check engine light TOYOTA SEQUOIA 2017 2.G User Guide

409
4-3. Do-it-yourself maintenance
4
Maintenance and care
Power steering fluid
■ Fluid level
The fluid level should be within the appropriate range.
Full (when cold)
Add fluid (when cold)
Full (when hot)
Add fluid (when hot)
Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 minutes, or slightly longer in frigid temperatures. (Fluid
temperature, 140°F - 175°F [60°C - 80°C])
Cold: Engine has not been run for about 5 hours. (Room tem- perature, 50°F - 85°F[10°C - 30°C])
■ Checking the fluid level
Make sure to check the fluid type and prepare the necessary items.
Clean all dirt off the reservoir.
Remove the cap by turning it counterclockwise.
Wipe the dipstick clean.
Reinstall and remove the reservoir cap again.
Check the fluid level.
Fluid type Automatic transmission fluid DEXRON® II or III
Items Rag or paper towel and funnel (only for adding fluid)

5
When trouble arises
475
5-2. Steps to take in an emergency
■
Four-wheel drive system warning buzzer
The buzzer indicated that the transfer mode is not selected correctly.
■ Key reminder buzzer
The buzzer indicates that the key has not been removed (with the engine
switch in the ACC or LOCK position and the driver’s door opened).
■ Open moon roof reminder buzzer
The buzzer indicate that the moon roof is still opened (with the engine switch
in the ACC or LOCK position and the driver’s door opened).
■ If the malfunction indicator lamp comes on while driving
First check the following:
● Is your vehicle low on gas?
If it is, refuel the vehicle immediately.
● Is the fuel tank cap loose?
If it is, tighten it securely.
The light will go off after taking several driving trips.
If the light does not go off even after several trips, contact your Toyota dealer
as soon as possible.
■ Front passenger detection sensor and passenger seat belt reminder
If luggage or other load is placed on the front passenger seat, depending on
its weight, the reminder light to flash and buzzer to sound.
■
When the tire pressure warning light comes on
Check the tire inflation pressure and adjust to the appropriate level.
Pushing the tire pressure warning reset switch does not turn off the tire
pressure warning light.
■The tire pressure warning light may turn on due to natural causes
The tire pressure warning light may turn on due to natural causes such
as natural air leaks or tire inflat ion pressure changes caused by tem-
perature. In this case, adjusting the tire inflation pressure will turn off the
warning light (after several minutes).

5
When trouble arises
477
5-2. Steps to take in an emergency
■If the tire pressure warning light frequently comes on after blinking
for 1 minute
If the tire pressure warning light frequently comes on after blinking for 1
minute when the engine switch is turned to the ON position, have it
checked by your Toyota dealer.
■
Customization that can be co nfigured at Toyota dealer
The vehicle speed linked seat belt reminder buzzer can be disabled.
(Customizable features →P. 539)
CAUTION
■If the tire pressure warning light comes on
Be sure to observe the following precautions. Failure to do so could
cause loss of vehicle control and result in death or serious injury.
●Stop your vehicle in a safe place as soon as possible. Adjust the tire
inflation pressure immediately.
●If the tire pressure warning light come s on even after tire inflation pres-
sure adjustment, it is pr obable that you have a flat tire. Check the tires.
If the tire is flat, change to the spare tire and have the flat tire repaired
by the nearest Toyota dealer.
●Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate,
you could lose control of the steering wheel or the brakes.
■If a blowout or sudden air leakage should occur
The tire pressure warning syste m may not activate immediately.

