4wd TOYOTA SEQUOIA 2001 Service Repair Manual

IN±44
± INTRODUCTIONTERMS
44 Author: Date:
2005 SEQUOIA (RM1146U) T/M
Transmission
TMCTOYOTA Motor Corporation
TMMKTOYOTA Motor Manufacturing Kentucky, Inc.
TRCTraction Control System
TURBOTurbocharge
TWCThree±Way Catalyst
U/DUnderdrive
U/SUndersize
VCVVacuum Control Valve
VENTVentilator
VIMVehicle Interface Module
VINVehicle Identification Number
VPSVariable Power Steering
VSCVehicle Skid Control
VSVVacuum Switching Valve
VTVVacuum Transmitting Valve
VVT±iVariable Valve Timing±intelligent
W/With
WGNWagon
W/HWire Harness
W/OWithout
1STFirst
2NDSecond
2WDTwo Wheel Drive Vehicle (4 x 2)
3RDThird
4THFourth
4WDFour Wheel Drive Vehicle (4 x 4)
4WSFour Wheel Steering System
5THFifth

B07270
MA04O±03
B07272
Drive Shaft Boots
B07271
Dust Cover
Z04824
A/T
OK if coolOK if hot
Add if coolAdd if hot
± MAINTENANCECHASSIS
MA±7
54 Author: Date:
2005 SEQUOIA (RM1146U)
CHASSIS
INSPECTION
1. INSPECT STEERING LINKAGE
(a) Check the steering wheel free play (See page SR±9).
(b) Check the steering linkage for looseness or damage.
Check that:

Tie rod ends do not have excessive play.

Dust seals are not damaged.

Boot clamps are not loose.
2. INSPECT SRS AIRBAG (See page RS±3)
3. INSPECT STEERING GEAR HOUSING OIL
Check the steering gear housing for oil leaks.
If leakage is found, check the cause and repair.
4. 4WD:
INSPECT DRIVE SHAFT BOOTS
Inspect the drive shaft boots for clamp looseness, grease leak-
age or damage.
5. INSPECT BALL JOINTS AND DUST COVERS
(a) Inspect the ball joints for excessive looseness.
(b) Inspect the dust cover for damage.
6. 2WD:
CHECK OIL LEVEL IN AUTOMATIC TRANSMISSION
AND DIFFERENTIAL
(a) Automatic transmission:
Check that the fluid level is in the ºHOTº range at the nor-
mal operating temperature (70 ± 80°C or 158 ± 176°F)
and add as necessary.
NOTICE:
Do not overfill.
Transmission fluid (A/T): See page
DI±524

B07273
Filler Plug
Differential
Z04824
A/T
OK if coolOK if hot
Add if coolAdd if hot
P23117
Filler Plug
Transfer
B07968
Differential
Front
RearFiller Plug
Filler Plug MA±8
± MAINTENANCECHASSIS
55 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Differential:
Remove the filler plug and feel inside the hole with your
finger. Check that the oil comes to within 5 mm (0.20 in.)
of the bottom edge of the hole. If the level is low, add oil
until it reaches the bottom of the filler hole.
Differential oil: See page SA±129
7. 4WD:
CHECK OIL LEVEL IN AUTOMATIC TRANSMISSION,
TRANSFER AND DIFFERENTIAL
(a) Automatic transmission:
Check that the fluid level is in the ºHOTº range at the nor-
mal operating temperature (70 ± 80°C or 158 ± 176°F)
and add as necessary.
NOTICE:
Do not overfill.
Transmission fluid (A/T): See page DI±524
(b) Transfer:
Remove the filler plug and feel inside the hole with your
finger. Check that the oil comes to within 5 mm (0.20 in.)
of the bottom edge of the hole. If the level is low, add oil
until it reaches the bottom of the filler hole.
Transfer oil: See page TR±4
(c) Differential:
Remove the filler plug and feel inside the hole with your
finger. Check that the oil comes to within 5 mm (0.20 in.)
of the bottom edge of the hole. If the level is low, add oil
until it reaches the bottom of the filler hole.
Front differential oil: See page SA±38
Rear differential oil: See page SA±129

