5
When trouble arises
639
5-2. Steps to take in an emergency
■
Four-wheel drive system warning buzzer
The buzzer indicated that the transfer mode is not selected correctly.
■ Key reminder buzzer
The buzzer indicates that the key has not been removed (with the engine
switch in the ACC or LOCK position and the driver’s door opened).
■ Open moon roof reminder buzzer
The buzzer indicate that the moon roof is still opened (with the engine switch
in the ACC or LOCK position and the driver’s door opened).
■ If the malfunction indicator lamp comes on while driving
First check the following:
● Is your vehicle low on gas?
If it is, refuel the vehicle immediately.
● Is the fuel tank cap loose?
If it is, tighten it securely.
The light will go off after taking several driving trips.
If the light does not go off even after several trips, contact your Toyota dealer
as soon as possible.
■ Front passenger detection sensor and passenger seat belt reminder
If luggage or other load is placed on the front passenger seat, depending on
its weight, the reminder light to flash and buzzer to sound.
■
When the tire pressure warning light comes on
Check the tire inflation pressure and adjust to the appropriate level.
Pushing the tire pressure warning reset switch does not turn off the tire
pressure warning light.
■The tire pressure warning light may turn on due to natural causes
The tire pressure warning light may turn on due to natural causes such
as natural air leaks or tire inflation pressure changes caused by temper-
ature. In this case, adjusting the ti re inflation pressure will turn off the
warning light (after several minutes).

5
When trouble arises
641
5-2. Steps to take in an emergency
■If the tire pressure warning light frequently comes on after blinking
for 1 minute
If the tire pressure warning light frequently comes on after blinking for 1
minute when the engine switch is turned to the ON position, have it
checked by your Toyota dealer.
■
Customization that can be co nfigured at Toyota dealer
The vehicle speed linked seat belt reminder buzzer can be disabled.
(Customizable features P. 703)
CAUTION
■If the tire pressure warning light comes on
Be sure to observe the following precautions. Failure to do so could
cause loss of vehicle control and result in death or serious injury.
●Stop your vehicle in a safe place as soon as possible. Adjust the tire
inflation pressure immediately.
●If the tire pressure warning light comes on even after tire inflation pres-
sure adjustment, it is pr obable that you have a flat tire. Check the tires.
If the tire is flat, change to the spare tire and have the flat tire repaired
by the nearest Toyota dealer.
●Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate,
you could lose control of the steering wheel or the brakes.
■If a blowout or sudden air leakage should occur
The tire pressure warning syste m may not activate immediately.

5
When trouble arises
657
5-2. Steps to take in an emergency
■After completing the tire change
The tire pressure warning
system must be reset. (P. 581)
■When using the temporary spare tire
As the temporary spare tire is not equipped with the tire pressure warn-
ing valve and transmitter, low inflation pressure of the temporary spare
tire will not be warned. Also, if you re place the temporary spare tire after
the tire pressure warning light comes on, the light remains on.
CAUTION
■Using the jack
Improper use of the jack may lead to death or serious injuries due to the
vehicle suddenly falling off the jack.
●Do not use the jack for any purpose other than replacing tires or install-
ing and removing tire chains.
●Only use the jack that comes with this vehicle for replacing a flat tire.
Do not use it on other vehicles, an d do not use other jacks for replac-
ing tires on this vehicle.
●Always check that the jack is securely set to the jack point.
●Do not put any part of your body under the vehicle supported by a jack.
●Do not start or run the engine while your vehicle is supported by the
jack.
●Do not raise the vehicle while someone is in it.
●When raising the vehicle, do not put an object on or under the jack.
●Do not raise the vehicle to a hei ght greater than that required to
replace the tire.
●Use a jack stand if it is necessary to get under the vehicle.
Take particular care when lowering the vehicle to ensure that no one
working on or near the vehicle will be injured.
■Using the jack handle
Insert the square head securely until you hear a click to prevent the
extension parts from coming apart unexpectedly.

