TOYOTA SEQUOIA 2001 Service Repair Manual

F19196
E5
ECM
CANL
CANH34
33W
L2
J53
1
J532
J55
1
J55 J/C
W
R16
T5
14
T5ENG±
ENG+
VSC+
VSC± 7
T5
11
T5 L
W WL7
IL2
6
IL2 26 S1 ABS & VSC Actuator
(Skid Control ECU)Translate
ECU
IG1 1
T5 B±R
J37 J37J/C Sub J/B No.3
8
3C 8
3AB±R
B±R
B±Y
W±L I18
Ignition SW
WInstrument Panel J/B
4
1F
1
1L4
1C
6
1C ECU±IG
AM1
AM1 IG1
ALT
BatteryGND 40
T5 J43
J/C
O
A A O
IG1
2 CANH
CANL
A
A
8
5
BF10
Fusible Link
Block
(*1)
(*1)
(*2)
(*2)
(*1) Vehicle CAN Circuit
(*2) CAN1 Circuit (*1)
(*1)
(*2)
(*2)
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
DI±999
1193 Author: Date:
2005 SEQUOIA (RM1146U)
WIRING DIAGRAM

F19152
Translate ECU
GND
DI±1000
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
1194 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
1 Check the DTC of the VSC (See page DI±911).
CHECK:
Check skid control ECU DTC.
RESULT:
DTC is not outputA
DTC (C1203/53) is outputB
B Repair circuit indicated by the output code
(See page DI±921).
A
2 Check for open circuit in harness and connector between GND terminal of the
translate ECU and body ground.
PREPARATION:
Disconnect the translate ECU connector.
CHECK:
Measure the resistance between the GND terminal and body
ground.
OK:
Continuity
NG Repair or replace harness or connector (Trans-
late ECU GND circuit).
OK

± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
DI±1001
1195 Author: Date:
2005 SEQUOIA (RM1146U)
3 Replace the translate ECU and check if the trouble occurs again.
PREPARATION:
(a) Clear the translate DTC (See page DI±911).
(b) Turn the ignition switch OFF.
CHECK:
Turn the ignition switch to the ON position, and check if the same DTC is stored in the memory.
PREPARATION:
DTC 53 is not outputA
DTC 53 is outputB
B Replace skid control ECU
(See page BR±52).
NOTICE:
When replacing the skid control ECU, perform zero point
calibration (See page DI±897).
A
END

F19197
S1 ABS & VSC Actuator
(Skid Control ECU)Translate
ECU
CANH
CANL6
2L
WL
W 7
IL2
6
IL27
T5
11
T5VSC+
VSC±
IG1 1
T5 B±R
J37 J37J/C
B±R
B±R8
3C 8
3A
I18
Ignition SW
4
1F4
1C
1L6
1C ECU±IG
AM1
AM1 IG1
B±Y
2
W±L W
ALT
Battery24
T5
40
T5LVL2
GND 23
IA1 9
IA5Y±L Y±L W±B O
A
O A
AB1
Brake Fluid
Level Warning SW
J43
J/C
IG 1Sub J/B No.3
Instrument Panel J/B
8
5F10
Fusible Link Block
B1
1 2
2A
A
1
(*) CAN1 Circuit (*)(*)
(*)
(*) DI±1002
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
1196 Author: Date:
2005 SEQUOIA (RM1146U)
DTC 58 Malfunction of Brake Fluid Level Warning
Switch
CIRCUIT DESCRIPTION
The brake fluid level warning switch sends the appropriate signal to the translate ECU.
This signal indicates a drop in brake fluid level.
DTC No.DTC Detecting ConditionTrouble Area
58

Brake fluid level warning switch connector is disconnected
for 1 sec. or more.

Brake fluid level warning switch is ON for 30 sec. or more.
Brake fluid level warning switch circuit

Brake fluid level warning switch

Brake fluid reservoir level

Translate ECU
WIRING DIAGRAM
DIDMI±01

F18069
P2
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
DI±1003
1197 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
1 Check the DTC of the VSC (See page DI±911).
CHECK:
Check skid control ECU DTC.
RESULT:
DTC is not outputA
DTC (C1202 / 52) is outputB
B Repair circuit indicated by the output code
(See page DI±921).
A
2 Check brake fluid level warning switch.
PREPARATION:
Disconnect the brake fluid level warning switch connector.
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionSwitch ConditionSpecified Condition
(B2±1) ± (B2±2)Float UP10 kW or more
(No continuity)
(B2±1) ± (B2±2)Float DOWN1 W or less (Continuity)
NG Replace brake fluid level warning switch.
OK
3 Check for open and short circuit in harness and connector between brake fluid
level warning switch and translate ECU (See page IN±35).
NG Repair or replace harness or connector.
OK

