± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
DI±819
1013 Author: Date:
2005 SEQUOIA (RM1146U)
*2: Comes on and goes off repeatedly at 0.25 second intervals.
*3: Comes on and goes off repeatedly at 0.125 second inter-
vals.

DIDK4±01
D13491
DLC3:
CG TC
F19148
Combination Meter
Tire Pressure
Warning Lamp
F19128
ON0.25 sec.
OFF
0.25 sec.
0.5 sec.
1.5 sec.4.5 sec. 2.5 sec.
0.5 sec. ON
OFF Normal System Code:
Code 13 and 33:
1.5 sec.
Repeat
D05981DLC3
Hand±Held
Tester
DI±820
± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
1014 Author: Date:
2005 SEQUOIA (RM1146U)
DTC CHECK / CLEAR
1. DTC CHECK (USING SST CHECK WIRE)
(a) Check DTCs.
(1) Using the SST, connect terminals TC and CG of
DLC3.
SST 09843±18040
(2) Turn the ignition switch to the ON position.
(3) Read and record any DTCs from the tire pressure
warning lamp on the combination meter. Refer to
the illustration on the left for examples of a normal
system code and codes 13 and 33.
HINT:

If the tire pressure warning lamp does not blink any DTCs
or the normal system code, inspect the tire pressure
warning lamp circuit or TC terminal circuit.
Trouble AreaSee page
Tire pressure warning lamp circuitDI±873
TC terminal circuitDI±888

If 2 or more malfunctions are indicated at the same time,
the lowest numbered DTC is displayed first.
(4) Refer to the Diagnostic Trouble Code Chart (see
page DI±825) for DTC information.
(5) After completing the check, turn the ignition switch
off and remove the SST from DLC3.
SST 09843±18040
2. DTC CHECK (USING HAND±HELD TESTER)
(a) Check DTCs.
(1) Connect the hand±held tester to the DLC3.
(2) Turn the ignition switch to the ON position.
(3) Read the DTCs following the prompts on the tester
screen.
HINT:
Refer to the hand±held tester operator's manual for further de-
tails.

± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
DI±821
1015 Author: Date:
2005 SEQUOIA (RM1146U)
3. DTC CLEAR
HINT:
After repairing the malfunctions, clear the DTCs.
(a) Connect the hand±held tester to DLC3.
(b) Turn the ignition switch to the ON position.
(c) Erase the DTCs following the prompts on the tester
screen.
HINT:
Refer to the hand±held tester operator's manual for further de-
tails.

DIDK5±01
DI±822
± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
1016 Author: Date:
2005 SEQUOIA (RM1146U)
DATA LIST / ACTIVE TEST
1. DATA LIST
(a) Connect the hand±held tester to DLC3.
(b) Turn the ignition switch to the ON position.
(c) Following the display on the hand±held tester, read the ºDATA LISTº.
ItemMeasurement item/
Range (Display)Normal ConditionDiagnostic Note
MODE STATUS
Tire pressure warning system
mode/NORMAL or REG 2nd or
REG M or TESTNORMAL: Normal mode
TEST: Test mode±
MAIN TIRENumber of main tire ID to be regis-
tered/0 or 1 or 2 or 3 or 4 or 50 to 5 should be displayed±
2ND TIRENumber of 2ND tire ID to be regis-
tered/0 to 1 or 2 or 3 or 4 or 50 to 5 should be displayed±
SELECT SWSelect switch/Main, 2ndMain±
INITIAL SWInitialization switch/ON, OFFON: Switch on
OFF: Switch off±
VEHICLE SPEED
Vehicle speed reading/
min.: 0 km/h (0 mph),
max.: 255 km/h (158 mph)
Actual vehicle speedSpeed indicated on the
combination meter
REGIT ID1 CODERegistered ID1 code/min.: 0,
max.: FFFFFFFThe ID No. registered in the trans-
mitter ID1 is displayed±
REGIT ID2 CODERegistered ID2 code/min.: 0,
max.: FFFFFFFThe ID No. registered in the trans-
mitter ID2 is displayed±
REGIT ID3 CODERegistered ID3 code/min.: 0,
max.: FFFFFFFThe ID No. registered in the trans-
mitter ID3 is displayed±
REGIT ID4 CODERegistered ID4 code/min.: 0,
max.: FFFFFFFThe ID No. registered in the trans-
mitter ID4 is displayed±
REGIT ID5 CODERegistered ID5 code/min.: 0,
max.: FFFFFFFThe ID No. registered in the trans-
mitter ID5 is displayed±
TRANS STATUSID code transmission status/
FINISH or NOWFINISH or NOW±
TIREPRESS1
ID1 tire inflation pressure/
min.: 0 kPa (0 kgfVcm2, 0 psi),
max.: 637.5 kPa (6.48 kgfVcm2,
92.2 psi)Actual tire inflation pressure±
TIREPRESS2
ID2 tire inflation pressure/
min.: 0 kPa (0 kgfVcm2, 0 psi),
max.: 637.5 kPa (6.48 kgfVcm2,
92.2 psi)Actual tire inflation pressure±
TIREPRESS3
ID3 tire inflation pressure/
min.: 0 kPa (0 kgfVcm2, 0 psi),
max.: 637.5 kPa (6.48 kgfVcm2,
92.2 psi)Actual tire inflation pressure±
TIREPRESS4
ID4 tire inflation pressure/
min.: 0 kPa (0 kgfVcm2, 0 psi),
max.: 637.5 kPa (6.48 kgfVcm2,
92.2 psi)Actual tire inflation pressure±
TIREPRESS5
ID5 tire inflation pressure/
min.: 0 kPa (0 kgfVcm2, 0 psi),
max.: 637.5 kPa (6.48 kgfVcm2,
92.2 psi)Actual tire inflation pressure±

± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
DI±823
1017 Author: Date:
2005 SEQUOIA (RM1146U)Item
Measurement item/
Range (Display)Normal ConditionDiagnostic Note
TIRE TEMP1
ID1 temperature in tire/
min.: ±40
C (±40
F),
max.: 215
C (419
F)
Actual tire temperature±
TIRE TEMP2
ID2 temperature in tire/
min.: ±40
C (±40
F),
max.: 215
C (419
F)
Actual tire temperature±
TIRE TEMP3
ID3 temperature in tire/
min.: ±40
C (±40
F),
max.: 215
C (419
F)
Actual tire temperature±
TIRE TEMP4
ID4 temperature in tire/
min.: ±40
C (±40
F),
max.: 215
C (419
F)
Actual tire temperature±
TIRE TEMP5
ID5 temperature in tire/
min.: ±40
C (±40
F),
max.: 215
C (419
F)
Actual tire temperature±
BATT VOLT1ID1 battery voltage/
OVER or LESSOVER±
BATT VOLT2ID2 battery voltage/
OVER or LESSOVER±
BATT VOLT3ID3 battery voltage/
OVER or LESSOVER±
BATT VOLT4ID4 battery voltage/
OVER or LESSOVER±
BATT VOLT5ID5 battery voltage/
OVER or LESSOVER±
SELECT SW INFOSelect switch setting information/
WITH or WITHOUTWITH or WITHOUT±
INITIAL SW INFOInitialization switch setting informa-
tion/WITH or WITHOUTWITH or WITHOUT±
INIT THRESHOLD1
ID1 initial threshold of low±pres-
sure/
min.: 0 kpa (0 kgf´cm, 0 psi),
max.: 637.5 kpa (6.48 kgf´cm, 92.2
psi)
Tire pressure after initialization±
INIT THRESHOLD2
ID2 initial threshold of low±pres-
sure/
min.: 0 kpa (0 kgf´cm, 0 psi),
max.: 637.5 kpa (6.48 kgf´cm, 92.2
psi)
Tire pressure after initialization±
INIT THRESHOLD3
ID3 initial threshold of low±pres-
sure/
min.: 0 kpa (0 kgf´cm, 0 psi),
max.: 637.5 kpa (6.48 kgf´cm, 92.2
psi)
Tire pressure after initialization±
INIT THRESHOLD4
ID4 initial threshold of low±pres-
sure/
min.: 0 kpa (0 kgf´cm, 0 psi),
max.: 637.5 kpa (6.48 kgf´cm, 92.2
psi)
Tire pressure after initialization±