5
When trouble arises
493
5-2. Steps to take in an emergency
Confirm that the tire is not loose
after tightening:
Push and pull the tire
Try rotating
Visually check to ensure the tire
is not hung on surrounding
parts.
If looseness or misassembly
exists, repeat step 2 and step 3.
Repeat step 3 any time the ti re is lowered or disturbed.
Stow the tools and jack securely.
■After completing the tire change
The tire pressure warning system must be reset. (→P. 417)
■When using the temporary spare tire
As the temporary spare tire is not equipped with the tire pressure warn-
ing valve and transmitter, low inflation pressure of the temporary spare
tire will not be warned. Also, if you replace the temporary spare tire after
the tire pressure warning light comes on, the light remains on.
CAUTION
■Using the jack
Improper use of the jack may lead to death or serious injuries due to the
vehicle suddenly falling off the jack.
●Do not use the jack for any purpose other than replacing tires or install-
ing and removing tire chains.
●Only use the jack that comes with this vehicle for replacing a flat tire.
Do not use it on other vehicles, an d do not use other jacks for replac-
ing tires on this vehicle.
●Always check that the jack is securely set to the jack point.
●Do not put any part of your body under the vehicle supported by a jack.
●Do not start or run the engine while your vehicle is supported by the
jack.
●Do not raise the vehicle while someone is in it.
●When raising the vehicle, do not put an object on or under the jack.
●Do not raise the vehicle to a hei ght greater than that required to
replace the tire.
●Use a jack stand if it is necessary to get under the vehicle.
Take particular care when lowering the vehicle to ensure that no one
working on or near the vehicle will be injured.

502 5-2. Steps to take in an emergency
■Starting the engine when the battery is discharged
The engine cannot be started by push-starting.
■ Avoiding a discharged battery
●Turn off the headlights and the audio system while the engine is turned
off.
● Turn off any unnecessary electrical components when the vehicle is run-
ning at a low speed for an extended period, such as in heavy traffic, etc.
■ When the battery is removed or discharged
Flex-fuel vehicles: The information re corded in the computer will be cleared,
which may cause the engine to run roughly and reduce driving performance
for a while when the engine is first started. In this case, wait until the engine
runs normally.
If the vehicle is running on E85, the engine may stall. In this case, restart the
engine, repeatedly if necessary.
■ Charging the battery
The electricity stored in the battery will discharge gradually even when the
vehicle is not in use, due to natural discharge and the draining effects of cer-
tain electrical appliances. If the vehicle is left for a long time, the battery may
discharge, and the engine may be unable to start. (The battery recharges
automatically during driving.)
Start the engine of the second vehicle. Increase the engine
speed slightly and maintain at that level for approximately 5
minutes to recharge the battery of your vehicle.
Maintain the engine speed of the second vehicle and start
the vehicle’s engine.
Once the vehicle’s engine has started, remove the jumper
cables in the exact reverse order in which they were con-
nected.
Once the engine starts, have th e vehicle checked at your Toyota
dealer as soon as possible.

518 6-1. Specifications
Ignition system
Electrical system
Differential
*: Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at thefactory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an
equivalent of matching quality to satisfy the above specification. Please con-
tact your Toyota dealer for further details.
Spark plug
Make DENSO
Gap SK20HR11
0.043 in. (1.1 mm)
NOTICE
■
Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine.
Battery
Open voltage at
68° F (20 °C): 12.6 ⎯ 12.8 V Fully charged
12.2 ⎯ 12.4 V Half charged
11 . 8
⎯ 12.0 V Discharged
(Voltage checked 20 minutes after the
key is removed with all the lights
turned off)
Charging rates 5 A max.
Oil capacity
Front
(4WD models)2.17 qt. (2.05 L, 1.80 Imp.qt.)
Rear
1.64 qt. (1.55 L, 1.36 Imp.qt.)
Oil type and viscosity*Toyota Genuine Differential Gear Oil
LT 75W-85 GL-5 or equivalent