DI±1004
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
1198 Author: Date:
2005 SEQUOIA (RM1146U)
4 Replace the translate ECU and check if the trouble occurs again.
PREPARATION:
(a) Clear the translate DTC (See page DI±911).
(b) Turn the ignition switch OFF.
CHECK:
Turn the ignition switch to the ON position, and check if the same DTC is stored in the memory.
PREPARATION:
DTC 58 is not outputA
DTC 58 is outputB
B Replace skid control ECU
(See page BR±52).
NOTICE:
When replacing the skid control ECU, perform zero point
calibration (See page DI±897).
A
END

± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
DI±1005
1199 Author: Date:
2005 SEQUOIA (RM1146U)
DTC 65 Malfunction 1 of Vehicle CAN
CIRCUIT DESCRIPTION
The circuit is used to send TRAC&VSC control information from the skid control ECU to the ECM, and engine
control information from the ECM to the skid control ECU via the CAN communication system.
This DTC is output when communication between the translate ECU and the skid control ECU is cut off.
DTC No.DTC Detecting ConditionTrouble Area
65
Any of the following 1. through 3. is detected when IG1
voltage is 8.5 V or more and vehicle speed exceeds by 9
mph (15 km/h) or more.
1. Condition that signal cannot be received from ECM at
least once within 5 sec. occurs 10 times or more within
60 seconds.
2. Signal cannot be received continuously for 2 sec. or
more.
3. Condition that signal cannot be sent to ECM at least
once within 5 sec. occurs 10 times or more within 60
seconds.

ENG+, ENG± circuit (CAN communication system)

ECM

Translate ECU

Suspension control ECU
DIDMJ±01

F19799
S25
Suspension Control ECU
CANL
CANH34
33W
L2
J53
12
J55
1
J55W
R16
T5
14
T5ENG±
ENG+
VSC+
VSC± 7
T5
11
T5 L
W
WL7
IL2
6
IL2 26 S1 ABS & VSC Actuator
(Skid Control ECU)Translate
ECU
IG1 1
T5 B±R
J37 J37J/C Sub J/B No.3
8
3C 8
3AB±R B±R
B±Y
W±L I18
Ignition SW
WInstrument Panel J/B
4
1F
1
1L4
1C
6
1C ECU±IG
AM1
AM1 IG1
ALT
BatteryGND 40
T5 J43
J/C
O
A A O
IG1
2 CANH
CANL
AA
8
5
BF10
Fusible Link
Block
J53J56 J5612 W
G 28
29 CANL
CANH
E5
ECM
(*1) Vehicle CAN Circuit
(*2) CAN1 Circuit (*1)
(*2)(*1)
(*1)
(*1)(*1)
(*1)
(*2)(*2)
(*2) DI±1006
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
1200 Author: Date:
2005 SEQUOIA (RM1146U)
WIRING DIAGRAM

F19152
Translate ECU
GND
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
DI±1007
1201 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION PROCEDURE
1 Check DTC of the VSC (See page DI±911).
CHECK:
Check skid control ECU DTC.
RESULT:
DTC is not outputA
DTC is outputB
B Repair circuit indicated by the output code
(See page DI±921).
A
2 Check for open circuit in harness and connector between GND terminal of the
translate ECU and body ground (See page IN±35).
PREPARATION:
Disconnect the translate ECU connector.
CHECK:
Measure the resistance between the GND terminal and body
ground.
OK:
Continuity
NG Repair or replace harness or connector (Trans-
late ECU GND circuit.
OK

DI±1008
± DIAGNOSTICSABS WITH EBD & BA & TRAC & VSC SYSTEM
1202 Author: Date:
2005 SEQUOIA (RM1146U)
3 Replace the translate ECU and check if the trouble occurs again.
PREPARATION:
(a) Clear the translate DTC (See page DI±911).
(b) Turn the ignition switch OFF.
CHECK:
Turn the ignition switch to the ON position, and check if the same DTC is stored in the memory.
PREPARATION:
DTC 65 is not outputA
DTC 65 is outputB
B Check and replace suspension control ECU,
ECM or CAN communication system.
A
END