DI±824
± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
1018 Author: Date:
2005 SEQUOIA (RM1146U) INIT THRESHOLD5
ID5 initial threshold of low±pres-
sure/
min.: 0 kpa (0 kgf´cm, 0 psi),
max.: 637.5 kpa (6.48 kgf´cm, 92.2
psi)
Tire pressure after initialization±
# CODESNumber of DTC recorded/
min.: 0, max.: 255Min.: 0, Max.: ±±

DIDK6±01
± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
DI±825
1019 Author: Date:
2005 SEQUOIA (RM1146U)
DIAGNOSTIC TROUBLE CODE CHART
HINT:

If no abnormality is found when the parts are inspected, inspect the tire pressure monitor ECU.

If a malfunction code is displayed during the DTC check, inspect the circuit listed for that code. For
details of each code, refer to the ºSee pageº under respective ºDTC No.º in the DTC chart.
DTC chart of Tire Pressure Warning:
DTC No.
(See Page)Detection ItemTrouble Area
C2111/11
(DI±827)Transmitter ID1 operation stop

Tire pressure monitor valve sub±assy

Tire pressure monitor receiver assy

Tire pressure monitor ECU
C2112/12
(DI±827)Transmitter ID2 operation stop

Tire pressure monitor valve sub±assy

Tire pressure monitor receiver assy

Tire pressure monitor ECU
C2113/13
(DI±827)Transmitter ID3 operation stop

Tire pressure monitor valve sub±assy

Tire pressure monitor receiver assy

Tire pressure monitor ECU
C2114/14
(DI±827)Transmitter ID4 operation stop

Tire pressure monitor valve sub±assy

Tire pressure monitor receiver assy

Tire pressure monitor ECU
C2115/15
(DI±827)Transmitter ID5 operation stop

Tire pressure monitor valve sub±assy

Tire pressure monitor receiver assy

Tire pressure monitor ECU
C2121/21
(DI±834)Transmitter ID1 not received

Tire pressure monitor valve sub±assy

Tire pressure monitor receiver assy

Tire pressure monitor ECU

Wire harness
C2122/22
(DI±834)Transmitter ID2 not received

Tire pressure monitor valve sub±assy

Tire pressure monitor receiver assy

Tire pressure monitor ECU

Wire harness
C2123/23
(DI±834)Transmitter ID3 not received

Tire pressure monitor valve sub±assy

Tire pressure monitor receiver assy

Tire pressure monitor ECU

Wire harness
C2124/24
(DI±834)Transmitter ID4 not received

Tire pressure monitor valve sub±assy

Tire pressure monitor receiver assy

Tire pressure monitor ECU

Wire harness
C2125/25
(DI±834)Transmitter ID5 not received

Tire pressure monitor valve sub±assy

Tire pressure monitor receiver assy

Tire pressure monitor ECU

Wire harness
C2141/41
(DI±842)Transmitter ID1 error

Tire pressure monitor valve sub±assy

Tire pressure monitor ECU

Tire pressure monitor receiver assy
C2142/42
(DI±842)Transmitter ID2 error

Tire pressure monitor valve sub±assy

Tire pressure monitor ECU

Tire pressure monitor receiver assy
C2143/43
(DI±842)Transmitter ID3 error

Tire pressure monitor valve sub±assy

Tire pressure monitor ECU

Tire pressure monitor receiver assy
C2144/44
(DI±842)Transmitter ID4 error

Tire pressure monitor valve sub±assy

Tire pressure monitor ECU

Tire pressure monitor receiver assy
C2145/45
(DI±842)Transmitter ID5 error

Tire pressure monitor valve sub±assy

Tire pressure monitor ECU

Tire pressure monitor receiver assy

DI±826
± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
1020 Author: Date:
2005 SEQUOIA (RM1146U)C2165/65
(DI±847)
Abnormal temperature inside ID1 tire

Tire pressure monitor valve sub±assy

Tire pressure monitor ECU

Tire pressure monitor receiver assy
C2166/66
(DI±847)Abnormal temperature inside ID2 tire

Tire pressure monitor valve sub±assy

Tire pressure monitor ECU

Tire pressure monitor receiver assy
C2167/67
(DI±847)Abnormal temperature inside ID3 tire