B13807
A: Propeller Shaft Spiders
B: Propeller Shaft Sliding YokesAB
A
A
MA0568
MA±10
± MAINTENANCECHASSIS
57 Author: Date:
2005 SEQUOIA (RM1146U)
(b) Recoat the drive shaft thrust bush with grease (See page
SA±34).
11. 4WD:
LUBRICATE PROPELLER SHAFT AND TIGHTEN
BOLTS
(a) Lubricate the propeller shaft, referring to the lubrication
chart. Before pumping in grease, wipe off any mud and
dust on the grease fitting.
Grease grade:
Propeller shaft (Except Double±cardan joint)
Lithium base chassis grease NLGI No.2
(b) Tighten the bolts for propeller shaft.
(2WD: See page PR±5)
(4WD: See page PR±9)
12. ROTATE TIRE (See page SA±3)
13. TIGHTEN BOLTS AND NUTS ON CHASSIS AND BODY
(a) Tighten the following parts:

Seat mounting bolts
Torque:
37 N´m (375 kgf´cm, 27 ft´lbf)

SS1M7±01
± SERVICE SPECIFICATIONSPROPELLER SHAFT
SS±29
171 Author: Date:
2005 SEQUOIA (RM1146U)
PROPELLER SHAFT
SERVICE DATA
Propeller shaftRunout Maximum0.8 mm (0.031 in.)
Spider bearing
axial playMaximum
4WD rear propeller shaft
2WD and 4WD front propeller shaft
0.05 mm (0.0020 in.)
0.05 mm (0.0020 in.)
4WD rear
propeller shaft
Snap ring thickness Color/Mark
None
Light brown
Blue
None
1
2
3
4
5
6
7
8
9
10
2.00 mm (0.0784 in.)
2.03 mm (0.0799 in.)
2.06 mm (0.0811 in.)
2.09 mm (0.0823 in)
1.99 mm (0.0783 in.)
2.01 mm (0.0791 in.)
2.03 mm (0.0799 in.)
2.05 mm (0.0807 in.)
2.07 mm (0.0815 in.)
2.09 mm (0.0823 in.)
2.11 mm (0.0831 in.)
2.13 mm (0.0839 in.)
2.15 mm (0.0846 in.)
2.17 mm (0.0854 in.)
2WD and 4WD
front propeller
shaft
Snap ring thickness Color
Blue
Yellow
Silver
Copper
Black
Red
Green
1.638 mm (0.0645 in.)
1.588 mm (0.0625 in.)
1.537 mm (0.0605 in.)
1.511 mm (0.0595 in.)
1.486 mm (0.0585 in.)
1.435 mm (0.0565 in.)
1.384 mm (0.0545 in.)

SS07Z±05
SS±30
± SERVICE SPECIFICATIONSPROPELLER SHAFT
172 Author: Date:
2005 SEQUOIA (RM1146U)
TORQUE SPECIFICATION
Part tightenedN´mkgf´cmft´lbf
Propeller shaft assembly (2WD)
Propeller shaft x Differential
8889765
Propeller shaft assembly (4WD)
Front propeller shaft x Front differential
Front propeller shaft x Transfer
Rear propeller shaft x Rear differential
Rear propeller shaft x Transfer
74
88
88
88750
897
897
89754
65
65
65

SS±38
± SERVICE SPECIFICATIONSSUSPENSION AND AXLE
180 Author: Date:
2005 SEQUOIA (RM1146U)
Air suspension
Amount of change in vehicle height
HIGH position:
LOW position (4WD):
LOW position (2WD):
40 mm (1.57 in.)
±30 mm (±1.18 in.)
±15 mm (±0.59 in.)
Air suspension
Difference between the tester value and vehicle height
(D±C measurement):
5 mm (0.20 in.) or less
Height control sensor link standard length:6.5 ± 15.0 mm (0.26 ± 0.59 in.) or less

