952-1. Instrument cluster
2
Vehicle status information and indicators
Displays the vehicle speed
Clock
Automatically adjusts the time by using the GPS time information (GPS
clock).
For details, refer to “MULTIMEDIA OWNER’S MANUAL”.
Fuel gauge
Displays the quantity of fu el remaining in the tank.
In the following sit uations, the actual quantity of fuel remain ing in the tank
may not be displayed correctly. Refer to P.96 if the actual quantity of fuel
remaining in the tank is not displayed correctly.
• A small amount of fuel is added.
• Fuel is added with the fuel gauge near or at “F”.
• The vehicle is stopp ed on an uneven surface, such as a slope.
• The vehicle is driven on a slope or around a curve.
Engine coolant temperature gauge
Displays the engine coolant temperature
Odometer and trip meter
Odometer:
Displays the total distance th at the vehicle has been driven
Trip meter:
Displays the distance the vehicle has been driven since the meter was last
reset. Trip meters “A” and “B” c an be used to record and display different
distances independently.
Outside temperature ( P.96)
Multi-information display
Presents the driver with a variety of driving-related data ( P.105)
Displays warning messages if a malfunction occurs (P.466)
Shift position and shift range indicator
Displays the selected shift posit ion or selected shift range (P.226)
■The meters and display illumi-
nate when
The power swit ch is in ON.
■When changing driving mode
Speedometer color is changed fol-
lowing the selected driving mode or
when Trail Mode is turned on.
(  P.323, 324)
C
D
E
F
G
H
I

3425-1. Using the air conditioning system and defogger
5-1.Using the air conditioning system and defogger
Automatic mode switch
Left-hand side temperature control knob
Right-hand side temperature control knob
“SYNC” switch
“OFF” switch
Windshield defogger switch
Rear window and outside rear view mirror defoggers switch
Eco air conditioning mode switch
Fan speed decrease switch
Fan speed increase switch
Airflow mode control switch
Outside/recirculated air mode switch
Front seat concentrated airflow mode (S-FLOW) switch
“A/C” switch
■Adjusting the temperature
setting
Turn driver’s side temperature
control dial clockwise to increases the temperature and
turn the dial counterclockwise to
decreases the temperature.
The air conditioning system
Automatic air co
nditioning system
Air outlets and fan speed are automatically adjusted accord-
ing to the temperature setting.
Air conditioning controls
A
B
C
D
E
F
G
H
I
J
K
L
M
N

Alphabetical Index557
K
Keyless entrySmart key system................. 155
Wireless remote control ....... 132
Keys ......................................... 130 Battery-saving function......... 156
Electronic key ....................... 130
If the electronic key does not operate properly ................. 483
If you lose your keys ............ 481
Key number plate ................. 130
Keyless entry................ 132, 155
Mechanical key .................... 134
Power switch ................ 217, 219
Replacing the battery ........... 433
Warning buzzer .................... 156
Wireless remote control key . 132
Knee airbags ............................. 33
L
Lane Tracing Assist (LTA) ..... 268 Operation ............................. 268
Warning messages .............. 278
Language (multi-information dis- play) ....................... 113, 519, 520
LATCH anchors ........................ 59
LED accessory lights ............. 238 Replacing light bulbs ............ 439
Lever Auxiliary catch lever ............. 398
Hood lock release lever........ 398
Shift lever ............................. 226
Turn signal lever................... 230
Wiper lever ................... 244, 247
License plate lights Light switch .......................... 237
Replacing light bulbs ............ 439
Light bulbs Replacing ............................. 439
Wattage ................................ 504
Lights Automatic High Beam system
...........................................240
Fog light switch .....................244
Front interior lights................353
Headlight switch ...................237
Interior lights .........................353
Personal lights ......................353
Rear interior light ..................353
Replacing light bulbs ............439
Turn signal lever . ..................230
Vanity lights ..........................364
Wattage ................................504
LTA (Lane Tracing Assist) .....268 Operation..............................268
Warning messages ...............278
Luggage compartment light 144, 148
Luggage cover ........................361
M
Maintenance Do-it-yourself maintenance ..396
General maintenance ...........392
Maintenance data .................496
Maintenance requirements ...390
Malfunction indicator lamp ....457
Menu icons ..............................106
Meter Clock ......................................99
Hybrid System Indicator .......102
Indicators ................................90
Instrument panel light control97, 104
Meter control switches..106, 116
Meters ..............................93, 99
Multi-information display.....105,
115
Settings ........................110, 518
Units .....................113, 519, 520
Warning lights.................88, 456
Warning messag es .......114, 466
Meter control switches...106, 116