Tire pressure monitor valve sub±assy

Tire pressure monitor ECU

Tire pressure monitor receiver assy
C2168/68
(DI±847)Abnormal temperature inside ID4 tire

Tire pressure monitor valve sub±assy

Tire pressure monitor ECU

Tire pressure monitor receiver assy
C2169/69
(DI±847)Abnormal temperature inside ID5 tire

Tire pressure monitor valve sub±assy

Tire pressure monitor ECU

Tire pressure monitor receiver assy
C2171/71
(DI±852)Transmitter ID not registeredTire pressure monitor ECU
C2176/76
(DI±854)Receiver error

Tire pressure monitor receiver assy

Tire pressure monitor ECU

Wire harness
C2177/77
(DI±860)Initialization incomplete

Tire pressure monitor valve sub±assy

Tire pressure monitor ECU

Tire pressure monitor receiver assy

Wire harness
C2191/91
(DI±870)Vehicle speed signal error

Vehicle speed sensor

Tire pressure monitor ECU

Combination meter

Wire harness

DIDK7±01
± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
DI±827
1021 Author: Date:
2005 SEQUOIA (RM1146U)
CIRCUIT INSPECTION
DTC C2111/11 Transmitter ID1 Operation Stop
DTC C2112/12 Transmitter ID2 Operation Stop
DTC C2113/13 Transmitter ID3 Operation Stop
DTC C2114/14 Transmitter ID4 Operation Stop
DTC C2115/15 Transmitter ID5 Operation Stop
CIRCUIT DESCRIPTION
The tire pressure monitor valve sub±assy stops transmitting signals when receiving specific signals. The
ECU stores the DTCs when the tire pressure monitor valve sub±assy receives the signals, for some reason,
and stops transmitting signals. As this is not a system malfunction, the DTCs are erased when signal trans-
mission is resumed.
HINT:
The electric wave is stopped at assembly plant, because the strength of the electric wave emitting from the
tire pressure sensing transmitter does not comply with the Japan Wireless Telegraphy Act.
DTC No.DTC Detecting ConditionTrouble Area
C2111/11
C2112/12
C2113/13
C2114/14
C2115/15
When any signal similar to the stop signal is received for
some reason, these DTCs will be output.
Tire pressure monitor valve sub±assy

Tire pressure monitor receiver assy

Tire pressure monitor ECU
HINT:
It is necessary to perform the procedure to identify the tire pressure monitor valve sub±assy that is malfunc-
tioning because it cannot be identified by the output DTC.

DI±828
± DIAGNOSTICSTIRE PRESSURE WARNING SYSTEM
1022 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
NOTICE:
It is necessary to register an ID code after replacing the tire pressure monitor valve sub±assy and/or
the tire pressure monitor ECU (see page DI±805).
HINT:
Set the tire pressure to the specified value.
1 Forcibly transmit transmitter ID of all wheels.
PREPARATION:
Remove the valve cores of the all wheels to rapidly reduce the pressure of all tires to 120 kPa (1.2 kgf/cm2,
17 psi respectively).
HINT:
The transmitter ID can be transmitted forcibly by rapidly reducing tire air pressure.
NEXT
2 Check DTC (See page DI±820).
CHECK:
Check for a DTC.
OK:
DTC is not output.
OK Set tire pressure to normal value (Transmitter
stop condition is completely reset).
NG
3 Set tire pressure to normal value.
PREPARATION:
Set the tire pressure back to the specified normal value.
Tire sizeFrontRearSpare
P245 / 70 R 16220 kPa (2.2 kgf/cm2, 32 psi)240 kPa (2.4 kgf/cm2, 35 psi)240 kPa (2.4 kgf/cm2, 35 psi)
P265 / 70 R 16220 kPa (2.2 kgf/cm2, 32 psi)220 kPa (2.2 kgf/cm2, 32 psi)220 kPa (2.2 kgf/cm2, 32 psi)
P265 / 65 R 17220 kPa (2.2 kgf/cm2, 32 psi)220 kPa (2.2 kgf/cm2, 32 psi)220 kPa (2.2 kgf/cm2, 32 psi)
NEXT
