1: Height control mode select switch
2: Height control switch
This rear height control air suspension
controls the vehicle height depending
on vehicle driving conditions.
You can choose automatic control mode
or manual control mode. In automatic
control mode, you can select the ve-
hicle height between “HI” (high), “N”
(normal) and “LO” (low) modes with the
height control switch. In manual control
mode, you can adjust the vehicle height
seamlessly with the height control
switch.
To change the mode between automatic
control mode and manual control mode,
use the height control mode select switch.The vehicle height is automatically ad-
justed to a selected height mode. Howev-
er, when the front drive control is in “4LO”
mode, the vehicle height cannot be ad-
justed automatically even if the vehicle
condition changes, but height mode can
be changed manually with the height con-
trol switch.
(a) Vehicle height modes
“N” (normal) mode—
The vehicle height in this mode is stan-
dard. Regardless of the number of occu-
pants or the luggage loading condition, the
vehicle height is always automatically ad-
justed to a fixed height in this mode while
the engine is running.
This mode is suitable for ordinary driving.
“HI” (high) mode—
The vehicle height is about 40 mm (1.6
in.) higher at rear than “N” mode height.
This mode is suitable when driving on
bumpy roads and through water.
However, when the vehicle speed exceeds
30 km/h (18 mph) in “HI” mode, “N” mode
is automatically selected.
CAUTION
“HI” mode should be only used for
severe offroad driving conditions.
Because the vehicle’s center of gravi-
ty is higher in this setting, the ve-
hicle may become unstable when
turning abruptly, resulting in an acci-
dent.
Rear height control air
suspension—
—Automatic control mode

05_SEQUOIA_U (L/O 0409)
191
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
(c) Vehicle height adjustment
To change the mode, push the height
control switch on either side of “”
(higher) or “ ” (lower).
The height control indicator light indicates
which mode is selected. (See “(d) Indica-
tor lights” described below.)
Selecting “HI” mode—
Push the height control switch on the “ ”
side when the vehicle speed is 30 km/h
(18 mph) or less.
To change “N” mode to “HI”, push the
switch once. To change “LO” mode to “HI”,
push the
switch twice.
Selecting “N” mode—
To change “HI” mode to “N”, push the
height control switch on the “ ” side
once.
If the underbody of the vehicle has
touched the surface on bumpy roads, the
vehicle height cannot be lowered with the
height control switch.
To change “LO” mode to “N”, push the
height control switch on the “ ” side
once.
Selecting “LO” mode—
Push the height control switch on the “ ”
side while the vehicle is stopped.
To change “N” mode to “LO”, push the
switch once.
To change “HI” mode to “LO”, push the
switch twice.
If the underbody of the vehicle has
touched the surface on bumpy roads, the
vehicle height cannot be lowered with the
height control switch. Even if the engine is stopped while the
vehicle height is being lowered, the opera-
tion continues for up to 35 seconds. If,
within this 35 seconds, any of the side
doors or the back door is opened, opera-
tion will continue for a further 15 seconds.
When adjusting the vehicle height with
one or more doors open, make sure that
there is nothing that might come into con-
tact with the vehicle body or around the
doors.

05_SEQUOIA_U (L/O 0409)
192
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
NOTICE
If the vehicle height is changed fre-
quently when the vehicle is heavily
loaded, the compressor may over-
heat, causing the vehicle height ad-
justment operation to stop.
 Before you lower the vehicle height
with the height control switch,
check under the vehicle to make
sure nothing to damage the vehicle
or no one to be injured is there and
that the underbody of the vehicle
does not touch the ground.
 After unloading, the height of a ve-
hicle equipped with the rear height
control air suspension becomes
slightly higher than the normal ve-
hicle height. Take sufficient care
where the overhead height is re-
stricted.
 Do not select “LO” mode for bumpy
roads. If the underbody of the ve-
hicle touches the road surface, the
vehicle may be damaged.
If you attempt to adjust the vehicle height
with anything such as snow, ice, or stones
in contact with the vehicle body, the ve-
hicle height may not change. In this case,
stop the vehicle, press the height control
mode select switch, and check that manu-
al control mode indicator light comes on.
Then, remove the obstruction.
CAUTION
If you drive through water, set the
vehicle height to “HI” with the height
control switch and then change to
manual control mode by pushing the
height control mode select switch. Do
not exceed 30 km/h (18 mph) or “HI”
mode will automatically change to
“N” mode. Do not drive through water
deeper than about 700 mm (28 in.)
even if the vehicle height is in “HI”
mode.
NOTICE
When jacking up or insta lling tire
chains, be sure to set manual con-
trol mode by pushing the height
control mode select switch and stop
the engine. Otherwise, the vehicle
height may change because of the
automatic leveling function, result-
ing in an accident.
 If your vehicle must be towed, set
the vehicle height to “N” and
change to manual control mode.
Otherwise, the vehicle height may
change because of the automatic
leveling function, resulting in an ac-
cident.
 If your vehicle gets stuck in a
ditch, set manual control mode by
pushing the height control mode se-
lect switch. Otherwise, the vehicle
height may change because of the
automatic leveling function, result-
ing in an accident.

