4326-3. Do-it-yourself maintenance
SEQUOIA_OM_USA_OM0C035U■
Initializing the tire pressure warning system
Initialize the system
with the tire inflation pressure adjusted to the speci-
fied level.
■If the tread on snow tires wea rs down below 0.16 in. (4 mm)
The effectiveness of the tires as snow tires is lost.
■Situations in which the tire pressure warning system may not op er-
ate properly
●In the following cases, the tire pressure warning system may no t operate
properly.
• If non-genuine Toyota wheels are used.
• A tire has been replaced with a tire that is not an OE (Original Equip-
ment) tire.
• A tire has been replac ed with a tire that is not of the specif ied size.
• Tire chains, etc., are equipped.
• An auxiliary-supported ru n-flat tire is equipped.
• If a window tint that affects the radio wave signals is instal led.
• If there is a lot of snow or ice on the vehicle, particularly around the
wheels or wheel housings.
• If the tire inflation pressure is extremely higher than the sp ecified
level.
• If wheel without the tire pressure warning valve and transmitt er is
used.
• If the ID code on the tire pressure warning valves and transmi tters is
not registered in the tire pressure warning computer.
●Performance may be affected in the following situations.
• Near a TV tower, electric power plant, gas station, radio stat ion, large
display, airport or other facilit y that generates strong radio waves or
electrical noise
• When carrying a portable radio, cellular phone, cordless phone or
other wireless communication device
If tire position information is not correctly displayed due to the radio
wave conditions, the display may be corrected by driving and ch anging
the radio wave conditions.
●When the vehicle is parked, the time taken for the warning to s tart or go
off could be extended.
●When tire inflation pressure declines rapidly for example when a tire has
burst, the warning may not function.

4637-1. Essential information
SEQUOIA_OM_USA_OM0C035U
7
When trouble arises
If the vehicle is trapped in rising water
●Remove the seat belt first.
● If the door can be opened, open the door and exit the vehicle.
● If the door can not be opened, open the window using the power
window switch and exit the vehicle through the window.
● If the window can not be opened using the power window switch,
remain calm, wait until the water level inside the vehicle rise s to the
point that the water pressure i nside of the vehicle equals the water
pressure outside of the vehicl e, and then open the door and exi t the
vehicle.
In the event the vehicle is submerged in water, remain calm and
perform the following.
WARNING
■ Using an emergency hammer* for emergency escape
The front side windows and rear side windows, as well as the re ar window
can be shattered with an emergency hammer
* used for emergency escape.
However, an emergency hammer can not shatter the windshield as it is lam-
inated glass.
*: Contact your Toyota dealer or aftermarket accessory manufacturer for
further information about an emergency hammer.
■ Escaping the vehicle from the window
There are cases where escaping the vehicle from the window is n ot possi-
ble due to seating position, passenger body type, etc.
When using an emergency hammer, consider your seat location and the
size of the window opening to ensure that the opening is accessible and
large enough to escape.

5408-1. Specifications
SEQUOIA_OM_USA_OM0C035U
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure
Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressureThe maximum cold inflated pressure to which
a tire may be inflated, shown on the sidewall
of the tire
Recommended infla-
tion pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weight
The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight
The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant
weight150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
*
that follows
Occupant distributionDistribution of occupants in a vehicle as speci-
fied in the third column of Table 1
* below

5538-2. Customization
8
Vehicle specifications
SEQUOIA_OM_USA_OM0C035U■
Power back door (
P. 118)
■Power windows ( P. 165)
■Power back window ( P. 1 6 8 )
■Rear window wiper and washer ( P. 241)
FunctionDefault settingCustomized
setting
Switch operation Push and holdOne short
push—— O
Wireless remote control
linked operation On Off—— O
Operation signal volume Off
On—— O
Operation when door
locksPossible Impossible—— O
Time elapsed before back
door closing function is
activated when pushing
switch in the luggage
compartment1.5 seconds
0 seconds
—— O1 seconds
2 seconds
FunctionDefault settingCustomized
setting
Door key linked operation Open and close Open only—— OClose only
Off
FunctionDefault settingCustomizedsetting
Linked back door key
operation Open and closeOpen only—— OClose only
Sensitivity of jam protec-
tion function Level 1 Level 2 to 4
—— O
FunctionDefault settingCustomized
setting
Washer linkage wiper con-
trol On Off—— O
Drip prevention function On
Off—— O

