’06_SEQUOIA_U (L/O 0508)
333
The roof luggage carrier consists of
roof rails (1) attached to the roof and
sliding cross rails (2).
To adjust the positions of cross rails, do
this.1. Turn the knobs counterclockwise to loosen the cross rails.
2. Slide the cross rails to the desired position for loading the luggages of
various sizes.
3. After adjusting, be sure to tighten the cross rails by turning knobs clockwise.
Follow the manufacturer ’s instructions and
precautions when installing the attach-
ments or their equivalent.
CAUTION
When you load cargo on the roof lug-
gage carrier, observe the following:
Place the cargo so that its weight
is distributed evenly between the
front and rear axles.
If loading long or wide cargo, never
exceed the vehicle overall length or
width. (See “Dimensions and
weights” on page 456 in Section 8
for information on your vehicle
overall length and width.)
Before driving, make sure the cargo
is securely fastened on the roof
luggage carrier.
Loading cargo on the roof luggage
carrier will make the center of the
vehicle gravity higher. Avoid high
speeds, sudden starts, sharp turns,
sudden braking or abrupt maneu-
vers, otherwise it may result in loss
of control or vehicle rollover due to
failure to operate this vehicle cor-
rectly.
If driving for a long distance, on
rough roads, or at high speeds,
stop the vehicle now and then dur-
ing the trip to make sure the cargo
remains in its place.
Do not exceed 68 kg (150 lb.) cargo
weight on the roof luggage carrier.
NOTICE
When loading the luggages, be careful
not to scratch the surface of the
moon roof.
Roof luggage carrier

’06_SEQUOIA_U (L/O 0508)
455
SPECIFICATIONS
Specifications
Dimensions and weights456
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine 457
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . .
Fuel 457
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Service specifications 457
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
Tires 460
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . .
Fuses 461
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . .
SECTION 8

’06_SEQUOIA_U (L/O 0508)
456
∗1: Unladen vehicle∗2: With P245/70R16 tires and without
roof rails
∗3: With P265/70R16 or P265/65R17 tires
and without roof rails
∗4: With P245/70R16 tires and with roof
rails
∗5: With P265/70R16 or P265/65R17 tires
and with roof rails
∗6: Installing accessories in addition to
those installed at the factory increases
the weight of the vehicle, thereby re-
ducing vehicle capacity weight. Con-
tact your Toyota dealer about the
weight of accessory parts.
Dimensions and weights
1860 (73.2)∗2
1870 (73.6)∗3
1915 (75.4)∗4
1925 (75.8)∗5
Overall length mm (in.)
Overall width mm (in.)
Overall height
∗ 1mm (in.) Tw o
−wheel drive models
Four −wheel drive models
Wheelbase mm (in.)
Front tread mm (in.)
Rear tread mm (in.)
Vehicle capacity
weight
∗ 6 (occupants
 luggage) kg (lb.)
Towing capacity
(trailer weight +
cargo weight) kg (lb.)
5180 (203.9)
2005 (78.9)
1880 (74.0)
∗ 3
1935 (76.2)∗5
3000 (118.1)
1675 (65.9)
1710 (67.3)
567 (1250)
2948 (6500)
2812 (6200)
Tw o
−wheel drive models
Four −wheel drive models
