TOYOTA SEQUOIA 2021 Owners Manual (in English)

4516-3. Do-it-yourself maintenance
6
Maintenance and care
SEQUOIA_OM_USA_OM0C035U
Light bulbs
Check the wattage of the light bulb to be replaced. ( P. 530)
■Rear
You may replace the following bulbs by yourself. The difficulty
level of replacement varies depending on the bulb. If necessary
bulb replacement seems diffic ult to perform, contact your
Toyota dealer.
For more information about replacing other light bulbs, contact
your Toyota dealer.
Preparing for light bulb replacement
Bulb locations
Stop/tail and rear side marker
lights
Rear turn signal lights
Back-up lights Tail lights
License plate light

4526-3. Do-it-yourself maintenance
SEQUOIA_OM_USA_OM0C035U■
Stop/tail, rear side marker light
s and rear turn signal lights
Open the back door and remove the cover.
To protect the cover, place a rag between the flathead screwdri ver or
equivalent and cover as shown in the illustrations.
Left side (vehicles without speaker in the luggage)
Replacing light bulbs
1
Right sideLeft side (vehicles with
speaker in the luggage)

4536-3. Do-it-yourself maintenance
6
Maintenance and care
SEQUOIA_OM_USA_OM0C035U
Turn the bulb bases counter-
clockwise.Stop/tail and rear side
marker light
Rear turn signal light
Remove the light bulb. Stop/tail and rear side
marker light
Rear turn signal light
When installing, reverse the steps listed.2
3
4

4546-3. Do-it-yourself maintenance
SEQUOIA_OM_USA_OM0C035U■
Tail lights, back-up lights
Vehicles with power back
door only: Remove the cov-
ers.
To protect the cover, place a rag
between the flathead screw-
driver or equivalent and cover
as shown in the illustrations.
Remove the nuts.
Remove the rear combina-
tion light assembly in the
order shown in the illustra-
tion.
1
2
3

4556-3. Do-it-yourself maintenance
6
Maintenance and care
SEQUOIA_OM_USA_OM0C035U
Turn the bulb base counter-
clockwise.Tail light
Back-up light
Remove the light bulb. Tail light
Back-up light
When installing, reverse the steps listed.4
5
6

4566-3. Do-it-yourself maintenance
SEQUOIA_OM_USA_OM0C035U■
License plate lights
Remove the screws and
lens.
Remove the light bulb.
When installing, reverse the steps listed.
1
2
3

4576-3. Do-it-yourself maintenance
6
Maintenance and care
SEQUOIA_OM_USA_OM0C035U■
Replacing the following bulbs
If any of the lights listed below has burnt out, have it replac
ed by
your Toyota dealer.
● Headlight low beams
● Headlight high beams
● Front side marker lights
● Daytime running lights
● Parking lights
● Front turn signal lights
● Front fog lights
● Side turn signal lights (if equipped)
● High mounted stoplight
● Outer foot lights (if equipped)
■LED light bulbs
The following lights consist of a number of LEDs. If any LEDs burn out, take
your vehicle to your Toyota dealer to have the light replaced.
●Headlight low beams
● Headlight high beams
● Front side marker lights
● Daytime running lights
● Parking lights
● Front turn signal lights
● Front fog lights
● Side turn signal lights (if equipped)
● High mounted stoplight
● Outer foot lights (if equipped)
■ Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the lens does not indicate a
malfunction. Contact your Toyota dealer for more information in the following
situations:
● Large drops of water have built up on the inside of the lens.
● Water has built up inside the lens.

4586-3. Do-it-yourself maintenance
SEQUOIA_OM_USA_OM0C035U
WARNING
■Replacing light bulbs
● Turn off the lights. Do not attempt to replace the bulb immedia tely after
turning off the lights.
The bulbs become very hot and may cause burns.
● Do not touch the glass portion of the light bulb with bare hands. When it is
unavoidable to hold the glass portion, use and hold with a clea n dry cloth
to avoid getting moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.
● Fully install light bulbs and any parts used to secure them. Fa ilure to do so
may result in heat damage, fire, or water entering the headligh t unit. This
may damage the headlights or cause condensation to build up on the lens.
● Do not attempt to repair or disassemble light bulbs, connectors , electric
circuits or component parts.
Doing so may result in death or serious injury due to electric shock.
■ To prevent damage or fire
● Make sure bulbs are fully seated and locked.
● Check the wattage of the bulb before installing to prevent heat damage.

459
When trouble arises7
SEQUOIA_OM_USA_OM0C035U7-1. Essential information
Emergency flashers .......... 460
If your vehicle has to be stopped in an
emergency ...................... 461
If the vehicle is trapped in rising water.................. 463
7-2. Steps to take in an emergency
If your vehicle needs to be towed ......................... 464
If you think something is wrong .............................. 468
Fuel pump shut off system ............................ 469
If a warning light turns on or a warning buzzer
sounds ............................ 470
If a warning message is displayed......................... 479
If you have a flat tire.......... 491
If the engine will not start ................................. 505
If the electronic key does not operate properly ........ 507
If the vehicle battery is discharged ...................... 509
If your vehicle overheats ... 513
If the vehicle becomes stuck ............................... 516

4607-1. Essential information
SEQUOIA_OM_USA_OM0C035U
Emergency flashers
Press the switch.
All the turn signals will flash.
To turn them off, press the switch
once again.
■Emergency flashers
●If the emergency flashers are used for a long time while the engine is not
operating, the battery may discharge.
● If any of the SRS airbags deploy (inflate) or in the event of a strong rear
impact, the emergency flashers will turn on automatically
The emergency flashers will turn off automatically after operating for approx-
imately 20 minutes. To manually turn the emergency flashers off, press the
switch twice. (The emergency flashers may not turn on automatic ally
depending on the force of the impact and conditions of the coll ision.)
The emergency flashers are used to warn other drivers when the
vehicle has to be stopped in the road due to a breakdown, etc.
