jack points TOYOTA SEQUOIA 2003 1.G Owners Manual

03_SEQUOIA_U (L/O 0301)
325
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
FrontRear
5. Position the jack at the correct jack
point as shown.
Make sure the jack is positioned on a
level and solid place.
JACK POINTS: Front—Under the frame side rail
Rear—Under the rear axle housingPut a jack handle, jack handle extension
and jack handle end together as shown in
the illustration.
1 Jack handle end
2 Jack handle extension
3 Jack handle
NOTICE
Tighten all joints securely. Otherwise,
the extension may come off and it
may damage the paint or vehicle
body.
6. After making sure that no one is inthe vehicle, raise it high enough so
that the spare tire can be installed.
Remember you will need more ground
clearance when putting on the spare tire
than when removing the flat tire.
To raise the vehicle, insert the jack handle
extension in to the jack (it is a loose fit)
and turn it clockwise with the handle,
making sure the handle remains firmly
fitted onto the jack handle extension. As
the jack touches the vehicle and begins
to fit, doublecheck that it is properly
positioned.
—Positioning the jack —Raising your vehicle
