tow TOYOTA SEQUOIA 2003 1.G Owners Manual

03_SEQUOIA_U (L/O 0301)
30
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
When closing the back door, use the
inside strap for easier reach to the
back door.
To close the back door, lower it and press
down on it. After closing the back door,
try pulling it up to make sure it is secure-
ly closed.
See “Luggage stowage precautions” on
page 292 in Section 2 for precautions in
loading luggage.
CAUTION
Keep the back window and back door
closed while driving. This not only
keeps the luggage from being thrown
out but also prevents exhaust gases
from entering the vehicle.
NOTICE
To prevent damage to the back door
dampers, do not apply any force,
paint or let any other foreign matter
on them.
Driver’s side
Passenger’s side

03_SEQUOIA_U (L/O 0301)
40
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
While the vehicle is being driven, all ve-
hicle occupants should have the seatback
upright, sit well back in the seat and prop-
erly wear the seat belts provided.
CAUTION
Do not drive the vehicle unless the
occupants are properly seated. Do
not allow passengers to sit on top
of a foldeddown seatback, or in
the luggage compartment or cargo
area. Persons not properly seated
and/or properly restrained by seat
belts can be severely injured in the
event of emergency braking or a
collision.
During driving, do not allow pas-
sengers to stand up or move
around between seats. Otherwise,
severe injuries can occur in the
event of emergency braking or a
collision.
Driver seat
CAUTION
The SRS driver airbag deploys with
considerable force, and can cause
death or serious injury especially if
the driver is very close to the airbag.
The National Highway Traffic Safety
Administration (“NHTSA”) advises:
Since the risk zone for driver airbag
is the first 50—75 mm (2—3 in.) of
inflation, placing yourself 250 mm (10
in.) from your driver airbag provides
you with a clear margin of safety.
This distance is measured from the
center of the steering wheel to your
breastbone. If you sit less than 250
mm (10 in.) away now, you can
change your driving position in sever-
al ways:
Move your seat to the rear as far
as you can while still reaching the
pedals comfortably.
Slightly recline the back of the
seat. Although vehicle designs vary,
many drivers can achieve the 250
mm (10 in.) distance, even with the
driver seat all the way forward, sim-
ply by reclining the back of the
seat somewhat. If reclining the back
of your seat makes it hard to see
the road, raise yourself by using a
firm, nonslippery cushion, or raise
the seat if your vehicle has that
feature.
If your steering wheel is adjustable,
tilt it downward. This points the air-
bag toward your chest instead of
your head and neck.
The seat should be adjusted as rec-
ommended by NHTSA above, while
still maintaining control of the foot
pedals, steering wheel, and your view
of the instrument panel controls.
Seats Front seats—
—Front seat precautions (on vehicles with SRS front airbags)

03_SEQUOIA_U (L/O 0301)
45
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
When returning seats to their origi-
nal position, observe the following
precautions in order to prevent per-
sonal injury in a collision or sud-
den stop:
Be careful not to get your hands or
feet pinched in the seat.
Make sure the seat is securely
locked by pushing forward and rear-
ward on the top of the seatback or
by trying to pull up the edge of the
bottom cushion. Failure to do so
will prevent the seat belt from oper-
ating properly.
Make sure the seat belts are not
twisted or caught under the seat
and are arranged in their proper
position and are ready to use.
Folding the seats up will enlarge the lug-
gage compartment. See “Luggage stowage
precautions” on page 292 in Section 2 for
precautions when loading luggage.
SEATBACK ANGLE ADJUSTING LEVER
Lean forward and pull the lever up.
Then lean back to the desired angle
and release the lever.
CAUTION
To reduce the risk of sliding under
the lap belt during a collision, avoid
reclining the seatback any more than
needed. The seat belts provide maxi-
mum protection in a frontal or rear
collision when the passengers are sit-
ting up straight and well back in the
seats. If you are reclined, the lap belt
may slide past your hips and apply
restraint forces directly to the abdo-
men. In the event of a frontal colli-
sion, the more the seat is reclined,
the greater the risk of personal injury.
—Adjusting second seat

03_SEQUOIA_U (L/O 0301)
47
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
Right side only—
When returning the foldedup second
seat to its original position:
Once the seat is moved from the
foldedup position to the foldeddown
position, it cannot be directly returned
to the foldedup position again. (It is
impossible to operate the seat in the
order 1→2→ 1.) When you return the
foldeddown seat (position 2) to its
foldedup position (position 1), you
must return the foldeddown seat (posi-
tion 2) to its original position (position
3) once. (It is possible to operate the
seat in the order 1 →2→ 3→ 1.)
BEFORE FOLDING UP SECOND SEATS
Stow the second seat belt buckles as
shown in the illustration.
This prevents the buckles from falling out
when you fold up the seatback.
NOTICE
The seat belt buckles must be stowed
before you fold up the second seat.
—Folding up second seats

03_SEQUOIA_U (L/O 0301)
48
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
Right side
Left side
FOLDING UP SECOND SEATS
Right side—1. Lower the head restraint to the low- est position. Fold down the seatback
while pulling the seatback angle ad-
justing lever and swing the whole
seat up and forward.
Left side—
1. Lower the head restraints to the low- est position. Fold down the seatback
while pulling the seatback angle ad-
justing lever and swing the whole
seat up and forward while pu lling
the seat lock release lever on the
side.
CAUTION
Make sure people or luggage are
clear from the seat. Then, hold the
seat and slowly move it. Otherwise,
people may be injured or luggage
may be damaged, if the seat hits
them.
To avoid serious injury, do not sit
on the folded seatback.
Left side only—Use the seat lock
release lever on the side only when
folding up the seat.
Vehicles without third seats—Folding up
the rear seats will enlarge the luggage
compartment. See “Luggage stowage pre-
cautions” on page 292 in Section 2 for
precautions when loading luggage.