± DIAGNOSTICSENGINE
DI±55
249 Author: Date:
2005 SEQUOIA (RM1146U)DIST DTC CLEAR
Distance after DTC cleared:
Min.: 0 km/h, Max.: 65535 km/hEquivalent to drive distance after
DTCs were erased'
WU CYC DTC CLEARWarm±up cycle after DTC cleared:
Min.: 0, Max.: 255'Number of warm±up cycles after
DTC cleared
MODEL CODEModel code:'Identifying the model code:
UCK30 (2WD), UCK40 (4WD)
ENGINE TYPEEngine type:'Identifying the engine type:
2UZFE
CYLINDER NUMBERCylinder number:
Min.: 0, Max.: 255'Identifying the cylinder number:
8
TRANSMISSIONTransmission type:'Identifying the transmission type:
ECT(5AT)
DESTINATIONDestination'Identifying the destination:
A (America)
MODEL YEARModel year:
Min.: 0, Max.: 255'Identifying the model year:
200#
SYSTEMSystem identification'Identifying the engine system:
GASLIN (gasoline engine)
AI STATUSAI operation prohibit:
OK or NGOK
*1: If no idling conditions are specified, the transmission gear selector lever should be in the N or P position,
and the A/C switch and all accessory switches should be OFF.
2. ACTIVE TEST
HINT:
Performing an ACTIVE TEST enables components including the relays, VSV (Vacuum Switching Valve),
and actuators, to be operated without removing any parts. The ACTIVE TEST can be performed with a
hand±held tester. Performing an ACTIVE TEST as the first step of troubleshooting is one method of shorten-
ing diagnostic time.
DATA LIST can be displayed during ACTIVE TESTs.
(a) Connect a hand±held tester to the DLC3.
(b) Turn the ignition switch to ON.
(c) Turn the tester ON.
(d) Select the following menu items: DIAGNOSIS / ENHANCED OBD II / ACTIVE TEST.
(e) Perform the ACTIVE TEST by referring to the table below.
Hand±held Tester DisplaysTest DetailsControl RangesDiagnostic Notes
INJ VOLChange injection volumeBetween ±12 % and 25 %

All injectors tested at the same
time

Perform test at less than 3,000
rpm

Injection volume can be changed
in 1 % graduations within control
range
A/F CONTROLChange injection volumeLower by 12.5 % or increase by 25
%

Perform test at less than 3,000
rpm

A/F CONTROL enables checking
and graphing of A/F (Air Fuel Ra-
tio) sensor and Heated Oxygen
(HO2) sensor voltage outputs

To conduct test, select following
menu items: ACTIVE TEST / A/F
CONTROL / USER DATA / AFS
B1S1 and O2S B1S2, and press
YES and ENTER followed by F4
EVAP VSV (ALONE)Activate EVAP VSV controlON/OFF±

DIDIK±01
D13871
Combination Meter
DLC3 Stop Light SwitchECM
Park/Neutral Position SwitchSpeed Sensor (SP2) Shift Solenoid Valve S1
Shift Solenoid Valve SR
Shift Solenoid Valve SLU
Shift Solenoid Valve SL2 ATF Temperature
Sensor No. 2Integration Control and Panel
(Shift Position L Switch)
MIL
Shift Solenoid Valve SL1
Shift Solenoid
Valve SLT
ATF Temperature
Sensor No.1
Shift Solenoid Valve S2
Speed Sensor (NT)

AT Oil Temp Warning LightShift Lever
(O/D Main Switch)
4WD:
4WD Control ECU
± DIAGNOSTICSAUTOMATIC TRANSMISSION
DI±519
713 Author: Date:
2005 SEQUOIA (RM1146U)
LOCATION

DIDIL±01
D14205
Shift Solenoid Valve S1
MIL
(Malfunction Indicator Lamp) S1
S2
SL1
SL2
SLT
SLU
SR
WShift Solenoid Valve S2
Shift Solenoid Valve SL1
Shift Solenoid Valve SL2
Shift Solenoid Valve SLT
Shift Solenoid Valve SLU
Shift Solenoid Valve SR
OILW
AT Oil Temp Warning Light ECM Crankshaft Position Sensor
Engine CoolantTemperature Sensor
Combination Meter
Stop Lamp Switch Assy
DLC3
(Data Link Connector 3)THW VTA1, 2
VC
SPD
STPTH01
TC Throttle Position Sensor
ATF (Automatic Transmission
Fluid) Temperature Sensor No. 1Mass Air Flow Meter
Accelerator Pedal Position SensorVPA
VPA2
Shift Lever
(O/D Main Switch)
Input Speed Sensor (NT)NT
Output Speed Sensor (SP2)SP2
TH02
ATF (Automatic Transmission
Fluid) Temperature Sensor No. 2Skid Control ECUNSW
Park/Neutral Position Switch
R, D, 3, 2
VG
NE
L
ODMSIntegration Control and Panel
(Shift Position L Switch)
L4



: 4WD4WD Control ECU
CAN DI±520
± DIAGNOSTICSAUTOMATIC TRANSMISSION
714 Author: Date:
2005 SEQUOIA (RM1146U)
SYSTEM DIAGRAM
The configuration of the electronic control system in the A750E/A750F automatic transmission is as shown
in the following chart.
