TOYOTA SEQUOIA 2021 Owners Manual (in English)

3615-3. Using the storage features
5
Interior features
SEQUOIA_OM_USA_OM0C035U
Lift the lid while pulling up the
knob to release the lock.
Front console box
●When using the front console box lid as
an armrest, pull the knob up and slide
the lid forward as needed.
When the lid is forward, it cannot be
lifted.
● The tray in the console box slides for-
ward/ backward.
● To remove the tray, lift up the remove
position.

3625-3. Using the storage features
SEQUOIA_OM_USA_OM0C035U●
To remove the box, lift up.
● The following items can be stowed on
the backside of the console box lid.
Card holder
Map holder
Tissue holder
Pen holder
Card holder

3635-3. Using the storage features
5
Interior features
SEQUOIA_OM_USA_OM0C035U
Push the tab down to release
the lock and remove the lid.
Stow the lid.
Map holder (center console)
1
2
Rear console box (if equipped)
Upper boxLower box
Push the knob and lift the lid. P ush the knob and lift the lid.

3645-3. Using the storage features
SEQUOIA_OM_USA_OM0C035U
●The separator can be used at either of
two positions, change the separator
position.
● The separator can be stowed, stow the
separator to the lid.
● When using the back side tray, open the
upper box
● The inside tray can be removed, pull the
tray up.
● When closing the rear console box lid,
close the rear console box by lifting the
grip on the inside of the upper box.

3655-3. Using the storage features
5
Interior features
SEQUOIA_OM_USA_OM0C035U
The overhead console is useful for temporarily storing sunglass es and
similar small items.
Push the knob forward to open the
console.
WARNING
■ When opening/closing the lower box
Be careful not to get your hands or feet caught between the low er box and
the upper box.
Failure to do so may result in serious injury.
■ When opening the lower box
Make sure that the upper box is locked. Items stored inside may fall out and
cause injury.
Overhead console

3665-3. Using the storage features
SEQUOIA_OM_USA_OM0C035U
Cup holders
FrontFront console box
Pull the lid down.
Rear
Rear console box (if equipped)
On the rear console box
In the rear console box
Attach the separator when using either console box as a cup hol der.
Both cup holders cannot be used at the same time.

3675-3. Using the storage features
5
Interior features
SEQUOIA_OM_USA_OM0C035U
■Removing the cup holder (front)
Remove and stow the lid. ( P. 363)
■ Removing the separator (rear console box)
In the rear console box
On the rear console box Pull the cup holder up.
Pull the separator up.
Pull the separator up.
1
2

3685-3. Using the storage features
SEQUOIA_OM_USA_OM0C035U■
The position of the separator can be changed (rear console box)
In the rear console box
On the rear console box
■ The separator can be adjusted (rear console box) Change the separator position.
Change the separator position.
Adjust the separator.
WARNING
■Items unsuitable f or the cup holders
Do not place anything other than cups or beverage cans in the c up holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury. If possible, cover hot drinks to prevent
burns.
NOTICE
■ Before sliding the second center seat to the most forward posit ion
(vehicles with bench type second seat)
Ensure that the cup holder on the front console box is closed.

3695-3. Using the storage features
5
Interior features
SEQUOIA_OM_USA_OM0C035U
■When using the bottle holder
●When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
Bottle holders
Front seatsRear seats
WARNING
■Items unsuitable for the bottle holder
Do not place anything other than a bottle in the bottle holders .
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
■ Items that should not be st owed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottl es in the bot-
tle holders, or glasses and paper cups containing liquid. The c ontents may
spill and glasses may break.

3705-3. Using the storage features
SEQUOIA_OM_USA_OM0C035U
Auxiliary boxes
FrontRear
Press the knob then pull the lid
down. Pull the lid up.
Rear console box (if equipped)
Pull the lever and open the box.