565
Alphabetical index
Engine
Compartment........................ 400
Engine switch ....................... 158
Hood ..................................... 399
How to start the
engine ................................ 158
Identification number ............ 514
If the engine will not start...... 497
Ignition switch ...................... 158
Overheating .......................... 504
Engine coolant
Capacity ............................... 517
Checking .............................. 405
Preparing and checking before winter ...................... 266
Engine coolan t temperature
gauge ..................................... 168
Engine immobilizer system .... 105
Engine oil Capacity ............................... 516
Checking .............................. 401
Preparing and checking before winter ...................... 266
Engine switch .......................... 158
Event data recorder .................. 25 FFV ....................................100, 523
Flex-fuel ............................100, 523
Flexible fuel vehicle .........100, 523
Floor mat...................................363
Fluid
Brake .....................................407
Washer ..................................413
Fog lights
Replacing light bulbs .............447
Switch....................................193
Wattage .................................522
Four-wheel drive system .........239
Front air conditioning system ....................................294
Front passenger occupant classification system ............124
Front passenger’s seat belt
reminder light.........................471
Front seats Adjustment ..............................48
Front side marker lights Replacing light bulbs .............447
Switch....................................187
Wattage .................................522
Front turn signal lights Replacing light bulbs .............447
Wattage .................................522
Fuel Capacity ................................515
Fuel gauge ............................168
Fuel pump shut off system ....468
Gas station information .........576
Information ............................523
Refueling ...............................100
Type ......................................515
Fuel filler door ..........................100
Fuel pump shut off system .....468
Fuses.........................................435F
*: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.

571
Alphabetical index
Tachometer .............................. 168
Tail lights
Replacing light bulbs ............ 447
Switch ................................... 187
Wattage ................................ 522
Talk switch
*
Telephone switch*
Theft deterrent system Alarm .................................... 107
Engine immobilizer system... 105
Tire inflation pressure ............ 423
Tire information
Glossary ............................... 533
Size ...................................... 530
Tire identification number ..... 529
Uniform tire quality grading ............................... 531
Tires Chains .................................. 267
Checking .............................. 415
If you have a flat tire ............. 486
Inflation pressure .......... 423, 521
Information ........................... 528
Replacing ............................. 486
Rotating tires ........................ 416
Size ...................................... 521
Snow tires............................. 266
Tire pressure warning system........................ 416, 472 Tissue pocket ...........................327
Tools .........................................486
Total load capacity...................264
Towing
Dinghy towing........................290
Emergency towing.................461
Trailer towing.........................270
Trailer weight rating.......272, 513
Traction control........................246
TRAC .........................................246
Trip information .......................178
Trip meter .................................168
Turn signal lights Replacing light bulbs .............447
Switch....................................165
Wattage .................................522
Valet key .....................................30
Vanity lights Vanity lights ...........................341
Wattage .................................522
Vanity mirrors...........................341
Vehicle data recordings ............24
Vehicle identification number ...................................514
Vehicle stability control...........246
VSC............................................246
T
*: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.
V

572 Alphabetical index
Warning buzzersBrake system ........................ 469
Open door ............................. 471
Seat belt reminder ................. 471
Warning lights
ABS ....................................... 470
Airbag system ....................... 470
Anti-lock brake system .......... 470
Brake assist system .............. 470
Brake system ........................ 469
Charging system .... ............... 469
Electronic engine control system ................................ 470
Malfunction indicator lamp .... 470
Master warning light .............. 474
Open door ............................. 471
Pretensioners ........................ 470
Seat belt reminder light ......... 471
SRS airbags .......................... 470
Tire pressure warning light .... 472
Warning messages .................. 480
Washer Checking ............................... 413
Preparing and checking
before winter ....................... 266
Switch............................ 195, 199
Washing and waxing ............... 382 Weight
Cargo capacity ...................... 259
Load limits ............................. 264
Towing capacity .................... 513
Trailer Weight Rating .... 275, 513
TWR .............................. 275, 513
Vehicle capacity weight......... 513
Weight ................................... 513
Wheels ...................................... 427
Window glasses .................. 90, 93
Window lock switch................... 90
Windows Power back window ................ 93
Power windows ....................... 90
Rear window defogger .......... 307
Washer.......................... 195, 199
Windshield wiper de-icer ........ 309
Windshield wipers ................... 195
Wireless remote control key Replacing the battery ............ 433
Wireless remote control .......... 31
WMA disc
*
W
