Headlights (high beam) P. 187
Pictorial indexExterior
Hood
P. 399
Windshield wipers
P. 195
Outside rear view
mirrors
P. 84
Front turn signal/parking
lights and daytime running
lights
∗ P. 165, 187, 191
Moon roof∗ P. 96
Fog lights∗ P. 193
Headlights (low beam) P. 187
Front side marker lights
P. 187

175
2-2. Instrument cluster
2
When driving
■
Indicators
The indicators inform the driver of the operating state of the
vehicle’s various systems.
Turn signal indicator
( →P. 165)
(Canada)
Tail light indicator
( →P. 187)
Headlight high beam
indicator ( →P. 191)*1AUTO LSD indicator
(→P. 244, 247)
Security indicator
(→P. 105, 107)
(4WD models)
Center differential lock
indicator ( →P. 240)
Shift position and shift
range indicators
(→P. 161)
*1TRAC OFF indicator
( →P. 247, 249, 250)
*1
AIR BAG ON indicator
(→P. 124)
Cruise control indicator
(→P. 202, 206)*1AIR BAG OFF indicator
( →P. 124)
*1,4
Slip indicator
(→P. 245, 247)
(4WD models)
4HI indicator ( →P. 239)
*1VSC OFF indicator
(→P. 244, 247, 249,
250)
(4WD models)
4LO indicator ( →P. 239)
*6
(If equipped)
BSM outside rear view
mirror indicators
(→P. 227)
(If equipped)
TOW HAUL indicator
( →P. 163)
(U.S.A.)
Headlight indicator
(→P. 187)

191
2-3. Operating the lights and wipers
2
When driving
Turning on the high beam headlights
With the headlights on, push
the lever forward to turn on the
high beams.
Pull the lever back to the center
position to turn the high beams
off.
Pull the lever toward you to
turn on the high beams.
Release the lever to turn them off.
You can flash the high beams
with the headlights on or off.
■Daytime running light system (if equipped)
●To make your vehicle more visible to other drivers during daytime driving,
the daytime running lights turn on automatically whenever the engine is
started and the parking brake is released with the headlight switch off or
in the “AUTO” position. (Illuminate brighter than the parking light.) Day-
time running lights are not designed for use at night.
Type C and D: Daytime running lights can be turned off by operating the
switch.
● Compared to turning on the headlights, the daytime running light system
offers greater durability and consumes less electricity, so it can help
improve fuel economy.
■ Headlight control sensor
The sensor may not function properly if
an object is placed on the sensor, or any-
thing that blocks the sensor is affixed to
the windshield.
Doing so interferes with the sensor
detecting the level of ambient light and
may cause the automatic headlight sys-
tem to malfunction.

440 4-3. Do-it-yourself maintenance
28 ECU-B17.5 AMultiplex communication system,
Multiport fuel injection system/
sequential multiport fuel injection
system, auto anti-glare inside rear
view mirror, power front driver’s
seat, power tilt and power tele-
scopic, power back door, gateway
ECU
29 DOME 7.5 AInterior lights, personal lights, van-
ity lights, engine switch light, foot
light, door courtesy lights, acces-
sory meter, power back door,
power third seat
30 HEAD LH 15 ALeft-hand headlight
(high beam)
31 HEAD LL 15 ALeft-hand headlight
(low beam)
32 INJ 10 AMultiport fuel injection system/
sequential multiport fuel injection
system, ignition system
33 MET 7.5 A Gauges and meters
34 IGN 10 ASRS airbag system, multiport fuel
injection system/sequential multi-
port fuel injection system, cruise
control system, gateway ECU
35 HEAD RH 15 ARight-hand headlight
(high beam)
36 HEAD RL 15 ARight-hand headlight
(low beam)
37 EFI NO.2 10 AMultiport fuel injection system/
sequential multiport fuel injection
system, leak detection pump
38 DEF I/UP 5 A No circuit
FuseAmpereCircuit

447
4-3. Do-it-yourself maintenance
4
Maintenance and care
Light bulbs
You may replace the following bulbs yourself. The difficulty level of
replacement varies depending on the bulb. If necessary bulb
replacement seems difficult to perfor m, contact your Toyota dealer.
For more information about replacing other light bulbs, contact your
Toyota dealer.
■ Prepare a replacement light bulb.
Check the wattage of the li ght bulb being replaced. (→P. 522)
■ Front bulb locations
Headlight low
beam
Front side marker
lights
Headlight high beam
Front fog lights (if equipped)
Front turn signal/
parking lights and daytime running
lights (if equipped)

448 4-3. Do-it-yourself maintenance
Replacing light bulbs■ Headlight high beam
Unplug the connector while
depressing the lock release.
■Rear bulb locations
Stop/tail and rear
side marker lights
Rear turn signal lights
License plate lightsBack-up lights
Tail lights

522 6-1. Specifications
Light bulbs
A: HB3 halogen bulbs
B: H11 halogen bulbs
C: H10 halogen bulbs
D: Wedge base bulbs (clear)
E: Wedge base bulbs (amber)
F: Double end bulbs
Light BulbsBulb No.WTy p e
ExteriorHeadlights
(high beam)
9005 60 A
Headlights
(low beam) —55 B
Front fog lights 9145 45 C
Front side marker lights 168 5 D
Front turn signal/parking
lights 4157NAK 27/8 E
Rear turn signal lights — 21 E
Stop/tail and rear side
marker lights 7443 21/5 D
Tail lights 194 3.8 D
Back-up lights 921 16 D
License plate lights 168 5 D
Outer foot light — 5 D
InteriorVanity lights 7065 1.4 F
Personal/interior lights
Front — 5 D
Center — 5 D
Rear — 5 D
Interior light 7506 5 F
Foot well lighting — 1.4 D
Door courtesy lights 168 5 D
