TOYOTA SEQUOIA 2001 Service Repair Manual

H41475H23348
D Squib
(Dual stage ±
2nd step)
D2+ D2±
Spiral
CableAirbag
Sensor
Assembly
Color: Black
A
B D EC F
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1389
1583 Author: Date:
2005 SEQUOIA (RM1146U)
6 Check D squib (dual stage ± 2nd step) circuit (short to B+).
PREPARATION:
Connect the negative (±) terminal cable to the battery, and wait
for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position.
(b) Measure the voltage according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
D2+ ± Body groundIgnition switch ONBelow 1 V
D2± ± Body groundIgnition switch ONBelow 1 V
NG Go to step 19.
OK
Go to step 11.
7 Check connector.
CHECK:
Check that the spiral cable connectors (on the steering wheel pad side) are not damaged.
OK:
The lock button is not disengaged, or the claw of the lock is not deformed or damaged.
NG Replace spiral cable (see page RS±21).
OK

H41475H23348
D Squib
(Dual stage ±
2nd step)
D2+ D2±
Spiral
CableAirbag
Sensor
Assembly
Color: Black
A
B D EC F
DI±1390
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1584 Author: Date:
2005 SEQUOIA (RM1146U)
8 Check D squib (dual stage ± 2nd step) circuit.
PREPARATION:
Connect the negative (±) terminal cable to the battery, and wait
for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position.
(b) Measure the voltage according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
D2+ ± Body groundIgnition switch ONBelow 1 V
D2± ± Body groundIgnition switch ONBelow 1 V
PREPARATION:
(a) Turn the ignition switch to the LOCK position.
(b) Disconnect the negative (±) terminal cable from the bat-
tery, and wait for at least 90 seconds.
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
D2+ ± D2±AlwaysBelow 1 W
D2+ ± Body groundAlways1 MW or higher
D2± ± Body groundAlways1 MW or higher
PREPARATION:
Release the activation prevention mechanism built into con-
nector ºBº (see page DI±1137).
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
D2+ ± D2±Always1 MW or higher
NG Go to step 21.
OK

H01003H10600H01077H23361
Spiral
CableAirbag
Sensor
Assembly
DTC 53
DLC3
TC
CG
D Squib
(Dual stage ±
2nd step)
E F
C D
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1391
1585 Author: Date:
2005 SEQUOIA (RM1146U)
9 Replace steering wheel pad (D squib, dual stage ± 2nd step).
PREPARATION:
(a) Replace the steering wheel pad (see page RS±21).
HINT:
Perform the inspection using parts from a normal vehicle if pos-
sible.
(b) Connect the connectors to the airbag sensor assembly.
(c) Connect the negative (±) terminal cable to the battery,
and wait for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(b) Clear the DTCs stored in memory (see page DI±1147).
(c) Turn the ignition switch to the LOCK position.
(d) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(e) Check the DTCs (see page DI±1147).
OK:
DTC 53 is not output.
HINT:
Codes other than DTC 53 may be output at this time, but they
are not related to this check.
NG Replace airbag sensor assembly
(see page RS±82).
OK
END

H01002H23349
Spiral
CableAirbag
Sensor
Assembly D Squib
(Dual stage ±
2nd step)
C ED F
DI±1392
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1586 Author: Date:
2005 SEQUOIA (RM1146U)
10 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connectors to the airbag sensor assembly.
(b) Connect the negative (±) terminal cable to the battery,
and wait for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(b) Clear the DTCs stored in memory (see page DI±1147).
(c) Turn the ignition switch to the LOCK position.
(d) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(e) Check the DTCs (see page DI±1147).
OK:
DTC B1810 is not output.
HINT:
Codes other than DTC B1810 may be output at this time, but
they are not related to this check.
NG Replace airbag sensor assembly
(see page RS±82).
OK
Go to step 12.

H01002C89252H23353
D2+ D2±
Spiral
Cable D Squib
(Dual stage ±
2nd step)
Color: Black Service Wire
C E
D FAirbag
Sensor
Assembly
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1393
1587 Author: Date:
2005 SEQUOIA (RM1146U)
11 Check airbag sensor assembly.
PREPARATION:
(a) From the step 6:
Turn the ignition switch to the LOCK position.
(b) From the step 6:
Disconnect the negative (±) terminal cable from the bat-
tery, and wait for at least 90 seconds.
(c) Connect the connectors to the airbag sensor assembly.
(d) Using a service wire, connect D2+ and D2± of connector
ºEº.
NOTICE:

Twist the end of the service wire in order to insert it
into the connector.