666 5-2. Steps to take in an emergency
■Starting the engine when the battery is discharged
The engine cannot be started by push-starting.
■ Avoiding a discharged battery
●Turn off the headlights and the audio system while the engine is turned
off.
● Turn off any unnecessary electrical components when the vehicle is run-
ning at a low speed for an extended period, such as in heavy traffic, etc.
■ When the battery is removed or discharged
●Flex-fuel vehicles: The information recorded in the computer will be
cleared, which may cause the engine to run roughly and reduce driving
performance for a while when the engine is first started. In this case, wait
until the engine runs normally.
If the vehicle is running on E85, the engine may stall. In this case, restart
the engine, repeatedly if necessary.
● Make sure that the key is not inside the vehicle when recharging or
replacing the battery. The key may be locked in the vehicle if the alarm is
activated. ( P. 110)
■ Charging the battery
The electricity stored in the battery will discharge gradually even when the
vehicle is not in use, due to natural discharge and the draining effects of cer-
tain electrical appliances. If the vehicle is left for a long time, the battery may
discharge, and the engine may be unable to start. (The battery recharges
automatically during driving.)
Once the vehicle’s engine has started, remove the jumper
cables in the exact reverse order in which they were con-
nected.
Once the engine starts, have the vehicle checked at your Toyota
dealer as soon as possible.

682 6-1. Specifications
Ignition system
Electrical system
Differential
*: Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at thefactory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an
equivalent of matching quality to satisfy the above specification. Please con-
tact your Toyota dealer for further details.
Spark plug
Make DENSO
Gap SK20HR11
0.043 in. (1.1 mm)
NOTICE
■
Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine.
Battery
Open voltage at
68 F (20 C): 12.6  12.8 V Fully charged
12.2  12.4 V Half charged
11 . 8
 12.0 V Discharged
(Voltage checked 20 minutes after the
key is removed with all the lights
turned off)
Charging rates 5 A max.
Oil capacity
Front
(4WD models)2.17 qt. (2.05 L, 1.80 Imp.qt.)
Rear
1.64 qt. (1.55 L, 1.36 Imp.qt.)
Oil type and viscosity*Toyota Genuine Differential Gear Oil
LT 75W-85 GL-5 or equivalent

731
Alphabetical index
Engine
Compartment........................ 565
Engine switch ....................... 159
Hood ..................................... 564
How to start the
engine ................................ 159
Identification number ............ 678
If the engine will not start...... 661
Ignition switch ...................... 159
Overheating .......................... 668
Engine coolant
Capacity ............................... 681
Checking .............................. 570
Preparing and checking before winter ...................... 275
Engine coolan t temperature
gauge ..................................... 169
Engine immobilizer system .... 107
Engine oil Capacity ............................... 679
Checking .............................. 566
Preparing and checking before winter ...................... 275
Engine switch .......................... 159
Event data recorder .................. 27
FFV ................................... 102, 687
Flex-fuel ........................... 102, 687
Flexible fuel vehicle ........ 102, 687
Floor mat .................................. 528
Fluid Brake .................................... 572
Washer ................................. 578
Fog lights
Replacing light bulbs ............ 611
Switch ................................... 194
Wattage ................................ 686
Four-wheel drive system ........ 248
Front air conditioning system ................................... 302
Front passenger occupant classification system............ 127 Front passenger’s seat belt
reminder light.........................635
Front seats Adjustment ..............................50
Front side marker lights
Replacing light bulbs .............611
Switch....................................188
Wattage .................................686
Front turn signal lights Replacing light bulbs .............611
Wattage .................................686
Fuel Capacity ................................679
Fuel gauge ............................169
Fuel pump shut off system ....632
Gas station information .........740
Information ............................687
Refueling ...............................102
Type ......................................679
Fuel filler door ..........................102
Fuel pump shut off system .....632
Fuses.........................................599
Garage door opener.................535
Gas station information...........740
Gauges ......................................169
Glove box..................................483
Hands-free system (for cellular phone) ................448
Hazard lights Switch....................................624
Head restraints
Adjusting ................................68
Headlight cleaner .....................202
Headlights Replacing light bulbs .............611
Switch....................................188
Wattage .................................686
Heaters Seat heaters ..................518, 521
Side mirror.............................314
F
G
H