05_SEQUOIA_U (L/O 0409)
193
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
(d) Indicator lights1. Height control indicator lights
2. Manual control mode indicator light
When the ignition switch is turned on, all
the indicator lights come on. The indicator
light showing the present mode only re-
mains on and all other lights go off after
a few seconds. This means the system
operates correctly.If you change the vehicle height mode,
the indicator lights change as follows:
When changing the vehicle height from
“N” mode to “HI”: 1. The “N” mode indicator light goes off and the “HI” mode indicator light blinks.
2. After the vehicle height control reaches “HI” mode, the “HI” mode indicator light
remains on. If the underbody of the vehicle has
touched the surface on bumpy roads or
the area around the rear suspension is
coated with ice, the vehicle height cannot
be changed with the height control switch.
In this case, move the vehicle or remove
the ice around the rear suspension. The
vehicle height will change to the selected
mode, after a while, when the ignition
switch is turned to the “ON” position.
In the following cases, there is a problem
somewhere in you rear height control air
suspension. Although there is no problem
to continue normal driving, have the rear
height control air suspension checked by
your Toyota dealer as soon as possible.
The height control indicator light and
manual control mode indicator light do
not come on when the ignition switch
is turned on.
The manual control mode indicator light
blinks.

05_SEQUOIA_U (L/O 0409)
194
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
(e) Parking and stopping tips
If you immediately stop the engine to park
the vehicle after off−road driving, the ve-
hicle height is lowered slightly as the ve-
hicle becomes cool. When parking, make
sure there is nothing that will be in con-
tact with the underbody of the vehicle.
When you start the engine, the vehicle
returns to the previous height.
If you park the vehicle for a long time,
the vehicle height may be gradually low-
ered. When parking for a long time, make
sure there is nothing that will be in con-
tact with the underbody of the vehicle.
When you start the engine, the vehicle
returns to the previous height.
If you stop the engine, the vehicle height
may change in accordance with the
change in the temperature. When you
start the engine, the vehicle returns to the
previous height. (f) Rear height control failure warning
If there is a problem somewhere in the
rear height control air suspension, “N”
mode is automatically selected. If this oc-
curs, the manual control mode indicator
light blinks and the vehicle height control
cannot be activated until the malfunction
is corrected. If this is the case, bring your
vehicle to your Toyota dealer as soon as
possible and have it checked.
(a) Selecting manual control mode
To select manual control mode, push
the height control mode select switch
with the vehicle stopped. The manual
control mode indicator light comes on
and the vehicle height is fixed at the
current height. The height can be ad-
justed by pushing the height control
switch.
The selected height is memorized in the
system even after the engine is stopped.
If you push the height control mode select
switch again, the manual control mode in-
dicator light goes out and automatic con-
trol mode is selected.
—Manual control mode