5578-3. Items to initialize
8
Vehicle specifications
SEQUOIA_OM_USA_OM0C035U
Items to initialize
*: If equipped
The following item must be initialized for normal system opera-
tion after such cases as the battery being reconnected, or main -
tenance being performed on the vehicle:
ItemWhen to initializeReference
Power windowWhen functioning abnormallyP. 1 6 6
Power back windowWhen functioning abnormallyP. 1 6 9
Moon roofWhen functioning abnormallyP. 1 7 3
Power back door*
• After reconnecting or chang- ing the battery.
• After changing a fuse.
P. 1 2 1
Message indicating main-
tenance is required
(U.S.A. only)After the maintenance is per-
formedP. 4 0 6
Tire pressure warning
system
• When rotating the tires on vehicles differing with front
and rear tire inflation pres-
sures.
• When changing the tire infla- tion pressure by changing
traveling speed or load
weight, etc.
• When changing the tire size.
P. 4 2 8

573What to do if... (Troubleshooting)
SEQUOIA_OM_USA_OM0C035U
●Did you press the engine switch while firmly depressing the brake pedal?
( P. 214)
●Is the shift lever in P? ( P. 216)
●Is the electronic key anywhere detectable inside the vehicle? ( P. 129)
●Is the steering wheel unlocked? (P. 217)
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. ( P. 507)
●Is the battery discharged? (P. 509)
●Is the engine switch in ON?
If you cannot release the shift lever by depressing the brake p edal with the
engine switch in ON. ( P. 223)
●It is locked automatically to prevent theft of the vehicle. ( P. 2 1 7 )
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( P. 165)
If you think something is wrong
The engine does not start
The shift lever cannot be shifted from P even if you depress
the brake pedal
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches

577Alphabetical index
SEQUOIA_OM_USA_OM0C035U
Back doorBack door.............................. 118
Back window ......................... 168
Wireless remote control ........ 119
Back window ............................ 168
Back-up lights Replacing light bulbs............. 454
Wattage ................................ 530
Battery ...................................... 423 Battery checking ................... 423
If the vehicle battery
is discharged ...................... 509
Preparing and checking
before winter....................... 334
Voltmeter ................................ 94
Warning light ......................... 470
Blind Spot Monitor (BSM) ....... 296
Bluetooth
® *
Bluetooth® audio*
Bluetooth® phone*
Bottle holders .......................... 369
Brake Fluid ...................................... 421
Parking brake........................ 226
Warning light ......................... 470
Brake assist ............................. 322
Break-in tips ............................. 178
Brightness control Instrument panel light
control................................... 96
BSM (Blind Spot Monitor) ....... 296 Care .................................. 398, 402
Aluminum wheels ................. 399
Exterior ................................. 398
Interior .................................. 402
Seat belts.............................. 403
Cargo capacity......................... 193
Cargo hooks ............................ 371
Cargo net hooks ...................... 371
CD player
*
Center differential lock ........... 316
Chains ...................................... 336
Child restraint system............... 58 Booster seats, definition ......... 59
Booster seats, installation....... 69
Convertible seats, definition ... 59
Convertible seats,
installation ...................... 66, 68
Front passenger occupant classification syst em ............ 51
Infant seats, definition............. 59
Infant seats, installation .......... 66
Installing CRS with LATCH anchors ............ 64
Installing CRS with seat belts...................................... 66
Installing CRS
with top tether strap.............. 70
BC
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

578Alphabetical index
SEQUOIA_OM_USA_OM0C035U
Child safety ................................ 57Airbag precautions .................. 42
Back door precautions .......... 122
Battery precautions ....... 424, 512
Child restraint system ............. 58
How your child should
wear the seat belt ................. 34
Installing child restraints ......... 62
Moon roof precautions .......... 174
Power window lock switch .... 165
Power window precautions ... 167
Rear door child-protectors .... 115
Removed key battery precautions ......................... 447
Seat belt extender precautions ........................... 39
Seat belt precautions .............. 36
Seat heater precautions........ 352
Child-protectors....................... 115
Cleaning ........................... 398, 402 Aluminum wheels.................. 399
Exterior ................................. 398
Interior................................... 402
Seat belts .............................. 403
Climate control seat ................ 353
Compass .................................. 393
Condenser ................................ 420
Console box ..................... 361, 363
Cooling system Engine overheating ............... 513
Cruise control .......................... 276
Cup holders.............................. 366
Curtain shield airbags ............... 40
Customizable features ............ 546 Daytime running light
system.................................... 229
Defogger Outside rear view mirrors ..... 343
Rear window ......................... 343
Windshield ............................ 343
Dimension ................................ 520
Dinghy towing.......................... 213
Display Multi-information display ......... 98
Warning message................. 479
Do-it-yourself maintenance .... 411
Door courtesy lights ............... 355 Wattage ................................ 530
Doors Automatic door locking and
unlocking systems .............. 116
Back door ............................. 118
Door lock ...................... 113, 118
Door windows ....................... 165
Open door warning buzzer ... 482
Outside rear view mirrors ..... 161
Rear door child-protector ...... 115
Side doors ............................ 113
Drive information....................... 99
Driver’s seat position memory .................................. 149
Driving ...................................... 176 Break-in tips.......................... 178
Correct driving posture ........... 28
Driving assist systems .......... 322
Off-road precautions ............. 329
Procedures ........................... 176
Winter drive tips .................... 334D

