rear view mirror TOYOTA SEQUOIA 2004 1.G User Guide

04_SEQUOIA_U (L/O 0309)
11 3
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
To block the glare from the front when the
main sun visor is swung to the lateral
side (position 2), swing down the sub vi-
sor.
CAUTION
Do not extend the plate at the end of
the sun visor when the visor is in the
position 1. It can cover the antiglare
inside rear view mirror and obstruct
the rear view.
To use the vanity mirrors, swing down
the sun visor and open the cover.
On some models, the vanity light comes
on when you open the cover.
—Vanity mirrors

04_SEQUOIA_U (L/O 0309)
11 5
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Lights, Wipers and Defogger
Headlights and turn signals11 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flashers 11 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Instrument panel light control 120
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front fog lights 120
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Personal lights 121
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Center interior and personal lights 121
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center interior light 122
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Luggage compartment light 123
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch light 124
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Windshield wipers and washer 125
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Back window wiper and washer 125
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Back window and outside rear view mirror defoggers 126
. . . . . . . . . . .
SECTION 1 5

04_SEQUOIA_U (L/O 0309)
126
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
The knob automatically returns from these
positions after you release it.
For instructions on adding washer fluid,
see “Adding washer fluid” on page 389 in
Section 7−3.
If the back window is not fully closed, the
back window wiper and washer will not
work. Make sure the back window is fully
closed when using the back window wiper
and washer.
NOTICE
Do not operate the back window wip-
er if the back window is dry. It may
scratch the glass.To defog or defrost the back window,
push the switch with the back window
closed.
The key must be in the “ON” position.
The thin heater wires on the inside of the
back window will quickly clear the surface.
An indicator light will illuminate to indicate
the defogger is operating.
On some models, heater panels in the
outside rear view mirrors will also quickly
clear the surfaces.
Push the switch once again to turn the
defogger off.
The system will automatically shut off af-
ter the defoggers have operated about 15
minutes. Make sure you turn the defoggers off
when the surfaces are clear. Leaving the
defoggers on for a long time could cause
the battery to discharge, especially during
stop
−and− go driving. The defoggers are
not designed for drying rain water or for
melting snow.
CAUTION
On some models, since the mirror
surfaces can get hot, do not touch
them when the defogger switch is on.
NOTICE
When cleaning the inside of the back
window, be careful not to scratch or
damage the heater wires or connec-
tors.
If the back window is not fully closed, the
back window defogger will not work. Make
sure the back window is fully closed when
using the back window defogger.
Back window and outside rear
view mirror defoggers

04_SEQUOIA_U (L/O 0309)
310
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
1. Check the area around the vehicle be-fore entering it.
2. Adjust seat position, seatback angle, seat cushion angle, head restraint
height and steering wheel angle.
3. Adjust the inside and outside rear view mirrors.
4. Lock all doors.
5. Fasten seat belts. Once you turn the ignition key to “START”
position and release it, the cranking hold
function continues to crank the engine in
“ON” position until it starts.
The function stops cranking the engine
after about 25 seconds maximum if the
engine has not started yet. When you
crank the engine again, wait a few sec-
onds and restart it.
If you hold the key in “START” position,
the function will keep cranking for about
30 seconds maximum. 1. Apply the parking brake firmly.
2. Turn off unnecessary lights and acces-
sories.
3. Put the selector lever in “P”. If you need to restart the engine while the
vehicle is moving, put the selector le-
ver in “N”. A starter safety device will
prevent the starter from operating if the
selector lever is in any drive position.
4. Depress the brake pedal and hold it to the floor until driving off.
Before starting the engine How to start the engine—
—Cranking hold function
(a) Before cranking

04_SEQUOIA_U (L/O 0309)
321
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
TRAILER LIGHTS
Your vehicle is equipped with a wire
harness stored in the rear end under
body. Some models are fitted with a
socket for trailer lights under the rear
bumper. Use either of them to connect
and operate the trailer lights. However,
the trailer lights must comply with fed-
eral, state/provincial and local regula-
tions. See your local recreational ve-
hicle dealer or rental agency for the
correct type of wiring and relays for
your trailer. Check for correct operation
of the turn signals and stop lights each
time you hitch up. Direct splicing may
damage your vehicle’s electrical system
and cause a malfunction of your lights.
7−pin connector (with towing pack-
age)—This can be also connected to
the trailer brake and trailer sub battery.NOTICE
Do not tow a trailer with (1) total tail
light electric power consumption of
over 93 W or (2) total turn and stop
light electric power consumption of
over 54 W.
Ex. (1) Tail lights → under 9.3 W
(SAE J573 No.69)  10
bulbs
(2) Turn/stop lights → under 27
W (SAE J573 No.1157)  4
bulbs (left 2, right 2)
BREAKIN SCHEDULE
Toyota recommends that you do not
tow a trailer with a new vehicle or a
vehicle with any new power train com-
ponent (engine, transmission, differen-
tial, wheel bearing, etc.) for the first
3200 km (2000 miles) of driving. MAINTENANCE
If you tow a trailer, your vehicle will
require more frequent maintenance due
to the additional load. For this informa-
tion, please refer to the scheduled
maintenance information in the “Sched-
uled Maintenance Guide” or “Owner ’s
Manual Supplement”.
Retighten all fixing bolts of the towing
ball and bracket after approximately
1000 km (600 miles) of trailer driving.
PRETOWING SAFETY CHECK
Check that your vehicle remains level
when a loaded or unloaded trailer is
hitched. Do not drive if the vehicle has
an abnormal nose −up or nose −down
condition, and check for improper
tongue load, overload, worn suspension
or other possible causes.
Make sure the trailer cargo is securely
loaded so that it cannot shift.
Check that your rear view mirrors con-
form to any applicable federal, state/
provincial or local regulations. If not,
install the rear view mirrors required
for towing purpose.