05_SEQUOIA_U (L/O 0409)
196
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
To raise the vehicle height—
Push the “” side of the switch for two
seconds or more. Each time you push the
switch, the vehicle height increases. When
the vehicle height is about 20 mm (0.8
in.) higher than the standard height, the
“HI” indicator light comes on.
The maximum selectable height is about
40 mm (1.6 in.) higher than the standard
height.
To lower the vehicle height—
Push the “ ” side of the switch. Each
time you push the switch, the vehicle
height decreases.
Tw o −wheel drive models—
When the vehicle height is about 7.5 mm
(0.3 in.) lower than the standard height,
the “LO” indicator light comes on.
The minimum selectable height is about
15 mm (0.6 in.) lower than the standard
height.
Four −wheel drive models—
When the vehicle height is about 15 mm
(0.6 in.) lower than the standard height,
the “LO” indicator light comes on.
The minimum selectable height is about
30 mm (1.2 in.) lower than the standard
height. If the underbody of the vehicle has
touched the surface on bumpy roads, the
vehicle height cannot be lowered with the
height control switch.
When adjusting the vehicle height with
one or more doors open, make sure that
there is nothing that might come into con-
tact with the vehicle body or around the
doors.
If the vehicle height is adjusted on the
slope, or with the selector lever in a posi-
tion other than “P” or “N” while the vehicle
is stopped, you may hear a sound caused
by the expansion and contraction of the
propeller shaft. This does not indicate a
malfunction.
CAUTION
The higher vehicle height should be
only set for severe offroad driving
conditions. Because the vehicle’s cen-
ter of gravity is higher in this setting,
the vehicle may become unstable
when turning abruptly, resulting in an
accident.
NOTICE

When lowering the vehicle, the ve-
hicle must be stopped. Otherwise,
when the vehicle speed exceeds 30
km/h (18 mph), automatic control
mode is activated and “N” is se-
lected automatically. Proper caution
should be taken in places where the
overhead height is limited.
 If the vehicle height is changed fre-
quently when the vehicle is heavily
loaded, the compressor may over-
heat, causing the vehicle height ad-
justment operation to stop.
 Before you lower the vehicle height
with the height control switch,
check under the vehicle to make
sure nothing to damage the vehicle
or no one to be injured is there and
that the underbody of the vehicle
does not touch the ground.
 After unloading, the height of a ve-
hicle equipped with the rear height
control air suspension becomes
slightly higher than the normal ve-
hicle height. Take sufficient care
where the overhead height is re-
stricted.

05_SEQUOIA_U (L/O 0409)
197
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
Do not lower the vehicle height for
bumpy roads. If the underbody of
the vehicle touches the road sur-
face, the vehicle may be damaged.
(c) Indicator lights
1. Height control indicator lights
2. Manual control mode indicator light
When the ignition switch is turned on, all
the indicator lights come on. The indicator
light showing the present mode only re-
mains on and all other lights go off after
a few seconds. This means the system
operates correctly. When you change the vehicle height in
manual mode, the height control indicator
light changes as follows:
Tw o
−wheel drive models
“HI”: 20 mm (0.8 in.) or higher than the standard height
“N”: Between −7.5 mm (0.3 in.) and 20
mm (0.8 in.) of the standard
height
“LO”: Lower than −7.5 mm (0.3 in.) of
the standard height
Four −wheel drive models
“HI”: 20 mm (0.8 in.) or higher than the standard height
“N”: Between −15mm (0.6 in.) and 20
mm (0.8 in.) of the standard
height
“LO”: Lower than −15 mm (0.6 in.) of
the standard height

05_SEQUOIA_U (L/O 0409)
198
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
In the following cases, there is a problem
somewhere in you rear height control air
suspension. Although there is no problem
to continue normal driving, have the rear
height control air suspension checked by
you Toyota dealer as soon as possible.
The height control indicator light and
manual control mode indicator light do
not come on when the ignition switch
is turned on.
The manual control mode indicator light
blinks.
(d) Parking and stopping tips
If you immediately stop the engine to park
the vehicle after off −road driving, the ve-
hicle height is lowered slightly as the ve-
hicle becomes cool. When parking, make
sure there is nothing that will be in con-
tact with the underbody of the vehicle.
If you park the vehicle for a long time,
the vehicle height may be gradually low-
ered. When parking for a long time, make
sure there is nothing that will be in con-
tact with the underbody of the vehicle.
If you stop the engine, the vehicle height
may change in accordance with the
change in the temperature. (e) Rear height control failure warning
If there is a problem somewhere in the
rear height control air suspension, the
manual control mode indicator light blinks.
If this is the case, change to the automat-
ic control mode by pushing the height
control mode select switch, and bring your
vehicle to your Toyota dealer as soon as
possible to have it checked.
The tire pressure warning system is de-
signed to provide warning when tire
inflation pressure of one or more of
your tires (including the spare tire) is
low. The low tire pressure warning light
comes on to inform you that low tire
inflation pressure may hamper driving.
Tire pressure warning
system—

