has been driven since the meter was last
Gauges and meters (w ith 4.2-inch display)
The meters display various drive information.
Meter display
A
B
C
D
E
F
G

962-1. Instrument cluster
The display of the speedometer can be selected from two types,
analog or digital. (P.107)
Analog speedometer
The units used on the meter and display may differ depending on the target
region.
Hybrid System Indicator
Displays the Hybrid System Indicator ( P.98)
Speedometer
Displays the vehicle speed
Clock ( P.100)
Fuel gauge
Displays the quantity of fu el remaining in the tank
Engine coolant temperature gauge
Displays the engine coolant temperature
Odometer and trip meter
Odometer:
Displays the total distance th at the vehicle has been driven
Trip meter:
Gauges and meters (with 7-inch display)
The meters display various drive information.
Meter display
A
B
C
D
E
F

972-1. Instrument cluster
2
Vehicle status information and indicators
Displays the distance the vehicle has been driven since the meter was last
reset. Trip meters “A” and “B” c an be used to record and display different
distances independently.
Outside temperature ( P.99)
Multi-information display
Presents the driver with a variety of driving-related data ( P.101)
Displays warning messages if a malfunction occurs (P.635)
Shift position and shift range indicator
Displays the selected shift posit ion or selected shift range (P.213)
Digital speedometer
The units used on the meter and display may differ depending on the target
region.
Hybrid System Indicator
Displays the Hybrid System Indicator ( P.98)
Speedometer
Displays the vehicle speed
Clock ( P.100)
Fuel gauge
Displays the quantity of fu el remaining in the tank
Engine coolant temperature gauge
Displays the engine coolant temperature
Odometer and trip meter
Odometer:
Displays the total distance th at the vehicle has been driven
G
H
I
A
B
C
D
E
F

Alphabetical Index727
Meters .............................. 92, 96
Multi-information display ...... 101
Settings ........................ 107, 688
Units ............................. 109, 689
Warning lights ................ 87, 624
Warning messages ...... 110, 635
Meter control switches .......... 102
Microphone ............................. 472
Mirrors Digital Rear-view Mirror........ 160
Inside rear view mirror.......... 158
Outside rear view mirror defog-gers .................................... 516
Outside rear view mirrors ..... 169
Vanity mirrors ....................... 536
Mobile Assistant .. ................... 467
Connectable devices and avail- able functions ..................... 467
Mobile Assistant operation ... 467
Moon roof Door lock linked moon roof oper-ation ................................... 174
Jam protection function ........ 174
Operation ............................. 174
Warning message ................ 175
Multi-information display Audio system-linked display . 106
Changing the display............ 102
Convenience Services (Sugges-tion function)............... 110, 689
Display contents ................... 101
Driving information display ... 103
Driving support system informa- tion display ......................... 105
Dynamic radar cruise control with full-speed range .......... 265
Hybrid System Indicator ... 93, 98
Intuitive parking assist-sensor ........................................... 287
Language ..................... 109, 689
LTA (Lane Tracing Assist).... 258
Menu icons ........................... 102 Meter control switches..........102
Navigation system-linked display
...........................................106
PCS (Pre-Collisio n System) .244
Pop-up display..............109, 689
Settings ........................107, 688
Tire pressure ...... ..................581
Units .............................109, 689
Vehicle information display...106
Warning message display ....110
Warning messages ...............635
N
Navigation system-linked display
...............................................106
Noise from under ve hicle...........8
Normal mode...........................358
O
Odometer.............................92, 96
Odometer and trip meter display “ODO TRIP” switch ...........94, 99
“ODO TRIP” switch ............94, 99
Oil Engine oil..............................668
Opener Back door .....................131, 133
Hood .....................................567
Outer foot lights Replacing light bulbs ............607
Wattage ................................674
Outside rear view mirrors ......169 Adjusting and folding ............169
BSM (Blind Spot M onitor) .....277
Outside rear view mirror defog- gers ....................................516
Outside temperature display .93, 99
Overheating.............................659