04_SEQUOIA_U (L/O 0309)
404
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
20. AM2 25 A: Starting system, multiport
fuel injection system/sequential multi-
port fuel injection system, electronic
throttle control system, “IGN 1” and
“IGN 2” fuses
21. TURNHAZ 20 A: Turn signal lights,
emergency flashers
22. RAD NO.3 20 A: Car audio/video sys-
tem
23. ST 30 A: Starting system, “STA” fuse
24. HORN 10 A: Horns
25. EFI NO.2 10 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system, electronic throttle control
system
26. DOME 10 A: Center interior and per-
sonal lights, personal lights, luggage
compartment light, air conditioning sys-
tem, wireless remote control system,
garage door opener, ignition switch
light, door courtesy lights, foot light,
vanity lights, power antenna 27. ECUB 7.5 A:
Multiplex communication
system (power door lock system, secu-
rity system, auto −door locking system,
automatic light control system, head-
light delay off system, tail light auto
cut system, illuminated entry system,
daytime running light system), back
door lock system, driver and front pas-
senger door lock system, gauges and
meters
28. MIR HTR 15 A: Outside rear view mir-
ror heaters
29. RAD NO.1 25 A: Car audio system
30. TAIL 15 A: Tail lights, back door cour-
tesy light, license plate lights
31. ECUIG 10 A: Charging system, cruise
control system, anti −lock brake system,
vehicle stability control system, traction
control system (two −wheel drive mod-
els), active traction control system
(four− wheel drive models), electronical-
ly controlled automatic transmission
system, power antenna, electric moon
roof, back door lock system, driver and
front passenger door lock system,
gauges and meters, multi −information
display, SRS airbag system, front seat
belt pretensioners
32. WSH 25 A: Wipers and washer
33. AC INV 15 A: Power outlets 34. IGN 2 20 A:
Starting system
35. PWR NO.3 20 A: Rear passenger’s
power window (right side)
36. PWR NO.4 20 A: Rear passenger’s
power window (left side)
37. CIG 15 A: Air conditioning systems,
power rear view mirror control, ciga-
rette lighter
38. RAD NO.2 7.5 A: Car audio/video sys-
tem, power antenna, power outlets,
multiplex communication system (power
door lock system, security system,
auto− door locking system, automatic
light control system, headlight delay off
system, tail light auto cut system, illu-
minated entry system, daytime running
light system)
39. 4WD 20 A: A.D.D. control system,
four −wheel drive system
40. STOP 15 A: Stop lights, high− mounted
stop lights, multiport fuel injection sys-
tem/sequential multiport fuel injection
system, vehicle stability control system,
traction control system (two −wheel
dr
ive models), active traction control
system (four −wheel drive models), mul-
tiplex communication system (auto− door
locking system)

04_SEQUOIA_U (L/O 0309)
405
2004 SEQUOIA from Sep. ’03 Prod. (OM34423U)
41. OBD 7.5 A: On−board diagnosis sys-
tem
42. PANEL 7.5 A: Instrument panel lights,
glove box light, lights of seat heaters,
cigarette lighter, ashtrays, multi −infor-
mation display, car audio/video system,
gauge and meters, air conditioning sys-
tems
43. PWR NO.1 25 A: Driver ’s door lock
system
44. WIP 25 A: Wiper and washers
45. IGN 1 10 A: Charging system
46. SUN ROOF 25 A: Electric moon roof
47. PWR NO.2 25 A: Front passengers’
door lock system
48. HTR 10 A: Air conditioning systems,
electric cooling fan, back window de-
fogger, outside rear view mirror heater
49. FOG 15 A: Front fog lights
50. GAUGE 15 A: Back−up lights, seat
heaters, gauge and meters, air condi-
tioning systems
51. PWR OUTLET 15 A: Power outlets
52. SEAT HTR 15 A: Seat heaters Fuses (type B)
53. RR HEATER 30 A: Rear air condition-
ing system
54. HEATER 40 A: Front air conditioning
system
55. DEFOG 40 A: Back window defogger
56. MAIN 40 A: Starting system, “H −LP
RH”, “H− LP LH” and “STA” fuses
57. DOOR NO.2 30 A: Multiplex commu-
nication system (power door lock sys-
tem, security system, auto −door locking
system)
58. PWR SEAT 30 A: Power front seats
59. AM1 40 A: “HTR”, “CIG”, “GAUGE”,
“RAD NO.2”, “ECU −IG”, “WIPER”,
“WSH” and “4WD” fuses
60. PWR NO.5 30 A: Power door lock sys-
tem, back door lock system Fuses (type C)
61. ALT 140 A: “AM1”, “PWR SEAT”,
“TAIL”, “STOP”, “SUN ROOF”, “PANEL”,
“OBD”, “FOG”, “PWR NO.1”, “PWR
NO.2”, “PWR NO.5”, “PWR NO.3”,
“PWR NO.4”, “PWR OUTLET” and
“SEAT HTR” fuses
62. ABS 60 A: Anti−lock brake system,
vehicle stability control system, traction
control system (two −wheel drive mod-
els), active traction control system
(four −wheel drive models)