580Alphabetical index
SEQUOIA_OM_USA_OM0C035U
Front side marker lights.......... 227Light switch ........................... 227
Replacing light bulbs............. 457
Front turn signal lights ........... 225 Replacing light bulbs............. 457
Turn signal lever ................... 225
Fuel ........................................... 244 Capacity ................................ 523
Fuel gauge .............................. 94
Fuel pump shut off system.... 469
Information ............................ 531
Refueling............................... 244
Type ...................................... 523
Warning light ......................... 472
Fuel consumption.................... 104
Fuel filler door.......................... 246 Refueling............................... 244
Fuel pump shut off system ..... 469
Fuses ........................................ 448
Garage door opener ................ 385
Gauges ....................................... 94
Glove box ................................. 360
Grocery bag hooks .................. 372
Hands-free system (for cellular phone)
*
Head restraints ........................ 154
Headlights ................................ 227 Automatic High Beam system ......... ....................... 231
Light switch ........................... 227
Replacing light bulbs............. 457
Heaters Air conditioning
system ....... ................. 340, 348
Outside rear view mirrors...... 343
Seat heaters ......................... 352
Hill-start assist control............ 322
Hood ......................................... 414 Hooks
Cargo hooks ......................... 371
Cargo net hooks ................... 371
Grocery bag hooks ............... 372
Retaining hooks (floor mat) .... 26
Horn .......................................... 157
I/M test ...................................... 410
Identification Engine .................................. 522
Vehicle .................................. 522
Ignition switch
(engine switch) ...................... 214
Illuminated entry system ........ 358
Immobilizer system ................... 76
Indicators ................................... 91
Initialization Maintenance ......................... 406
Moon roof ............................. 173
Power back window .............. 169
Power windows..................... 166
Tire pressure warning
system .......... ...................... 428
Inside rear view mirror ............ 158
Instrument panel light
control ...................................... 96
Interior lights ........................... 355
Intuitive parking assist ........... 290 Function ................................ 290
Warning message......... 481, 483
Jack Vehicle-equipped jack .......... 492
Jack handle .............................. 495
Jam protection function Moon roof ............................. 172
Power back door................... 121
Power back window .............. 169
Power windows..................... 166
G
H
I
J

582Alphabetical index
SEQUOIA_OM_USA_OM0C035U
MirrorsInside rear view mirror .......... 158
Outside rear view mirror
defoggers ........................... 343
Outside rear view mirrors...... 161
Vanity mirrors........................ 376
Moon roof ................................. 171 Door lock linked moon roof
operation ............................ 173
Jam protection function......... 172
Operation .............................. 171
MP3 disc
*
Multi-information display .......... 98 Drive information..................... 99
Language .............................. 100
LDA (Lane Departure Alert) ................................... 268
PCS (Pre-Collision system) ........ ....................... 255
Settings ................................. 100
Warning message ................. 479
Navigation system
*
Noise from under vehicle............ 8
Odometer.................................... 94
Off-road precaution s ............... 329
Oil Differential oil ........................ 527
Engine oil ...................... 416, 524
Transfer oil ............................ 527
Opener
Back door.............................. 120
Fuel filler door ....................... 246
Hood ..................................... 414
Outer foot lights....................... 355
Outside rear view mirrors ....... 161 Adjusting and folding ............ 161
BSM (Blind Spot Monitor) ..... 296
Outside rear view mirror defoggers ................. 343 Outside temperature
display...................................... 94
Overhead console ................... 365
Overheating, Engine ............... 513
Parking brake........................... 226 Operation .............................. 226
Parking brake engaged warning buzzer/
message............................. 482
Parking lights........................... 227 Light switch ........................... 227
Replacing light bulbs ............ 457
PCS (Pre-Collision system) .... 255 Enabling/disabling
the system ......... ................. 259
Pen holder ................................ 361
Personal lights......................... 357
Power back window ................ 168 Jam protection function ........ 169
Operation .............................. 168
Power outlets ........................... 377
Power steering Fluid .............................. 422, 528
Warning light......................... 471
Power windows ....................... 165 Door lock linked window operation ............................ 166
Jam protection function ........ 166
Operation .............................. 165
Window lock switch .............. 165
Pre-Collision system (PCS) ...................................... 255 Enabling/disabling
the system ......... ................. 259
N
O
P