03_SEQUOIA_U (L/O 0301)
50
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
From front
From rear1. SEAT POSITION ADJUSTING LEVER
From front—
Hold the center of the lever and pull it
up. Then slide the seat to the desired
position with slight body pressure and
release the lever.
From rear—
Pull the lever up. Then slide the seat
to the desired position and release the
lever.
When a person sits in the third seat
center position, adjust both seat cush-
ions to the same position.
Do not place anything under the seats. It
might interfere with the seatlock mecha-
nism.
2. SEATBACK ANGLE ADJUSTING LEVER
From front—
Lean forward and pull the lever toward
you. Then lean back to the desired
angle and release the lever.
From rear—
Push down the lever. Push the seatback
forward or pull it backward to the de-
sired angle and release the lever. When a person sits in the third seat
center position, align both seatbacks at
the same angle.
CAUTION
Adjust both seat cushions to the
same position and align both seat-
backs at the same angle when a
person sits in the third seat center
position. Otherwise, the person can-
not wear the seat belt properly and
this may cause serious injuries in
a collision.
To reduce the risk of sliding under
the lap belt during a collision,
avoid reclining the seatback any
more than needed. The seat belts
provide maximum protection in a
frontal or rear collision when the
passengers are sitting up straight
and well back in the seats. If you
are reclined, the lap belt may slide
past your hips and apply restraint
forces directly to the abdomen. In
the event of a frontal collision, the
more the seat is reclined, the great-
er the risk of personal injury.
—Adjusting third seats

03_SEQUOIA_U (L/O 0301)
51
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
BEFORE FOLDING UP THIRD SEATS1. Stow the third seat belt buckles as shown in the illustration.
This prevents the buckles from falling out
when you fold up the third seats.
NOTICE
The seat belt buckles must be stowed
before you fold up the third seats.
2. Make sure the shoulder belt passes through the hanger when folding the
third seats.
This prevents the shoulder belt from being
damaged.
CAUTION
The seat belt must be removed from
the hanger when the seat belt is in
use.
3. To stow the center seat belt, pull it slightly out of its cover. It will auto-
matically roll back partway. Roll the
seat belt backwards as shown above
and insert it into the slot of its cov-
er. Make sure the tabs are securely
locked in the cover.
NOTICE
The seat belt must be stowed before
you fold the seatback.
—Folding up third seats

03_SEQUOIA_U (L/O 0301)
52
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
CAUTION
When folding up the third seats, do
not fold down or up the second
seats.From frontFrom rear
FOLDING UP THIRD SEATS 1. Move the seat to the rearmost posi- tion. Lower the head restraint to the
lowest position. Unlock the seatback
and fold it down.
CAUTION
To avoid serious injury, do not sit on
the folded seatback.
Folding up the third seats will enlarge the
luggage compartment. See “Luggage stow-
age precautions” on page 292 in Section
2 for precautions when loading luggage.

03_SEQUOIA_U (L/O 0301)
54
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
CAUTION
When folding up the third seats, fix
the seats securely by adjusting the
length of the holding strap. Failure
to do so may cause an unexpected
accident or severe injury in the
event of emergency braking or a
collision.
When returning seats to their origi-
nal position, observe the following
precautions in order to prevent per-
sonal injury in a collision or sud-
den stop:
Be careful not to get your hands or
feet pinched in the seat.
Make sure the seat is securely
locked by pushing forward and rear-
ward on the top of the seatback or
by trying to pull up the edge of the
bottom cushion. Failure to do so
will prevent the seat belt from oper-
ating properly.
Make sure the seat belts are not
twisted or caught under the seat
and are arranged in their proper
position and are ready to use.
BEFORE REMOVING THIRD SEATS1. Stow the third seat belt buckles as shown in the illustration.
This prevents the buckles from falling out
when you remove the third seats.
NOTICE
The seat belt buckles must be stowed
before you remove the third seats.
2. When removing the third seats, pass the third seat belts through the
hangers.
This prevents the shoulder belt from being
damaged.
CAUTION
The seat belt must be removed from
the hanger when the seat belts is in
use.
—Removing third seats

03_SEQUOIA_U (L/O 0301)
55
2003 SEQUOIA from Jan. ’03 Prod. (OM34422U)
3. To stow the center seat belt, pull itslightly out of its cover. It will auto-
matically roll back partway. Roll the
seat belt backwards as shown above
and insert it into the slot of its cov-
er. Make sure the tabs are securely
locked in the cover.
NOTICE
The seat belt must be stowed before
you fold the seatback.
From front
From rear
REMOVING THIRD SEATS 1. Move the seat to the rearmost posi- tion. Lower the head restraint to the
lowest position. Unlock the seatback
and fold it down.
CAUTION
Make sure people or luggage are
clear from the seat. Then, hold the
seat and slowly move it. Otherwise,
people may be injured or luggage
may be damaged, if the seat hits
them.