Do not forcibly insert the twisted service wire into the
terminals of the connector when connecting.
(e) Connect the negative (±) terminal cable to the battery,
and wait for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(b) Clear the DTCs stored in memory (see page DI±1147).
(c) Turn the ignition switch to the LOCK position.
(d) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(e) Check the DTCs (see page DI±1147).
OK:
DTC B1811, B1812 or B1813 is not output.
HINT:
Codes other than DTC B1811, B1812 and B1813 may be out-
put at this time, but they are not related to this check.
NG Replace airbag sensor assembly
(see page RS±82).
OK

H01003H23354
Spiral
CableAirbag
Sensor
Assembly D Squib
(Dual stage ±
2nd step)
C ED F
DI±1394
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1588 Author: Date:
2005 SEQUOIA (RM1146U)
12 Check steering wheel pad (D squib, dual stage ± 2nd step).
PREPARATION:
(a) Turn the ignition switch to the LOCK position.
(b) Disconnect the negative (±) terminal cable from the bat-
tery, and wait for at least 90 seconds.
(c) From the step 11:
Disconnect the service wire from connector ºEº.
(d) Connect the connectors to the steering wheel pad.
(e) Connect the negative (±) terminal cable to the battery,
and wait for at least 2 seconds.
CHECK:
(a) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(b) Clear the DTCs stored in memory (see page DI±1147).
(c) Turn the ignition switch to the LOCK position.
(d) Turn the ignition switch to the ON position, and wait for at
least 60 seconds.
(e) Check the DTCs (see page DI±1147).
OK:
DTC B1810, B1811, B1812 or B1813 is not output.
HINT:
Codes other than DTC B1810, B1811, B1812 and B1813 may
be output at this time, but they are not related to this check.
NG
Replace steering wheel pad
(see page RS±21).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check (see page DI±1137).
HINT:

Perform the simulation method by selecting the check mode with the hand±held tester (see page
DI±1151).

After selecting the check mode, perform the simulation method by wiggling each connector of the air-
bag system or driving the vehicle on a city or rough road (see page DI±1151).

H41440H23351
Spiral
CableAirbag
Sensor
Assembly
D2+
D2±
D Squib
(Dual stage ±
2nd step)
B C ED FACowl Wire
A23
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1395
1589 Author: Date:
2005 SEQUOIA (RM1146U)
13 Check cowl wire (short).
PREPARATION:
Disconnect the cowl wire connector from the spiral cable.
HINT:
The activation prevention mechanism of connector ºBº has al-
ready been released.
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
A23±4 (D2+) ±
A23±3 (D2±)Always1 MW or higher
NG Repair or replace cowl wire.
OK

H41479H23350
Spiral
CableAirbag
Sensor
Assembly
D2+
D2±
D Squib
(Dual stage ±
2nd step)
Color: Black
A
B D EC F
DI±1396
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1590 Author: Date:
2005 SEQUOIA (RM1146U)
14 Check spiral cable (short).
PREPARATION:
Release the activation prevention mechanism built into con-
nector ºDº (see page DI±1137).
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
D2+ ± D2±Always1 MW or higher
NG Replace spiral cable (see page RS±21).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check (see page DI±1137).
HINT:

Perform the simulation method by selecting the check mode with the hand±held tester (see page
DI±1151).

After selecting the check mode, perform the simulation method by wiggling each connector of the air-
bag system or driving the vehicle on a city or rough road (see page DI±1151).

H41440H23351
Spiral
CableAirbag
Sensor
Assembly
D2+
D2±
D Squib
(Dual stage ±
2nd step)
B C ED FACowl Wire
A23
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±1397
1591 Author: Date:
2005 SEQUOIA (RM1146U)
15 Check cowl wire (open).
PREPARATION:
Disconnect the cowl wire connector from the spiral cable.
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
A23±4 (D2+) ±
A23±3 (D2±)AlwaysBelow 1 W
NG Repair or replace cowl wire.
OK

H41479H23350
Spiral
CableAirbag
Sensor
Assembly
D2+
D2±
D Squib
(Dual stage ±
2nd step)
Color: Black
A
B D EC F
DI±1398
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
1592 Author: Date:
2005 SEQUOIA (RM1146U)
16 Check spiral cable (open).
CHECK:
Measure the resistance according to the value(s) in the table
below.
OK:
Tester ConnectionConditionSpecified Condition
D2+ ± D2±AlwaysBelow 1 W
NG Replace spiral cable (see page RS±21).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check (see page DI±1137).
HINT:

Perform the simulation method by selecting the check mode with the hand±held tester (see page
DI±1151).

After selecting the check mode, perform the simulation method by wiggling each connector of the air-
bag system or driving the vehicle on a city or rough road (see page DI±1151).