735
Alphabetical index
Steering wheel
Adjustment ....................... 82, 83
Audio switches ..................... 368
Climate remote control switches ............................. 317
Steering wheel memory.......... 65
Telephone switches.............. 453
Stop lights
Replacing light bulbs ............ 611
Wattage ................................ 686
Storage feature ........................ 482
Storage precautions ............... 270
Stuck If your vehicle becomes
stuck................................... 671
Sun visors ................................ 504
Sunshade ................................. 524
Switch BSM main switch .................. 236
Emergency flasher switch .... 624
Engine switch ....................... 159
Fog light switch..................... 194
Hazard light switch ............... 624
Ignition switch ....................... 159
Light switches ....................... 188
Power back door switch ... 33, 43
Power back window switch..... 96
Power door lock switch........... 37
Power window switch ............. 93
Rear window wiper and washer switch .................... 200
Seatback folding/returning
switch ............................. 57, 63
Window lock switch ................ 93
Wiper and washer switch ......................... 196, 200 Tachometer...............................169
Tail lights
Replacing light bulbs .............611
Switch....................................188
Wattage .................................686
Talk switch................................453
Telephone switch .....................453
Theft deterrent system Alarm .....................................109
Engine immobilizer system ... 107
Tire inflation pressure .............587
Tire information
Glossary ................................697
Size .......................................694
Tire identification number ......693
Uniform tire quality grading ................................695
Tires Chains ...................................276
Checking ...............................580
If you have a flat tire ..............650
Inflation pressure...........587, 685
Information ............................692
Replacing ..............................650
Rotating tires .........................580
Size .......................................685
Snow tires .............................275
Tire pressure warning system ........................580, 636
Tissue pocket ...........................491
Tools .........................................650
Total load capacity...................273
Towing Dinghy towing........................299
Emergency towing.................625
Trailer towing.........................279
Trailer weight rating.......281, 677T

736 Alphabetical index
Traction control........................ 255
TRAC ......................................... 255
Trip information ....................... 179
Trip meter ................................. 169
Turn signal lightsReplacing light bulbs ............. 611
Switch.................................... 166
Wattage ................................. 686
Valet key .....................................32
Vanity lights Vanity lights ........................... 505
Wattage ................................. 686
Vanity mirrors........................... 505
Vehicle data recordings ............26
Vehicle identification number ................................... 678
Vehicle stability control........... 255
VSC............................................ 255
Warning buzzers Brake system ........................ 633
Open door ............................. 635
Seat belt reminder ................. 635
Warning lights ABS ....................................... 634
Airbag system ....................... 634
Anti-lock brake system .......... 634
Brake assist system .............. 634
Brake system ........................ 633
Charging system .... ............... 633
Electronic engine control system ................................ 634
Malfunction indicator lamp .... 634
Master warning light .............. 638
Open door ............................. 635
Pretensioners ........................ 634
Seat belt reminder light ......... 635
SRS airbags .......................... 634
Tire pressure warning light .... 636 Warning messages .................. 644
Washer
Checking ............................... 578
Preparing and checking before winter ....................... 275
Switch ........................... 196, 200
Washing and waxing ............... 548
Weight Cargo capacity ...................... 268
Load limits ............................. 273
Towing capacity .................... 677
Trailer Weight Rating .... 284, 677
TWR .............................. 284, 677
Vehicle capacity weight......... 677
Weight ................................... 677
Wheels ...................................... 591
Window glasses .................. 93, 96
Window lock switch................... 93
Windows Power back window ................ 96
Power windows ....................... 93
Rear window defogger .......... 314
Washer.......................... 196, 200
Windshield wiper de-icer ........ 316
Windshield wipers ................... 196
Wireless remote control key Replacing the battery ............ 597
Wireless remote control .......... 33
WMA disc.................................. 340
V
W