05_SEQUOIA_U (L/O 0409)
213
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
BAL: Adjusts the sound balance between
the right and left speakers. The display
ranges from L7 to R7.
DISC (Compact disc)
Push the “DISC” button to play a compact
disc.
When the audio system is set into com-
pact disc operation, the display shows the
track, or track and disc number currently
being played.
Vehicles with rear seat entertainment sys-
tem—
The “DISC” button may also be used to
operate a DVD player when a disc is
loaded in the DVD player. Pressing the
“DISC” button changes between the CD
player and DVD player. When the DVD
player is in operation, “AUX” appears on
the display.
Error messages
If the player malfunctions, your audio sys-
tem will display one of the four following
error messages.
“WAIT”: The compact disc player unit
may be too hot. Allow the player to cool
down.
“ERROR 1”: The disc may be dirty, dam-
aged or inserted incorrectly (up −side
down). Clean the disc and re −insert it. “ERROR 3”:
There is a problem inside
the system. Eject the disc or magazine.
Set the disc or magazine again.
“ERROR 4”: Over−current. Ask your
Toyota dealer to inspect.
If the malfunction still exists, take your
vehicle to your Toyota dealer.
Dolby
B NR∗
If you are listening to a tape that was
recorded with Dolby  B Noise Reduction,
push “
” (preset button 3). “” will
appear on the display. Push the button
again to turn off Dolby B NR.
The Dolby NR mode reduces tape noise
by about 10 dB. For best sound reproduc-
tion, play your tapes with this button on
or off according to the mode used to re-
cord the tape.
∗: Dolby noise reduction manufactured under license from
Dolby Laboratories Licensing Corporation. “DOLBY” and the
double D symbol
are trademarks of Dolby Laboratories
Licensing Corporation.
FM
Push the “FM” button to turn on the radio
and select the FM band. “FM1” or “FM2”
will appear on the display. This system
allows you to set twelve FM stations, two
for each of the preset button. PWR·VOL (Power and Volume)
Push “PWR·VOL” to turn the audio system
on and off. Turn “PWR·VOL” to adjust the
volume.
RAND (Random)
Push “
” to listen the tracks on the
disc in random order. “
” will ap-
pear on the display. The disc you are
listening to will play in random order. To
turn off the random feature, push this but-
ton again.
RPT (Repeat)
Cassette player
Push “RPT” (preset button 2) while the
track is playing. “
” will appear on
the display. When the track ends, it will
automatically rewind and replay. To turn
off the repeat feature, push this button
again.
There must be at least 3 seconds of blank
space between tracks in order for the re-
peat feature to work correctly.

05_SEQUOIA_U (L/O 0409)
214
2005 SEQUOIA from Sep. ’04 Prod. (OM34431U)
Compact disc player
Push “
” while the track is playing.
“
” will appear on the display. When
the track ends, it will automatically be
replayed. This process will be continued
until you push the button again to turn off
the repeat feature. SCAN
Radio
You can either scan all the frequencies on
a band or scan only the preset stations
for that band.
To scan the preset stations:
Push and hold the “SCAN” button until
you hear a beep. The radio will tune in
the next preset station up the band, stay
there for 5 seconds, and then move to the
next preset station. To stop scanning,
push this button again.
To scan all the frequencies:
Quickly push and release the “SCAN” but-
ton. The radio will find the next station up
the station band, stay there for 5 seconds,
and then scan again to the next station.
To stop scanning, push this button again.
Compact disc player
Push “
” to scan the tracks on a spe-
cific disc. “
” will appear on the dis-
play and the player will scan all the tracks
on the disc you are listening to. To select
a track, push “SCAN” again. If the player
scanned all the tracks on the disc, it will
stop scanning. SEEK/TRACK (Seeking/Track up/down)
Radio
In the seek mode, the radio finds and
plays the next station up or down the
station band.
To seek the next station, quickly push and
release “
” or “ ” side of the “SEEK/
TRACK” button. Do this again to find the
station after that.
Cassette Player
Use this button to skip up or down to
locate a song or recording.
You can select up to nine recordings (in-
cluding current one).
A blank space of at least 3 seconds is
considered to be a start of a recording.
When the beginning of a tape is reached,
the player automatically resumes play.
When the end of the tape is reached, the
player automatically reverses sides and
resumes normal play.
In addition, the feature may not work well
with some spoken word, live, or classical
recordings.
